- Page 1 Quad Screen Splitter LCD Console Drawer KVM-2404QSS User’s Manual Rev 0.3...
-
Page 2: Table Of Contents
Table of Contents Introduction ............................... 3 Package Contents ........................... 3 Features ..............................4 Equipment Requirement ........................5 Product Description ..........................6 Installation .............................. 10 Operation ..............................11 7.1 Front Panel ............................11 7.2 Hotkey Description ......................... 13 7.3 Mouse Operation ..........................14 Troubleshooting ............................. -
Page 3: Introduction
1. Introduction The Quad Screen Splitter ( QSS ) LCD console drawers represents the latest technology in KVM switching. The key advantage over conventional KVM switches is that it allows you to simultaneously display and administer 4 computers on a single console. It combines KVM features and a digital multi-viewer scaling and converting videos at both inputs and output. -
Page 4: Features
3. Features • 1U single rail with 24” LCD Monitor, • Support FHD with 1080p resolution. • Four independent DVI-D/USB/Audio/HUB interface for each PC. • Support Full screen and Quad screen mode • On Quad Screen mode, by Mouse moving across screen boundary or via Push Button or Hotkey to switching port •... -
Page 5: Equipment Requirement
4. Equipment Requirement Computers Video: DVI-D Audio: 3.5mm audio-output USB: USB type A Win XP / Win 7 (32/64-bit) / Win 8 (32/64 bit) Cables DVI-D single-link cable(s) Audio Cable(s) USB cable(s) -
Page 6: Product Description
5. Product Description Front Panel Port LED Indicator 1 ~ 4 Port Select Button 1 ~ 4 When the specific port button is pressed, or the mouse When the specific port button is pressed, the mouse moves to certain port, the LED of the acting port would pointer would be moved to the center of the port Button be lighted. - Page 7 Rear Panel Description (Console) Audio Output Compatible to a stereo ear-phone or speaker. (Console) USB HUB ports Please make sure the USB-accessing has been finished before port-switching to prevent the potential loss or damage of the files in USB-storage devices. In quad-screen-mode, the mouse from here would not make the port-switching ! (Host side) Audio port Connect with the 3.5mm phone-jack plug from the PC’s audio output.
- Page 8 Technical Specification Direct no. of Video 4x DVI-I (DVI-D signal) Computers 4x USB (type-B) 4x phone-jack（3.5 mm） Audio Max no of PC’s 23.6” Size Backlight Resolution 1920 * 1080 Full HD Max. color 16.7M Luminance 250cd/m View angel (H/V) 178 / 178 Contrast Ratio 3000 : 1 Port Select...
- Page 9 Note 1.The Video Resolution The QSS KVM would read the EDID information of the monitor，then automatically setting the output resolution according to below table. Priority Resolution/VSYNC freq. Comments 1 (High) 1920x1200 RB / 60Hz RB: Reduced Blanking 1920x1080p / 60Hz * 1920x1080p / 50Hz * 1920x1080i / 60Hz * 1920x1080i / 50Hz *...
-
Page 10: Installation
6. Installation Step 1 – Power-On LCD Drawer Warning: Before attempting to connect anything to the Switch, or your computers, please ensure that all computer equipment and devices are powered off. Power-ON LCD Drawer, it would have a short beep-sound ... -
Page 11: Operation
7. Operation 7.1 Front Panel Initial state (LED 1 ON, Full-Screen-Mode LED ON) Press ”button 2”, switch to PC2 Likely, press ”button 3”, switch to PC3... - Page 12 As press “Quad-mode” button, it would be in Quad-display mode, the mouse keeps at PC3. Press “button 2”, the mouse would be switched to PC2. When the full-screen mode button is pressed, it turns to Full-screen mode, the mouse keeps at PC2.
-
Page 13: Hotkey Description
7.2 Hotkey Description Hotkey Beep Description CTRL, CTRL, 1 1-short beep Switch to PC1 CTRL, CTRL, 2 1-short beep Switch to PC2 CTRL, CTRL, 3 1-short beep Switch to PC3 CTRL, CTRL, 4 1-short beep Switch to PC4 CTRL,CTRL, l 1-short beep Full Screen Mode Display Or CTRL,CTRL, L... -
Page 14: Mouse Operation
7.3 Mouse Operation In Quad-Split-Screen mode (as below figure) mouse moves across PC1-PC2 boundary, the mouse would switch from PC1 to PC2; keyboard is switched as well. -
Page 15: Troubleshooting
8. Troubleshooting No LED lights • Check that the power supply or power cable is properly connected to the mains socket. • Check that DC plug is fully inserted into the switch DC jack • Check that the device is powered by using optical mouse with visible red light. If power is not available, change the power supply.
