FD150
Quick Reference Guide
Thank you for Choosing a First Data™ Terminal
First Data terminals are some of the fastest, most secure point-of-sale terminals available. Installation is quick
and easy. Simply follow the instructions and begin accepting card transactions today.
What's in the box?
- FD150 Terminal
- Privacy Shield
- Power Cable
- AC/DC power
(1m)
1. Connect the Cables
J If present, remove the plastic cover over the
ports at the back of the terminal before proceeding.
J Insert the power cable into the power supply port
on the left hand side of the terminal.
J Insert the IP cable into the Ethernet port
J Insert the PSTN dial cable into the phone line port
- IP Cable
- Paper rolls (x2)
adapter block
- PSTN Dial Cable
- Quick Reference
Guide
2. Install the Print roll
J Open the paper cover by lifting
the black paper latch on the
top of the FD130 terminal.
J Drop the paper roll into the
paper tray. The thermal
print side of the paper will
feed out facing you.
J Close the cover of the
FD130 terminal until you hear
a click, then tear off any
excess paper.
J You are now ready to start using your new terminal.
See over for more detail.
Contact information
First Data Merchant
877-828-0720
Solutions Helpdesk
- BT Splitter
