Your new tool has been engineered and manufactured to WEN's highest standards for dependability,
ease of operation, and operator safety. When properly cared for, this product will supply you years
of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings,
and cautions. If you use your tool properly and for intended purpose, you will enjoy years of safe,
reliable service.
T50 20 Gauge
IMPORTANT:
NEED HELP? CONTACT US!
Have product questions? Need technical support?
Please feel free to contact us at:
800-232-1195
techsupport@wenproducts.com
WENPRODUCTS.COM
Stapler
Model # 61702
bit.ly/wenvideo
(M-F 8AM-5PM CST)
Advertisement
Table of Contents
Related Manuals for Wen 61702
Summary of Contents for Wen 61702
- Page 1 IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability, ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions.
-
Page 2: Table Of Contents
Technical Data Safety Rules Know Your Stapler Operation Troubleshooting Exploded View Parts List Warranty TECHNICAL DATA 61702 Model Number: 70 psi - 100 psi Operating Pressure Range: 1/4˝ NPT Air Inlet: 1/4˝ - 9/16˝ Staple Length: Staple Size: 20 Gauge 3/8˝... -
Page 3: Safety Rules
SAFETY RULES Hello! The purpose of the following safety symbols is to attract your attention to possible dangers. We don’t want any of our beloved customers accidentally injuring themselves. The safety symbols and the explanations with them deserve your careful attention and understanding. The safety warnings do not by themselves eliminate any danger. These instructions and warnings are not substitutes for proper accident prevention measures (obviously). - Page 4 SAFETY RULES 7. DRESS FOR SAFETY. Do not wear loose clothing, gloves, neckties, or jewelry (rings, watches, etc.) when operating the tool. Inappropriate clothing and items can get caught in moving parts and draw you in. ALWAYS wear non-slip footwear and tie back long hair. 8.
- Page 5 SAFETY RULES 18. MAKE THE WORKSHOP CHILDPROOF. Use padlocks and master switches and ALWAYS remove starter keys. Keep bystanders, children and visitors away while operating the power tool. Distractions can cause you to lose control. When tool is not in use, it should be locked away in a safe place. 19.
-
Page 6: Know Your Stapler
SAFETY RULES 31. KEEP ALERT. Watch what you are doing. Use common sense. Do not operate any tool when you are tired. 32. USE PROPER EXTENSION CORDS. When using an air compressor outdoors, use only rounded jackets extensions cords. These are intended for outside use. See manufacturer’s manual for the AWG required for the compressor’s amperage draw. -
Page 7: Operation
OPERATION WARNING - if any parts are missing, do not operate this tool until the missing parts are replaced. Failure to do so could result in possible serious personal injury. LUBRICATION This tool requires lubrication before each use (especially the first use). If an inline oiler is used, manual lubrication through the air inlet is not required. -
Page 8: General Operating Instructions
OPERATION LOADING THE STAPLE Warning: TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION, BEFORE LOADING: • Wear ANSI-approved safety goggles with side shields. Other people in the work area must also wear ANSI-approved impact safety goggles with side shields. • Release the trigger. •... -
Page 9: Troubleshooting
OPERATION CLEARING A JAMMED STAPLE WARNING: Disconnect the air line from the stapler and remove staples from the magazine before making ad- justments or personal injury may result. 1. If a staple is jammed in the discharge area, remove it with pliers. 2. -
Page 10: Exploded View
EXPLODED VIEW... -
Page 11: Parts List
Stock # Description Item Stock # Description 61702-001 SCREW 61702-030 SCREW 61702-002 CYLINDER CAP 61702-031 PLATE 2a 61702-002a EXHAUST DEFLECTOR 61702-032 SCREW 61702-003 GASKET 61702-033 DRIVE GUIDE 61702-004 SEAL 61702-034 SPRING PIN 2X10 61702-005 O-RING 15.7×2 61702-035 FIXED MAGAZINE UNIT... -
Page 12: Warranty
LIMITED ONE YEAR WARRANTY WEN Products is committed to building tools that are dependable for years. Our warranties are consistent with this commitment and our dedication to quality. LIMITED WARRANTY OF WEN CONSUMER POWER TOOLS PRODUCTS FOR HOME USE GREAT LAKES TECHNOLOGIES, LLC (“Seller”) warrants to the original purchaser only, that all WEN con- sumer power tools will be free from defects in material or workmanship for a period of one (1) year from date of purchase.
