Wen 61782 Operator's Manual

Wen 61782 Operator's Manual

Coil roofing nailer
Hide thumbs Also See for 61782:

Advertisement

Quick Links

Download this manual See also: Instruction Manual
Your new tool has been engineered and manufactured to WEN's highest standards for dependability,
ease of operation, and operator safety. When properly cared for, this product will supply you years
of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings,
and cautions. If you use your tool properly and for intended purpose, you will enjoy years of safe,
reliable service.
COIL ROOFING
IMPORTANT:
NEED HELP? CONTACT US!
Have product questions? Need technical support?
Please feel free to contact us at:
800-232-1195
techsupport@wenproducts.com
WENPRODUCTS.COM
NAILER
Model # 61782
bit.ly/wenvideo
(M-F 8AM-5PM CST)

Advertisement

loading
Need help?

Need help?

Do you have a question about the 61782 and is the answer not in the manual?

Questions and answers

Related Manuals for Wen 61782

Summary of Contents for Wen 61782

  • Page 1 IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability, ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions.
  • Page 2 Safety Rules Know Your Nailer Operation Exploded View and Parts List Maintenance Troubleshooting Warranty TECHNICAL DATA Model Number: 61782 Operating Pressure Range: 70 psi - 120 psi Air Inlet: 1/4˝ NPT Fastener Length: 3/4˝ - 1-3/4˝ Fastener Diameter: 0.120˝ (11 gauge) Air Consumption: 0.1 cube feet/ cycle at 100 psi...

  • Page 3: Fastener Specifications

    FASTENERS SPECIFICATIONS Only use recommended fasteners (screw, ring or smooth shank). SAFETY RULES Hello! The purpose of the following safety symbols is to attract your attention to possible dangers. We don’t want any of our beloved customers accidentally injuring themselves. The safety symbols and the explanations with them deserve your careful attention and understanding.
  • Page 4 SAFETY RULES Safety is a combination of common sense, staying alert and knowing how your item works. SAVE THESE SAFETY INSTRUCTIONS. WARNING: To avoid mistakes and serious injury, do not use your tool until the following steps have been read and understood 1.
  • Page 5 SAFETY RULES 12. DISCONNECT tool from air supply when not in use. Remove fasteners from magazine before leaving the area or passing the tool to another operator. Do not climb ladders, stairs, scaffoldings, etc. without disconnecting the tool. Do not carry a connected tool to another work area. Do not make adjustments, remove magazine, perform maintenance or clear jammed fasteners while connected to the air supply.
  • Page 6 SAFETY RULES 24. DO NOT DRIVE NAILS onto the heads of other fasteners. Do not use the tool at too steep of an angle. Personal injury from strong recoil, jammed fasteners, or ricochetted nails may result. 25. BE AWARE of material thickness when using the nailer. A protruding nail may cause injury. 26.

  • Page 7: Know Your Nailer

    KNOW YOUR NAILER Exhaust Cover Depth Setting Wheel Trigger Safety Bracket Air Inlet Shingle Guide Magazine OPERATION WARNING - if any parts are missing, do not operate this tool until the missing parts are replaced. Failure to do so could result in a possibly serious personal injury. LUBRICATION (FIG.
  • Page 8 Fig. G TYPES OF TRIGGERS Because we’re nice people, we have included two different triggers that you can use with the WEN Coil Roofing Nailer depending on the task at hand. Rapid Fire Trigger (Red Trigger): This trigger allows for nails to be shot quickly, one after another. Only one of the two safety mechanisms (the trigger or the safety bracket) needs to be disengaged between nails.
  • Page 9 OPERATION TO CHANGE THE TRIGGER (FIG. H) WARNING: Disconnect air line from tool and remove fasteners from magazine before making adjustments or personal injury may result. To swap out the trigger switch: 1. Remove the o-ring on the side of the trigger pin. 2.

  • Page 10: Exploded View And Parts List

    EXPLODED VIEW AND PARTS LIST Part No. Description Part No. Description Part No. Description 61782B-001 Screw M5x20 61782B-036 Adjuster 61782B-071 61782B-002 Bushing 61782B-037 Bracket Assembly 61782B-072 O ring 24.3x2.8 61782B-003 Exhaust Cover 61782B-038 Nut M3 61782B-073 Feed Hook 61782B-004 Washer 61782B-039 Spring Pin 3x28 61782B-074...
  • Page 11 EXPLODED VIEW AND PARTS LIST...

  • Page 12: Maintenance

    MAINTENANCE CAUTION - Disconnect tool from air before cleaning and inspections. Correct all problems before operation. Add pneumatic tool oil into the oiler regularly to ensure the moving components are finely lubricated. Check the filter of the compressor weekly and switch off the manual valve to drain water and contaminations out. Wipe the tool clean.

  • Page 13: Warranty

    LIMITED ONE YEAR WARRANTY WEN Products is committed to building tools that are dependable for years. Our warranties are consistent with this commitment and our dedication to quality. LIMITED WARRANTY OF WEN CONSUMER POWER TOOLS PRODUCTS FOR HOME USE GREAT LAKES TECHNOLOGIES, LLC (“Seller”) warrants to the original purchaser only, that all WEN con- sumer power tools will be free from defects in material or workmanship for a period of one (1) year from date of purchase.
