Chapter 1: Product Introduction

Knowing Your NISE 90

Front Panel

CAN bus

COM 3

USB2.0 Ports

Triple USB2.0 ports to connect the system with USB2.0/1.1 devices.

CAN Bus and COM1 RS232/RS422/RS485

DB-9 CAN bus connector and serial port used to connect RS232/422/485

USB 2.0

compatible serial devices.

LAN

COM3 and COM2

Serial ports used to connect RS232 compatible devices.

COM 1

LED Indicators

Two LEDs for HDD access and power status of the system. Two LEDs

indicators for COM port TX and RX signals, two programmable GPIO LEDs

and a LED for battery power, replace battery when this LED is active.

COM 2
