Product Features; Printer Standard Features - Printronix T600 Administrator's Manual

1.2 Product Features

1.2.1 Printer Standard Features

The printer offers the following standard features.
Product standard feature
Thermal transfer/ or direct thermal
6 operating buttons and 1 LED with 3 colors
2.3" color TFT display, 320 x 240 pixel (UI of operating menu)
32-bit RISC high performance processor (Atmel 9G25/ 400 MHz)
Center alignment holder with spiral spring
Gap transmissive sensor (Fixed, center of offset 4 from center)
Black mark reflective sensor (Position adjustable)
Ribbon encoder sensor
Head open sensor
Automatic media/ribbon sensor selecting
128 MB Flash memory
64 MB DDR2 DRAM
SD card reader for memory expansion, up to 32 GB
RS-232 interface (Max. 115,200 bps)
USB 2.0 interface (Hi speed mode)
Internal Ethernet print server (10/100 Mbps) interface
USB host
Standard industry emulations right out of the box including Eltron
language support
Internal 8 alpha-numeric bitmap fonts
Fonts and bar codes can be printed in any one of the four directions (0,
90,180, 270 degree)
Internal Monotype Imaging
Bold Condensed scalable font
Downloadable fonts from PC to printer memory
Bar code, graphics/image printing
Supported bar code
1D bar code
Code128 subsets
A.B.C, Code128UCC,
EAN128, Interleave 2
of 5, Code 39, Code
93, EAN-13, EAN-8,
Codabar, POSTNET,
UPC-A, UPC-E, EAN
and UPC 2(5) digits,
MSI, PLESSEY,
China Post, ITF14,
EAN14, Code 11,
TELPEN, PLANET,
Code 49, Deutsche
Post Identcode,
Deutsche Post
Leitcode, LOGMARS
®
true type font engine with one CG Triumvirate
Supported
2D bar code BITMAP,
BMP, PCX
CODABLOCK F
(Max. 256
mode,
colors
DataMatrix,
graphics)
Maxicode, PDF-
417, Aztec,
MicroPDF417,
QR code, RSS
Barcode (GS1
Databar)
- 2
® ®
and Zebra
P180043-001_A
