Components and connections

3.2 Components and connections
Installation Instructions S1 Turbo | M1470113_en
Item
1 Boiler flow connection
2 Boiler return connection
3 Drainage connection
4 Safety battery connection
5 Immersion sleeve for thermal discharge valve (sup‐
plied by the customer)
6 Flue spigot
7 Immersion sleeve for boiler sensor and STL
8 Broadband probe connection
9 Flue gas temperature sensor connection
Name
3
Unit S1 Turbo
Inches 1
Inches 1
Inches ½
Inches ½
Inches ½
mm 130
Inches ½
Inches ¾
Inches ½
