Page 2: Aircraft Specifications
AIRCRAFT SPECIFICATIONS： Wing Span: 1350mm/53.15" Wing Area: 26.01 Sq dm/ 403.2 Sq in Lenght:1070.5mm/40.95in Weight: 1500g RTF less battery RECOMMENDED EQUIPMENT： Motor: 2820/07 Radio: 4 channels, 4 servos Battery: 3S/4S 2200mAh-3300mAh ESC: 60A Warning! This model is not a toy. It is designed for maximum performance. - Page 3 1. Main Wing Wings Part List Cut the covering away Apply instant glue Fix the aileron servo Install the aileron horn Complete aileron servo system installing...
- Page 4 2. Main Landing Wheel Main Landing Wheel Part List The shaft passes through the wheel and the main landing chassis. Then fixed using M4 skidproof nut Put the complete wheel parts into the Locking the skidproof nut wheel cowling Locking the Wheelchocks Fix the wheel cowling with 4 tapping screw with pad...
- Page 5 Fix the main landing gear 3.Stabilizer/Vertical/Tail Wheel Stabilizer/ Vertical/Tail Wheel Part List Draw a line for cutting the covering away Judging by the line to cutting the Fix the stabilizer with instant glue covering away...
- Page 6 Cut the wood away and Apply instant glue drill a diameter for fixing the elevator 2mm hole linkage rod Fix the linkage rod with epoxy glue Apply instant glue Install the tail wheel Fix the tail wheel...
- Page 7 Bend the steel wire Fix the vertical with instant glue Cut the wood away and Fix the tail wheel steel wire with drill a diameter for fixing the tail wheel epoxy glue 2mm hole steel wire Install the elevator servo system Fix the elevator horn...
- Page 8 Fix the rudder horn and install rudder Complete elevator and rudder servo servo system system installing 4.Canopy/Cowling/Motor/Main Wing Cowling Part List Canopy Part List Fix the canopy with 6 pcs tapping Fix the cowling with 4 pcs M3*25 cross head screw screw with pad...
- Page 9 Install the canopy Fix the main wing Fix the cover plate Cover Plate Part List...
