MODEL BG4108
8-INCH WATER-COOLED
WET / DRY SHARPENER
Instruction Manual
NEED HELP? CONTACT US!
Have product questions? Need technical support? Please feel free to contact us:
1-847-429-9263 (M-F 8AM-5PM CST)
TECHSUPPORT@WENPRODUCTS.COM
IMPORTANT: Your new tool has been engineered and manufactured to WEN's highest standards for dependability,
ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged,
trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions. If you use
your tool properly and for its intended purpose, you will enjoy years of safe, reliable service.
WENPRODUCTS.COM
For replacement parts and the most up-to-date instruction manuals, visit

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BG4108 and is the answer not in the manual?

Questions and answers

Related Manuals for Wen BG4108

Summary of Contents for Wen BG4108

  • Page 1 1-847-429-9263 (M-F 8AM-5PM CST) TECHSUPPORT@WENPRODUCTS.COM IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability, ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions. If you use your tool properly and for its intended purpose, you will enjoy years of safe, reliable service.

  • Page 2: Table Of Contents

    CONTENTS WELCOME Introduction ..................... 3 Specifications ....................3 SAFETY General Safety Rules ..................4 Sharpener Safety Warnings................6 Electrical Information ..................8 BEFORE OPERATING Unpacking & Packing List .................9 Know Your Sharpener ..................10 Assembly & Adjustments ................11 OPERATION & MAINTENANCE Operation .......................

  • Page 3: Welcome

    INTRODUCTION Thanks for purchasing the WEN Wet / Dry Sharpener. We know you are excited to put your tool to work, but first, please take a moment to read through the manual. Safe operation of this tool requires that you read and understand this operator’s manual and all the labels affixed to the tool.

  • Page 4: Safety

    GENERAL SAFETY RULES WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Safety is a combination of common sense, staying alert and knowing how your item works. The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
  • Page 5 GENERAL SAFETY RULES WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Safety is a combination of common sense, staying alert and knowing how your item works. The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.

  • Page 6: Sharpener Safety Warnings

    SHARPENER SAFETY WARNINGS WARNING! Do not operate the power tool until you have read and understood the following instructions and the warning labels. SHARPENER SAFETY PERSONAL SAFETY 1. This sharpener is designed for sharpening and honing 1. Operate in a well ventilated area. Keep the floor area cutting tools, using the appropriate accessories.
  • Page 7 SHARPENER SAFETY WARNINGS WARNING! Do not operate the power tool until you have read and understood the following instructions and the warning labels. DURING OPERATION 7. Spacing between the tool rests and the wheel should always be set to 1/8 inch or less. Always hold the work- 1.

  • Page 8: Electrical Information

    ELECTRICAL INFORMATION GROUNDING INSTRUCTIONS In the event of a malfunction or breakdown, grounding provides the path of least resistance for an electric current and reduces the risk of electric shock. This tool is equipped with an electric cord that has an equipment grounding conductor and a grounding plug.

  • Page 9: Before Operating

    UNPACKING & PACKING LIST UNPACKING With the help of a friend or trustworthy foe, such as one of your in-laws, carefully remove the wet / dry sharpener from the packaging and place it on a sturdy, flat surface. Make sure to take out all contents and accessories. Do not discard the packaging until everything is removed.

  • Page 10: Know Your Sharpener

    KNOW YOUR SHARPENER TOOL PURPOSE This sharpener features a 8-inch grinding wheel and an 8.75-inch leather stropping wheel for sharpening and pol- ishing dull blades, wood chisels, knives, scissors, carving tools, axes and more. Refer to the following diagrams to become familiarized with all the parts and controls of your sharpener.

  • Page 11: Assembly & Adjustments

    ASSEMBLY & ADJUSTMENTS WARNING! To avoid injury from accidental startups, be sure that the tool is switched OFF and unplugged from the power source before inspecting the unit, making adjustments, or changing accessories. POSITIONING THE MACHINE Fig. 1 Place the machine on a stable, flat work surface. The machine has four rubber feet pre-installed to increase stability and reduce vibra- tion.
  • Page 12 ASSEMBLY & ADJUSTMENTS WARNING! To avoid injury from accidental startups, be sure that the tool is switched OFF and unplugged from the power source before inspecting the unit, making adjustments, or changing accessories. INSTALLING THE WORK SUPPORT Fig. 3A The universal work support (Fig. 3A / 3B - 1) acts as both a work rest and as an attachment arm for various jigs.
  • Page 13 OTHER SHARPENING JIGS Short Knife Jig Long Knife Jig To sharpen knives, scissors and axes, you’ll need a WEN Sharpening Accessory Kit (Model 42704B or 42703) (Fig. 5), sold separately at wenproducts.com. Follow the instructions included with your acces- sory jig kit for assembly and operation.
  • Page 14 ASSEMBLY & ADJUSTMENTS WARNING! To avoid injury from accidental startups, be sure that the tool is switched OFF and unplugged from the power source before inspecting the unit, making adjustments, or changing accessories. SETTING THE ANGLE USING THE ANGLE GUIDE Fig.
  • Page 15 ASSEMBLY & ADJUSTMENTS WARNING! To avoid injury from accidental startups, be sure that the tool is switched OFF and unplugged from the power source before inspecting the unit, making adjustments, or changing accessories. PREPARING THE STROPPING WHEEL The leather stropping wheel is pre-installed on the machine. Follow the instructions below to prepare the stropping wheel before honing operations.

  • Page 16: Operation & Maintenance

    OPERATION WARNING! Do not plug in or turn on the tool until it is fully assembled according to the instructions. Read through and become familiarized with the following procedures of handling and adjusting your tool. Failure to follow the safety instructions may result in serious personal injury. OPERATION CHECKLIST Prior to starting your sharpener, check that the following requirements have been met: •...
  • Page 17 OPERATION HONING A BLADE After sharpening the blade, use the leather stropping wheel to remove burrs from the blade and create a smooth, sharp edge. TIP: Scissors should not be honed on the leather stropping wheel. Remove any burrs from the scissors blades by pulling the blades over the surface of a piece of end-grain wood.

  • Page 18: Troubleshooting Guide

    TROUBLESHOOTING GUIDE WARNING! Stop using the tool immediately if any of the following problems occur. Repairs and replacements should only be performed by an authorized technician. For any questions, please contact our customer service at 1-847-429-9263, M-F 8-5 CST or email us at techsupport@wenproducts.com. PROBLEM POSSIBLE CAUSE SOLUTION...

  • Page 19: Maintenance

    WARNING! Any attempt to repair or replace electrical parts on this tool may be hazardous. Servicing of the tool must be performed by a qualified technician. When servicing, use only identical WEN replacement parts. Use of other parts may be hazardous or induce product failure.
  • Page 20 Grinding wheels should be inspected for any damage or cracking before each use. Store the grinding wheels to prevent them from the potential hazards of moisture, containments and other damage. Replacement 8-inch grinding wheels (Part BG4108-034) can be pur- chased from wenproducts.com. To replace a grinding wheel: 1.

  • Page 21: Exploded View & Parts List

    EXPLODED VIEW & PARTS LIST NOTE: Not all parts may be available for purchase. Parts and accessories that wear down over the course of normal use are not covered under the warranty.
  • Page 22 EXPLODED VIEW & PARTS LIST PART NO. DESCRIPTION QTY. PART NO. DESCRIPTION QTY. Washer ф8.4x24x2 BG4108-025 Tool Support BG4108-001 Washer ф6.2x12x1.5 Leather Sharpening BG4108-026 BG4108-002 Wheel Assembly (Jig 70) Friction Wheel Plastic BG4108-027 Moving Clamp (Jig 70) BG4108-004 Part BG4108-028...

  • Page 23: Warranty Statement

    (2) years from date of purchase or 500 hours of use; whichever comes first. Ninety days for all WEN products if the tool is used for pro- fessional or commercial use.
