NTP Server
Timezone
Day light Saving
Day light Saving Start
Day light Saving End : Mth: 1 Day: 1 Hour: 0
GS-2224L(time)#
trunk
del trunk
Syntax:
del trunk <port-range>
Description:
To delete the trunking port.
Argument:
<port-range>: port range, syntax 1,5-7, available from 1 to 24
Possible value:
<port-range>: 1 to 24
Example:
GS-2224L(trunk)# del trunk 1
set priority
Syntax:
set priority <range>
Description:
To set up the LACP system priority.
Argument:
<range>: available from 1 to 65535.
Possible value:
<range>: 1 to 65535, default: 32768
Example:
GS-2224L(trunk)# set priority 33333

set trunk

Syntax:
set trunk <port-range> <method> <group> <active LACP>
Description:
To set up the status of trunk, including the group number and mode of the trunk as
well as LACP mode.
Argument:
<port-range> : port range, syntax 1,5-7, available from 1 to 24
<method>:
static : adopt the static link aggregation
lacp : adopt the dynamic link aggregation- link aggregation control protocol
<group>: 1-8.
<active LACP>:
active : set the LACP to active mode
passive : set the LACP to passive mode
Possible value:
: 209.81.9.7
: GMT+8:00
: 0 Hours
: Mth: 1 Day: 1 Hour: 0
277
