Information about the device

Device description
The pH measuring device BW10 is suited for measuring pH
values and temperatures of liquids.
With the automatic temperature compensation and the
automatic calibration functions the measuring device permits a
quick and precise determination of the pH value between pH 0
and pH 14 in the temperature measuring range between 0 and
50 °C.
The three-point calibration is already carried out before leaving
the factory, but it can also be repeated using the supplied
pH buffer solution set.
The determined pH value is displayed along with the water
temperature.
The device comes equipped with an exchangeable pH electrode.
The electrode and the water temperature probe are protected
from external influences by means of a removable protective
cap.
The device is further equipped with a Hold function for holding
the currently measured value.
The auto-off function switches the device off after 15 minutes
and can be deactivated if required.
Device depiction
4
1
BW 10
2
CAL
3
BW 10
4
HOLD
5
CAL
6
HOLD
7
8
9
No. Designation
1 Battery compartment with screw-on lid
2 LC display
3 CAL button
4 HOLD button
5 Power button
6 Screw cap
7 Measuring probe
8 Measuring electrode
9 Protective cap
Display
15
14
No. Designation
10 Measured pH value indication
11 °C indication
12 Measured temperature indication
13 °F indication
14 ATC indication
15 CAL indication
pH measuring device BW10
BW 10
10
11
12
13
EN
