④ Remove the Cable tie of Extruder – Cut two side cable ties of Extruder with scissors.
Pay attention not to damage the driven belt when cutting the cable tie.
Remove red colored two cable ties in figure.
⑤ Remove the bottom package on the heated bed.
Lift the heated Bed up and remove the package.
If the heated bed cannot be lifted up manually, turn on the power
and go to menu to activate {Motions>Bed Up}.
It may cause the failure of printer when the Cable Tie, tape and packaging is not removed.
Please remove all fixed maerials to operate the printer properly.
Mounting of Clean Filter
① Remove the package of included clean filter and mount it into the filter case at the internal right of printer.
Mount the clean filter into the case in the correct position(The arrow should be outward)
If it is positioned incorrectly, the filter performance will degrade and cause a malfunction of
the ventilation fan.
