14 Get to know your PIN Pad
Operating your
Integrated PIN Pad —
samples of transaction flows
The rinciple of the integrated PIN Pad is that all EFT transactions are instigated from your POS solution to
prevent the need for double keying. The PIN Pad is in essence a "slave" to your POS serving the purpose
of enabling the customer's PIN to be entered and to build a secure EFT transaction for processing.

Purchase transaction

In this sample transaction flow, all transaction data is collected at the ECR/POS, and sent down to the terminal
in the PC-EFTPOS Transaction command.
01 02
Step Step
Alternatively, if 'Purchase' is not a configured hot
Select 'Purchase' from the main screen. If it is
key, select 'Transaction', then select 'Purchase'
configured as a hot key. (Refer to page 76 for details.)
from the transaction list.
03 04
Step Step
$0.00
$0.00
Key in the purchase amount and press the green
Key in the cash out amount if required.
ENTER key on the keypad.
