Amplifier Instructions - SBoostMcover1 cover1
Amplifier Instructions - SBoostMcover1 cover1
Amplifier
Amplifier
Installation
stallatio
stallat
Guide
Contents:
Guarantee and Warranty · · · · · · · · · · · · · · · · · · · · · · · ·
How it Works · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 2
Before Getting Started · · · · · · · · · · · · · · · · · · · · · · · · · · 3
Installing a Wilson Outside Antenna · · · · · · · · · · · · · · ·
Installing a Wilson Inside Antenna (Wireless) · · · · · · · · 6
Optional Cell Phone Cradle Plus · · · · · · · · · · · · · · · · · ·
Understanding the Amplifi er Lights · · · · · · · · · · · · · · · · 8
Warnings and Recommendations · · · · · · · · · · · · · · · · · 9
About Wilson Electronics · · · · · · · · · · · · · · · · · · · · · · · · 10
Amplifi er Specifi cations · · · · · · · · · · · · · · · · · · Back Cover
SIGNALBOOST
MINI-AMP
Dual-Band Wireless
Cellular / PCS
Amplifi er
!
Warning: This manual contains
important safety and operating information.
Please read and follow the instructions
in this manual. Failure to do so could be
hazardous and result in damage to your
amplifi er.
Wilson
TM
1
4
7
®
Electronics, Inc.
4/2/2008 9:16:35 AM
4/2/2008 9:16:35 AM
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Wilson Electronics SIGNALBOOST MINI-AMP
Summary of Contents for Wilson Electronics SIGNALBOOST MINI-AMP
-
Page 1: Table Of Contents
Warnings and Recommendations · · · · · · · · · · · · · · · · · 9 About Wilson Electronics · · · · · · · · · · · · · · · · · · · · · · · · 10 Amplifi... - Page 2 Returned Material Authorization (RMA) number supplied by Wilson Electronics. Wilson shall, at its option, either repair or replace the product. Wilson Electronics will pay for delivery of the repaired or replaced product back to the original consumer.
-
Page 3: How It Works
Wilson Electronics manufactures a wide variety of antennas to help you customize your amplifi er for your specifi c application. Several are shown below. See your dealer or visit www.wilsonelectronics.com. -
Page 4: Before Getting Started
Before Getting Started This guide will help you properly install Wilson’s SIGNALBOOST Mini-Amp Dual-Band Wireless Cellular/PCS Amplifi er. It is important to read through all of the installation steps for your particular application prior to installing any equipment. Read through the instructions, visualize where all the equipment will need to be installed and do a soft installation before mounting any equipment. -
Page 5: Installing A Wilson Outside Antenna
Installing a Wilson Outside Antenna To receive the best cell signal, select a location in the center of the vehicle’s roof 12 inches away from any other antennas and free of obstructions. Follow the specifi c antenna installation instructions included with the outside antenna (sold separately). - Page 6 Installing a Wilson Amplifi er Warning: Do not plug in the DC power supply until the outside and inside antenna cables are attached to the amplifi er. Select a location to install the amplifi er that is away from excessive heat, direct sunlight or moisture and that has proper ventilation.
-
Page 7: Installing A Wilson Inside Antenna (Wireless)
Wireless Installing a Wilson Inside Antenna Install the Ultra-slim inside antenna 8-12 inches from where the cell phone is located or directly on the cellular data card or laptop. Amplifi er Ultra-slim Antenna Warning: Do not install the Ultra-slim antenna within four inches of metal. (Metal found inside the vehicle’s seat will not affect the antenna’s performance.) Place the inside antenna on the side of the... -
Page 8: Attaching A Wilson Inside Antenna (Laptop/Data Card)
Laptop or Data Card Attaching a Wilson Ultra-slim Inside Antenna to a Laptop or a Cellular Data Card Amplifi er Ultra-slim Antenna The Ultra-slim antenna must be placed on or near the cellular data card to work properly. Attach the Ultra-slim antenna to the laptop or cellular data card with the VELCRO ®... -
Page 9: Understanding The Amplifi Er Lights
Powering up a Wilson Amplifi er Make sure both the outside and inside antenna cables are connected before powering up the amplifi er. Connect the power cable from the DC plug-in power supply to the amplifi er and insert the large end into DC power socket (the cigarette lighter outlet.) Warning: Use only the power supply provided in this package. -
Page 10: Warnings And Recommendations
Warnings and Recommendations Warning: In a wireless installation, do not plug the amplifi er directly into the cell phone or cellular data card using an antenna adapter. It will damage the cell phone or cellular data card. Warning: Do not plug in the DC power supply until the outside and inside antenna cables are attached to the amplifi... -
Page 11: About Wilson Electronics
About Wilson Electronics Wilson Electronics, Inc. has been a leader in the wireless communications industry for nearly 40 years. The company designs and manufactures amplifi ers, antennas and related components that signifi cantly improve cellular telephone signal reception and transmission in a wide variety of applications, both mobile and in-building. -
Page 12: Amplifi Er Specifi Cations
Amplifi er Specifi cations Dual Band 800/1900 MHz Specifi cations Model Number / Part Number 271230/801230 Connectors SMA Female Impedance (input/output) 50 ohms Dimensions 3.8 X 3.2 X 1.5 inch or 9.6 X 8.1 X 3.8 cm Weight 4 oz or 0.11 kg Frequency 824-894 MHz / 1850-1990 MHz Passband Gain (nominal)
