This equipment must be installed and serviced by a qualified technician.
!
WARNING
Improper installation can create electrical hazards which could result in property
damage, serious injury or death. Improper installation will void the warranty.
Notice to Installer
This manual contains important information about the installation, operation
and safe use of this product. Once the product has been installed this manual
must be given to the owner / operator of this equipment.
70XL
www.waterco.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Waterco MultiCyclone 70XL
Summary of Contents for Waterco MultiCyclone 70XL
- Page 1 Improper installation will void the warranty. Notice to Installer This manual contains important information about the installation, operation and safe use of this product. Once the product has been installed this manual must be given to the owner / operator of this equipment. www.waterco.com...
-
Page 2: Safety Information
DIMENSIONS ------------------------------------------------------ 04 EXPLODED DIAGRAM -------------------------------------------- 05 SAFETY INFORMATION 1. MultiCyclone 70XL is designed to work with water at temperatures greater than 0º C and less than 45ºC. The filter should never be operated outside of these temperatures or damage may occur. - Page 3 INTRODUCTION MultiCyclone 70XL is capable of saving water and reducing filter maintenance. The MultiCyclone 70XL works on the basis of centrifugal water filtration. There are no moving parts to wear and tear, and no filter media to clean or replace.
-
Page 4: Installation
MultiCyclone 70XL is ideal as a pre-filter to extend the life of your existing filter. • Save Water • Reduce backwash frequency. Please Note: the Multicyclone 70Xl is designed to filter sediment that is heavier than water; floating debris cannot be filtered out by centrifugal filtration. INSTALLATION Be sure to comply with the local plumbing codes. -
Page 5: Turn On Pump
For more information please refer to the Waterco “Warranty Terms & Conditions” booklet. With our on going commitment to quality products and service Waterco Limited reserves the right to alter the product in any manner and at any time without prior warning. -
Page 6: Technical Specification
TECHNICAL SPECIFICATION Pressure Rating: 250 kPa / 2.5 bar /36 psi Minimum Flow Rate: 36m3/hr (158.5 GPM) Maximum Flow Rate: 108 m3/hr (475.6 GPM) MultiCyclone 70XL Total Head Loss Curve 8.00 7.00 6.00 5.00 4.00 3.00 2.00 1.00 0.00 0.00 20.00... -
Page 7: Exploded Diagram
Waterco Multicyclone 70Xl I pg 05 EXPLODED DIAGRAM DESCRIPTION Nut M6 (Not Shown) Rubber Washer (Not Shown) O Ring BS 112 Air Relief Valve Bolt M10 Bolt M6 Washer M6 O Ring BS 009 O Ring BS 018 O Ring BS 025... - Page 8 Tel: +61 8 8244 6000 Tel: +1 450 748 1421 Tel: +65 6344 2378 acT diSTriBuTiON WaTercO (NZ) LiMiTed Tel: +61 2 6280 6476 auckland, New Zealand Tel: +64 9 525 7570 Waterco Limited ABN 62 002 070 733 (W99302 / ZZM1449) 07/2013...
