LANCOM 9100 VPN
Chapter 2: Installation
·
Fan The Fan LED displays the fan's status:
Green
Orange
Red
To prevent damage to the hardware, this LED is complemented by an acoustic
signal. If the fan is blocked or the CPU temperature exceeds 60°, a pulsed
acoustic signal is emitted.
»
COM Connection status of the serial configuration interface
Off
Green
Orange
¿
Online The online LED displays the general status of all WAN interfaces:
Off
Green
Green
Green
Red
´
Backup Displays the backup status:
Off
Red
16
On (perma- CPU temperature OK
nently)
On (perma- CPU temperature > 55°
nently)
blinking Hardware failure of the fan or CPU temperature > 60°; addi-
tional acoustic signal
No session logged on
On (perma- Serial configuration session logged on
nently)
Flickering Data transmission during the configuration session
No active connection
Flashing Opening the first connection
Inverse flashing Opening an additional connection
On (perma- At least one connection is established
nently)
On (perma- Error establishing the last connection
nently)
None of the WAN connections or virtual routers is in the
backup state
On (perma- At least one of the WAN connections or virtual routers is in
nently) the backup state
