OPERATION

IMPORTANT SAFETY INSTRUCTIONS
To reduce the risk of SEVERE INJURY or DEATH:
1. READ AND FOLLOW ALL WARNINGS AND
INSTRUCTIONS.
2. ALWAYS keep remote controls out of reach of
children. NEVER permit children to operate or play
with door control push buttons or remote controls.
3. ONLY activate door when it can be seen clearly, it is
properly adjusted, and there are no obstructions to
door travel.
4. ALWAYS keep door in sight and away from people
and objects until completely closed. NO ONE
SHOULD CROSS THE PATH OF THE MOVING DOOR.
5. NO ONE SHOULD GO UNDER A STOPPED,
PARTIALLY OPEN DOOR.
6. If possible, use emergency release handle to
disengage trolley ONLY when door is CLOSED. Use
caution when using this release with the door open.
Weak or broken springs or unbalanced door could
result in an open door falling rapidly and/or
unexpectedly and increasing the risk of SEVERE
INJURY or DEATH.
7. NEVER use emergency release handle unless
doorway is clear of persons and obstructions.
8. NEVER use handle to pull door open or closed. If
rope knot becomes untied, you could fall.
9. If one control (force or travel limits) is adjusted, the
other control may also need adjustment.

Using Your Door Operator

Your operator will operate with up to eight Security+
controls and one Security+
Activate your operator with any of the following:
• The Hand-Held Remote Control: Hold the large push button
down until the door starts to move.
• The Wall-Mounted Door Control: Hold the push button or
bar down until the door starts to move.
• The Keyless Entry (See Accessories): If provided with your
door operator, it must be programmed before use. See
Programming.
When the operator is activated (with the safety reversing
sensor correctly installed and aligned)
1. If open, the door will close. If closed, it will open.
2. If closing, the door will reverse.
3. If opening, the door will stop.
4. If the door has been stopped in a partially open position, it
will close.
5. If obstructed while closing, the door will reverse. If the
obstruction interrupts the sensor beam, the operator lights
will blink for fi ve seconds.
®
Keyless Entry System.
WARNING WARNING
10. After ANY adjustments are made, the safety reversal
system MUST be tested.
11. Safety reversal system MUST be tested every month.
Door MUST reverse on contact with 1-1/2" high (3.8
cm) object (or a 2x4 laid flat) on the floor. Failure to
adjust the door operator properly increases the risk
of SEVERE INJURY or DEATH.
12. ALWAYS KEEP DOOR PROPERLY BALANCED (see
page 3). An improperly balanced door may NOT
reverse when required and could result in SEVERE
INJURY or DEATH.
13. ALL repairs to cables, spring assemblies and other
hardware, ALL of which are under EXTREME tension,
MUST be made by a trained door systems
technician.
14. ALWAYS disconnect electric power to door operator
BEFORE making ANY repairs or removing covers.
SAVE THESE
15.
INSTRUCTIONS.
6. If obstructed while opening, the door will stop.
7. If fully open, the door will not close when the beam is
®
remote
broken. The sensor has no effect in the opening cycle.
If the sensor is not installed, or is misaligned, the door won't
close from a hand-held remote. However, you can close the
door with the Door Control, the Outside Keylock, or Keyless
Entry, if you activate them until down travel is complete. If you
release them too soon, the door will reverse.
The operator lights will turn on under the following
conditions: when the operator is initially plugged in; when
power is restored after interruption; when the operator is
activated.
They will turn off automatically after 4-1/2 minutes. Bulb size
is 75 watts maximum.
®
Security +
someone walks through the open door.
Do not exceed 8 complete cycles of door operation per hour
in commercial applications.
24
light feature: Lights will also turn on when
