IEX-408E-2VDSL2 Series
Quick Installation Guide
Moxa Managed VDSL2 Ethernet Extender Switch
Moxa Americas:
Toll-free: 1-888-669-2872
Tel:
1-714-528-6777
Fax:
1-714-528-6778
Moxa Europe:
Tel:
+49-89-3 70 03 99-0
Fax:
+49-89-3 70 03 99-99
Moxa India:
Tel:
+91-80-4172-9088
Fax:
+91-80-4132-1045
www.ipc2u.ru
Edition 1.0, April 2016
Technical Support Contact Information
www.moxa.com/support
2016 Moxa Inc. All rights reserved.
Moxa China (Shanghai office):
Toll-free: 800-820-5036
Tel:
+86-21-5258-9955
Fax:
+86-21-5258-5505
Moxa Asia-Pacific:
Tel:
+886-2-8919-1230
Fax:
+886-2-8919-1231
P/N: 1802004082010
*1802004082010*
www.moxa.pro
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Moxa Technologies IEX-408E-2VDSL2-HV
Summary of Contents for Moxa Technologies IEX-408E-2VDSL2-HV
- Page 1 IEX-408E-2VDSL2 Series Quick Installation Guide Moxa Managed VDSL2 Ethernet Extender Switch Edition 1.0, April 2016 Technical Support Contact Information www.moxa.com/support Moxa Americas: Moxa China (Shanghai office): Toll-free: 1-888-669-2872 Toll-free: 800-820-5036 Tel: 1-714-528-6777 Tel: +86-21-5258-9955 Fax: 1-714-528-6778 Fax: +86-21-5258-5505 Moxa Europe: Moxa Asia-Pacific: Tel: +49-89-3 70 03 99-0...
- Page 2 Overview The IEX-408E-2VDSL2 is an industrial managed Ethernet extender switch for establishing long distance Ethernet transmissions over twisted-pair copper wiring. IEX-408E-2VDSL2 units can easily be linked in series to form a long distance multi-drop configuration, with one IEX-408E-2VDSL2 unit located at each drop-point. Adjacent drop-points can be separated theoretically by up to 3 km, with a transmission speed of 1 Mbps achieved using a VDSL2 connection (with a connection distance of 300 m, a transmission speed of 100Mbps can be theoretically achieved).
-
Page 3: Package List
Easy network management by web browser, Telnet/serial console, Windows utility, ABC-02-USB, and MXview • Universal power supply options Universal high-voltage (HV) model (IEX-408E-2VDSL2-HV): 110/220 VDC/VAC (88 to 300 VDC, 85 to 264 VAC) Redundant dual inputs low-voltage (LV) model ... - Page 4 Ring, Ring Master, and Ring Coupler 5. Grounding screw (chassis ground) 6. 5-pin terminal receptor for power input(s) • Universal high-voltage (HV) model (IEX-408E-2VDSL2-HV): 110/220 VDC/VAC (PWR • Redundant dual inputs low-voltage (LV) model (IEX-408E-2VDSL2-LV): 12/24/48 VDC (PWR 1) and 12/24/48 VDC (PWR www.ipc2u.ru...
- Page 5 Rear Panel: 1. Screw holes for wall mounting 2. DIN-rail mounting kit Mounting Dimensions - unit = mm (inches) www.ipc2u.ru www.moxa.pro...
-
Page 6: Din-Rail Mounting
DIN-Rail Mounting The metal DIN-rail mounting kit is fixed to the back panel of the IEX-408E-2VDSL2. Mount the IEX-408E-2VDSL2 on the corrosion-free mounting rail that meets the EN 60715 standard. Installation STEP 1—Insert the upper lip of the DIN-rail kit into the mounting rail. -
Page 7: Wiring Requirement
STEP 2—Mounting the IEX-408E-2VDSL2 on the wall requires 4 screws. Use the IEX-408E-2VDSL2, with wall mount plates attached, as a guide to mark the location of the 4 screws. The heads of the screws should be less than 6.0 mm in diameter, and the shafts should be less than 3.5 mm in diameter, as shown in the figure on the right. -
Page 8: Wiring The Relay Contact
Grounding the Moxa IEX-408E-2VDSL2 Ethernet Extender Switch Grounding and wire routing help limit the effects of noise due to electromagnetic interference (EMI). Run the ground connection from the ground screw (chassis ground) to the grounding surface prior to connecting devices. ATTENTION This product is intended to be mounted onto a well-grounded mounting surface, such as a metal panel. -
Page 9: Wiring The Power Input
STEP 3—Insert the plastic terminal block connector prongs into the terminal block receptor, which is located on the IEX-408E-2VDSL2’s top panel. FAULT: The two contacts of the 4-pin terminal block connector are used to detect user-configured events. The two wires attached to the fault contacts form an open circuit when a user-configured event is triggered. -
Page 10: Wiring The Redundant Power Inputs
Take the following steps to wire the power input: STEP 1: Insert the Line/Neutral AC or Positive/Negative DC wires into the terminals (Terminal 1 for Line/Positive and Terminal 5 for Neutral/Negative) of the terminal block connector. STEP 2: To keep the AC or DC wires from coming loose, use a small flathead screwdriver to tighten the wire-clamp screws on the front of the terminal block connector. -
Page 11: Communication Connections
Communication Connections Each IEX-408E-2VDSL2 extender switch has 4 types of communication ports: • 1 USB console port (type B connector) • 1 USB storage port (type A connector) • 6 10/100BaseT(X) Fast Ethernet ports • 2 DSL (VDSL2 technology) ports USB Console Connection The IEX-408E-2VDSL2 has one USB console port (type B connector;... -
Page 12: 10/100Baset(X) Ethernet Port Connection
10/100BaseT(X) Ethernet Port Connection The 10/100BaseT(X) ports located on the IEX’s front panel are used to connect to Ethernet-enabled devices. Most users configure these ports for Auto MDI/MDI-X mode, in which case the port's pinouts are adjusted automatically depending on the type of Ethernet cable wiring (straight-through or cross-over), and the type of device (NIC-type or HUB/Switch-type) connected to the port. -
Page 13: Reset Button
DSL Port Pinouts for RJ45/RJ11 Connector Signal – – – Ring – – – Wiring the 2-pin DSL Port The 2-pin terminal block connectors on the IEX's front panel are used for the IEX's DSL port wiring. Top and front views of the terminal block connectors are shown below. -
Page 14: Turbo Ring Dip Switch Settings
Bypass Mode DIP Switch Settings The IEX-408E-2VDSL2 provides a 3-pin-DIP-switch which is located on the front panel for DSL bypass mode configurations. Please open the metal door first in order to adjust the mode and make sure you tighten the screw on the front of the door every time you complete the settings. Refer to below instructions on how to set the DSL bypass mode. - Page 15 There is a 4-pin-DIP-switch for Turbo Ring on the top panel of the IEX-408E-2VDSL2 that can help setup the Turbo Ring easily within seconds. If you do not want to use a hardware DIP switch to setup the Turbo Ring, you can use a web browser, telnet, or console to disable this function.
- Page 16 “Turbo Ring V2” DIP Switch Settings DIP 1 DIP 2 DIP 3 DIP 4 ON: Enables the ON: Enables this ON: Enables the ON: Activates default “Ring IEX model as the default “Ring DIP switch 1, 2, Coupling Ring Master. Coupling”...
-
Page 17: Led Indicators
LED Indicators Color State Description Per Device LED PWR 1 Amber Solid light Power is being supplied to the main system’s power input PWR1 Light off Power is not being supplied to the main system’s power input PWR1 PWR 2 Amber Solid light Power is being supplied to the main system’s power input PWR2 Light off... - Page 18 Color State Description Per Device LED CPLR/ Green Solid light 1. The switch’s coupling function is TAIL enabled to form a back-up path. 2. When it’s set as the Tail of the Turbo Chain. 3. POST S.W. Fail (+Stat on and Fault blinking) Blinking 1.
-
Page 19: Specifications
Specifications Technology Standards IEEE 802.3 for 10BaseT IEEE 802.3u for 100BaseT(X) and 100BaseFX IEEE 802.3ab for 1000BaseT(X) IEEE 802.3z for 1000BaseX IEEE 802.3x for Flow Control IEEE 802.1D-2004 for Spanning Tree Protocols IEEE 802.1w for Rapid STP IEEE 802.1Q for VLAN Tagging IEEE 802.1p for Class of Service IEEE 802.1X for Authentication IEEE 802.3ad for Port Trunk with LACP... - Page 20 Power Input Voltage LV Models: 12/24/48 VDC (9.6 to 60 VDC) and -48 VDC, isolated power and redundant dual inputs HV Models: 110/220 VDC/VAC (88 to 300 VDC, 85 to 264 VAC), isolated power Input Current Max. 1A @ 12 VDC Max.
