11. Reconnect all connectors to the backplate. See Figure 2-10 for connector locations.
Note
If option card is installed, connect the option card cable.

2.6.2 Digital I/O

Digital inputs can be set to provide many indicator functions, including all keypad functions except MENU. Digital
inputs are active (on) with low voltage (0 VDC), inactive (off) at 5 VDC. Use the DIGIO menu to configure the
digital inputs.
Digital outputs are typically used to control relays that drive other equipment. Outputs are designed to sink, rather
than source, switching current. Each output is a normally open collector circuit, capable of sinking 250 mA when
active. Digital outputs are active when low or at 0 VDC, with reference to the 5 VDC supply.
Use the DIO menu to set the function of the DIO pins to OUTPUT, them use the SETPTS menu to configure the
digital outputs.
Table 2-4 shows the pin assignments for connector J6.
2.7

Option Cards

Connector J2 is reserved for option cards. Table 2-5 lists the options available for the 880 Indicator. Each kit
includes instructions for installing and setting up the option.
2.8

Battery Replacement

When battery voltage gets low, the indicator display shows
displayed. The battery should last about seven years.
• Use the Revolution
of the indicator configuration on a PC before attempting battery replacement. If any data is lost, the
indicator configuration can be restored from the PC.
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type
WARNING
recommended by the manufacturer.
Dispose of unused batteries according to the manufacturer's instructions.
The battery should be considered bad and discarded at 2.9V.
Connector
J6
Table 2-4. J6 Pin Assignments (Digital I/O)
Option
Analog Output Card
Relay Board
EtherNet/IP
DeviceNet
Profibus DP
Profinet
Modbus TCP
Table 2-5. Available Option Cards
®
configuration utility or EDP commands (see Section 6.1 on page 58) to store a copy
Pin Signal
1 +5V
2 GND
3 DIO1
4 DIO2
5 DIO3
6 DIO4
Addendum Part Number
131601
131602
156554
156558
156556
156555
156557
. Replace the battery when this warning is
low bat
Installation 19
