Specifications
General Specifications
Display
LED lamp
Functions
Polarity
Current sensor
Overload indication
DCA zero adjust
Display rate
Battery
Operating temperature
Operating Humidity
Storage temperature
Altitude
Power consumption
Weight
Dimensions
Jaw opening
Standards
Electromagnetic
compatibility
Test Leads
6000 count LCD with multifunction indicators
Full scale 6200 counts for Capacitance function
Full scale 9999 counts for Frequency function
For Non‐Contact Voltage Detector
Current (ACA, DCA), Voltage (VAC, VDC), Resistance,
Capacitance, Frequency, Non‐Contact Voltage detector,
Continuity, and Diode test
"‐" indicates negative polarity (positive polarity assumed)
Hall effect
O.L
MA63: One‐touch ZERO button (also used as a Relative
function); MA61: REL button (Relative)
2~3 readings/second
Two 1.5V AAA batteries
0 0 0
0 C to 40 C (32 F to 104
< 75% RH 0~30C (32
< 50% RH 30~40C (86
0 0 0
‐10 C to 50 C (14 F to 122
2000m (6562')
20mA DC approx.
170g (6.0 oz.) including battery
175 x 60 x 33.5mm (6.9 x 2.4 x 1.3") (H x W x D)
17mm (0.7") 3000MCM
IEC/EN 61010‐1, EN61010‐2‐033, EN61010‐2‐032; Category III
300V, Category II 600V; pollution class 2
< 1V/m RF field: Overall accuracy = specified accuracy +5% of
the range. Unspecified indication for 1V/m RF field.
Use only test probes rated CAT II 600V, CAT III 300V or better
that meet the requirements of IEC 61010‐031
15
0
F)
0 0
F to 86 F)
0 0
F to 104 F)
0
F)
MA61_MA63-en-GB_V1.0 3/15
