10 Get to know your PIN Pad
If you intend to configure any other POS (which does not host the Gateway connection)
for connection via one of the above options to access the gateway
Run PC-EFTPOS Setup.exe
Select No PIN Pad and Server
In Client select a Comms Port for PIN Pad
At Comms to Bank select another PC on the Network
At Server Config enter IP Address of PC-EFTPOS Gateway PC
When Setup complete check line status in EFT Server reflects 'Connected'
When Setup complete check that the line status in EFT Server reflects 'Connected'
Connect a PIN Pad
In Client confirm that the correct COM Port is assigned
Configure the PIN pad by entering the CENTRiQ ID (if unknown please contact the helpdesk on 1800
243 444) by keying in the 5 digit ID and press Enter.
A software download will occur and will be complete when the PIN Pad displays
'Transaction / Admin'
Open PC-EFTPOS Client / Control Panel / Logon – PIN Pad and Logon will occur
All chip cards must be inserted into the chip card reader as shown below.
>
You must contact your POS provider to configure the POS Software for Integrated EFTPOS and to set up
receipt printing.
>
If your POS Solution does not have the latest PC-EFTPOS software installed, install the software from the
PC-EFTPOS installation CD or the setup file available for download from the website.
http://www.pceftpos.com/media/PC-EFTPOS%20Setup.exe
