17. Orient the Rear Console Cover (80) as shown
and attach it to the Upright (4) with two
M4 x 16mm Screws (101).
Next, orient the Front Console Cover (79) as
shown and attach it to the Rear Console Cover
(80) with two M4 x 16mm Screws (101).
18. Attach the Tablet Holder (9) to the Console (7)
with four M4 x 16mm Machine Screws (111);
start all the Machine Screws, and then tighten
them.
19. Make sure that all parts are properly tightened before you use the elliptical. Extra parts may be included.
Place a mat beneath the elliptical to protect the floor.
17
80
18
17
101
79
101
101
4
9
7
111
