Hardware Specifications
Standard Compliance: IEEE802.3/802.3ab / 802.3z / 802.3u / 802.3x
Network Interface:
Configuration
10/100/1000Mbps Gigabit TP
1000Base-SX Gigabit Fiber
1000Base-LX Gigabit Fiber
1000Base-LX Single Fiber WDM (BiDi) 1000 FDX
*Port 1, 8 are TP/SFP fiber dual media ports with auto detected function
*Optional SFP module supports LC or BiDi LC transceiver
Transmission Mode: 10/100Mbps support full or half duplex
Transmission Speed: 10/100/1000Mbps for TP
Full Forwarding/Filtering Packet Rate: PPS (packets per second)
MAC Address and Self-learning: 8K MAC address
Buffer Memory: Embedded 1392 KB frame buffer
Flow Control: IEEE802.3x compliant for full duplex
Backpressure flow control for half duplex
Cable and Maximum Length:
TP
1000Base-SX
1000Base-LX
1000Base-LX WDM (BiDi)
Mode
NWay
1000 FDX
1000 FDX
1000Mbps support full duplex only
1000Mbps for Fiber
Forwarding Rate
1,488,000PPS
148,800PPS
14,880PPS
4K VLAN table entries,
Cat. 5 UTP cable, up to 100m
Up to 220/275/500/550m,
which depends on Multi-Mode Fiber type
Single-Mode Fiber, up to10/30/50Km
Single-Mode Single Fiber, up to 20Km
288
Connector
TP (RJ-45)
*SFP
*SFP
*SFP
Speed
1000Mbps
100Mbps
10Mbps
Port
1 - 8
1-24(Option)
1-24(Option)
1-24(Option)
