Summary of Contents for HobbyKing Assault 100
-
Page 2: Table Of Contents
Prior to your first flight Troubleshooting Battery precautions Charging the battery Battery installation Receiver board interface ASSAULT 100 DSMX Satellite receiver settings How to bind and use the satellite receiver RF module parameters ASSAULT 100 RF module parameters Exploded view Parts list... -
Page 3: Introduction
From basic flight maneuvers to aggressive aerobatics, the Assault 100 can do it all for those who appreciate the power of larger helicopters but lack the flying space, we believe that the Assault 100 is the perfect replacement and solution. -
Page 4: Additional Safety Precautions
Additional safety precautions Helicopter parameters 293mm 87.5mm 113mm 249mm 38.4mm 7.4V 450mAh 25C Standard accessories Li-po battery x1 Main blade x1 pair Tail rotor x1 7.4V 450mAh 25C Mounting tape Hex wrench x1 Push rod x3 Connecting rod x2 Screws x1bag Philips screwdriver x1... -
Page 5: Pre-Flight
Binding procedures 5. ESC Lock: To prevent accidental start-ups, the ESC is locked when the ASSAULT 100 is initialized. To unlock, push the throttle up to midpoint then return it to the lowest position; at this point, you should hear the ESC give an au -dible warning, signifying that the ESC has been unlocked. -
Page 6: Prior To Your First Flight
Prior to your first flight Assault 100 Pitch forward Pitch backward Roll right Roll left... -
Page 7: Troubleshooting
Trouble shooting... -
Page 8: Battery Precautions
Battery precautions Use balance chargers to charge the flight battery. 7.4V Battery precautions TURNIGY 7.4V (2S) variable rate DC Li-Po charger Instructions : 1.Connect the XC-1S5 charger to a 110-220V wall outlet 2.Connect the lithium polymer battery to the charger via the balancing tap (white, four pin connector). The LEDs on the charger will turn red once charging has commenced, and green once charging has been completed. -
Page 9: Battery Installation
Battery installation Receiver board interface To tail motor To main motor DSMX satellite port Front Rear... -
Page 10: Assault 100 Dsmx Satellite Receiver Settings
Assault 100 DSMX / DSM2 Satellite receiver settings System setup Model type: Helicopter: Swash type: Normal: Function menu Throttle curve ( normal) 1：0% Travel 2：85% 3：85% AIL ELE RUD GER 4：85% 5：85% Pitch curve ( stunt ) Throttle curve (stunt) Pitch curve (normal) 1：40%... - Page 11 Bind plug Press and hold the bind button of the transmitter to Power on the receiver bind Unplug the battery and main receiver Bind successful Connect the receiver with the receiver board of Power on the transmitter, then the helicopter helicopter Fasten the satellite receiver to the helicopter Install the canopy...
- Page 12 RF Module instruction RF MODULE 1. RF MODULE CHART Internal power supply switch Mode indicator light : F/ J/ other Signal indicator light Also use to indicate charging status (Red : signal disable / charging ; Green : signal enable / low power ) Mode selector button 2.
-
Page 13: Assault 100 Rf Module Parameters
If you see the green light flash, please charge the battery immediately. RF Module status lights Assault 100 RF module parameters Select helicopter mode, Servo NORM, then set the output as PPM specifications are as follows:... - Page 14 FUTABA radio settings for the Assault 100 Select helicopter mode, Servo NORM, then set the output as PPM SWASHPLATE SETTING: PARAMETER RESET:Execute TYPE:HELICOPTER SWASH:H-1 MODUL:PPM ATL:ON [ END POINT ] [ THR-CURVE ](NORM) [ THR-CURVE ](IDL) 1 AILE 85/85 POINT - 1...
-
Page 15: Aile
Walkera radio settings for the Assault 100 MODEL 2.SWRSH 1.TYPE 1-NRM FUNCTION MENU: REVSW： ELEV (REV) AILE(REV) THRO(REV) RUDD(NORM) GEAR(NORM) PITCH(REV) GYRO(NORM) TRVRD ELEV : U 65% D 65 % AILE : L 55% R 55% THHOLD STATE: ACT THRO : H 100%... -
Page 16: Rudd
Turnigy 9X radio settings for the Assault 100 FUNCTION MENU: REVSW： ELEV (REV) AILE(REV) THRO(REV) RUDD(NORM) GEAR(NORM) PITCH(REV) GYRO(NORM) TRVRD THHOLD ELEV: U 65% D 65% AILE : L 55% R 55% STATE: ACT THRO: H 100% L 100% RUDD: L 70%... - Page 17 Turnigy 9X radio settings for the Assault 100 Remove the default 2.4GHz module System menu: 1. Type SELE Heli- Heli 1 2. Mode UAT PPM （SYSTEM） 1. TYPE SELE 2.MODE UAT PPM THCRV NORM (FUNCTION) REVERSE ELEV (REV) POINT - L...
-
Page 18: Pich
PIT/CV 3D AUX- CH CH5 GEAR POINT - L CH6 HOV CH7 HOV THRO CH8 PIT TRIM CH9 THRO HOLD H 100% E. POINT 1 AILE 75/75 2 ELEV 80//80 3 THRO 100/100 4 RUDD 75/75 5 GYRO 100/100 6 PICH 60/60 Exploded view... -
Page 19: Parts List
Parts list PART NAME Quantity Main frame 9255000066-0 9255000067-0 Swashplate set 9255000068-0 Linkage Black tail rotor 9255000069-0 Canopy 9255000070-0 Swashplate bearings Φ6xΦ10x2.5mm 9255000071-0 9255000072-0 Cross axle/Stepped rings/Screws 9255000073-0 Main motor Tail set 9255000074-0 Green main rotor blade 9255000075-0 Receiver 9255000076-0 Landing skid 9255000077-0 9255000078-0... -
Page 20: Accessories List
Accessories list Main frame Landing skid Black main rotor blade Swashplate set SKU : 9255000066-0 SKU : 9255000077-0 SKU : 9255000087-0 SKU : 9255000067-0 Main rotor hub/ Main blade grip Linkage Pull rod Main rotor hub cover SKU : 9255000078-0 SKU : 9255000068-0 SKU : 9255000079-0 SKU : 9255000088-0... - Page 21 SKU : 9255000096-0 SKU : 9255000085-0 Linear servo Tail set Green main rotor blade carton strip plate SKU : 9255000074-0 SKU : 9255000075-0 SKU : 9255000095-0 The Assault 100 utilizes BLHeli ESC technology. BLHeli is an open-sourced ESC firmware designed by enthusiasts.
