Summary of Contents for Wen 5182
-
Page 2: Table Of Contents
Safety Instructions................Specific Safety Rules for Cordless Drill Driver........ Know Your Drill/Driver……………………………………………. Assembly.................... Operation.................... Maintenance..................Warranty ..................... SPECIFICATIONS Model: 5182 Motor: 18Volt DC No Load Speed: 0-550 RPM Number of Clutch Positions: 19+1 Max torque: 115 in. lbs Chuck Capacity: 3/8"... -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS GENRAL SAFETY RULES WARNING! Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in electric shock, fire and / or serious injury. WORK AREA SAFETY 1. Keep work area clean and well lit. Cluttered or dark areas invite accidents. 2. -
Page 4: Power Tool Use And Care
with your finger on the switch or energizing in power tools that have the switch on invites accidents. 4. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury. 5. -
Page 5: Specific Safety Rules For Cordless Drill Driver
4. Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid ejected from the battery may cause irritation or burns. SERVICE Have your power tool serviced by a qualified repair person using only identical replacement parts. - Page 6 3. Use of an attachment not recommended or sold by the battery-charger manufacturer may result in a risk of fire, electric shock or injury to persons. 4. Do not abuse the cord or charger. Never use the cord to carry the charger. Do not pull the charger cord to disconnect the plug from receptacle.
-
Page 7: Know Your Drill/Driver
KNOW YOUR DRILL/DRIVER 9 1 2 8 3 7 4 5 6 1-Torque Adjustment Ring 2-Keyless Chuck 3-Trigger Switch 4-LED Worklight 5-Battery Pack 6-Battery Release Button 7-Soft Grip Handle 8-Direction of Rotation Selector (Forward/Center Lock/Reverse) 9-Power Indicator WARNING! The safe use of this product requires an understanding of the... -
Page 8: Assembly
KEYLESS CHUCK The 3/8" keyless chuck allows you to hand-tighten or release the drill bit in the chuck jaws. FORWARD/REVERSE/CENTER LOCK The direction of rotation selector located above the trigger switch changes the direction of bit rotation. Setting the trigger switch in the OFF (center lock) position helps to reduce the possibility of accidental starting when not in use. -
Page 9: Operation
OPERATION CHARGING YOUR BATTERY PACK WARNING: The charger and battery pack are specifically designed to work together so do not attempt to use any other devices. Never insert or allow metallic objects into your charger or battery pack connections because an electrical failure and hazard will occur. - Page 10 POWER INDICATOR This drill is equipped with a power indicator which is used to display the battery pack’s remaining run time. Press the power indicator button to display the LED lights. When the battery capacity indicator is red, the battery has less than 30% of its capacity and should be charged. (4) ...
- Page 11 DIRECTION OF ROTATION SELECTOR (FORWARD/REVERSE/CENTER LOCK) Reverse Forward The direction of bit rotation is reversible and is controlled by a selector located above the trigger switch. With the Drill/Driver held in normal operating position: 1. Position the direction of rotation selector to the left of the tool for forward rotation. 2.
-
Page 12: Led Worklight
ADJUSTABLE TORQUE CLUTCH The torque clutch can be adjusted to 19+1 different settings. The higher the torque setting, the more force the drill produces. When using the drill for different driving applications, it is necessary to increase or decrease the torque in order to help prevent the possibility of damaging screw heads, threads, workpiece, etc. - Page 13 REMOVING BITS 1. Lock the trigger switch by placing the direction of rotation selector in the OFF (center) position. 2. Open the chuck jaws. NOTE: Rotate the chuck body in the direction of the arrow marked OPEN to close the chuck jaws.
- Page 14 METAL DRILLING For maximum performance, use high speed steel bits for metal or steel drilling. 1. When drilling metals, use light oil on the drill bit to keep it from overheating. The oil will prolong the life of the bit and increase the drilling action. 2.
-
Page 15: Maintenance
MAINTENANCE GENERAL MAINTENANCE Your tool requires no additional lubrication or maintenance. There are no user serviceable parts in your power tool. Never use water or chemical cleaners to clean your power tool. Wipe clean with a dry cloth. Always store your power tool in a dry place. Keep the motor ventilation slots clean.
