Information about the device

Description of the device
The T3000 Multifunction measuring meter is used for
carrying out detailed analysis in the fields of material
and construction diagnostics. To do so, the device has
a 24 bit analogue/digital converter which delivers pre-
cise results and is permanently stable compared with
analogue measuring instruments.
The operating elements are found on the front and
sides of the robust housing. A scratch proof colour
display with touch function (1) is allows entering and
selecting values and functions and also displaying de-
tected results. You can also navigate the device soft-
ware for selecting measuring functions by using the
cross control (3) and the "OK" key (5).
Pressing the "Back" key (2) returns you to the previ-
ous screen of the device software. Pressing the "Main
menu" key (6) opens the main menu which is also
shown when you start the device.
Pressing the "Illumination on/off" key (4) either
switches the background illumination for the colour
display and the keys on or dims them.
The sensor connections (one SDI connection (7) and
one BNC connection (8)) are found above the colour
display (1). At the SDI connection (7), connect the ap-
propriate digital SDI sensor for the corresponding sit-
uation. The universal interface of the SDI sensors
allows the multifunction measuring meter to automat-
ically detect the sensor construction and/or indicates
when the wrong type of sensor is connected. Depend-
ing on the sensor construction, it is calibrated to the
prevailing surrounding conditions after connection.
Any sensor settings are saved directly to the corre-
sponding SDI sensor. The various measured values,
such as relative humidity, dew point or flow rate, are
automatically calculated by the SDI sensors and
transmitted to the multifunction measuring meter.
B - 3
At the BNC connection (8), you connect passive wood
or building moisture sensors.
The measured results of the sensor which is connect-
ed to the SDI or BNC connection are shown in the de-
vice's colour display (1).
The "On/Off" key (10) and a USB connection (11) are
found on the sides of the device.
You can connect the device to a computer by using the
supplied USB connection cable. Then you can extract
and analyse your measured results with the optional
MultiMeasure Studio Standard or MultiMeasure Studio
Professional software. Contact TROTEC
service if you want this alternative version.
