11 Get to know your PIN Pad

How to configure the PIN Pad

The default comms mode when first powering on the PIN Pad will be pre-set at the factory according to
the cable already connected to the PIN Pad:
First PIN Pad screen
1-WIFI (restart needed)
2-SERIAL (POS integration)
3- PSTN
4- DIAL: PREFIX
5- BLIND DIAL
ENTER-CONTINUE
Press ENTER to continue.
The PIN Pad will perform a software download and go the idle screen when the download is completed.
CONFIGURE
Second PIN Pad screen
ENTER
CENTRiQ is the First Data supported Terminal
Management System (TMS).
Enter the CENTRiQ ID to connect to the
TMS. The CENTRiQ ID will be provided to
you by First Data.
Enter the CENTRiQ ID using the
PIN pad's keypad then press the green
enter key.
CENTRiQ ID
