• If necessary, adjust the set screw on the rear of the instru-
ment with a screwdriver to correct the setting.
Battery check
➭
Set the range switch to the „Ω x 1" position.
➭
Short-circuit connecting sockets „⊥" and „Ω" using a mea-
suring lead.
➭ Set the pointer to full deflection position 0 Ω using potenti-
ometer knob.
If it is no longer possible to set the full deflection or if the reading
does not remain constant after setting, the mignon cell is spent
or the pigtail fuse is defective.

4.3 Voltage Measurement

!
Attention!
Regardless of the value of the measured voltage, as a
safety precaution, do not exceed the sum of 500 V
CAT II for measured voltage plus voltage against earth
when directly connecting up the multimeter!
The left-hand connection socket marked „⊥" should be con-
nected whenever possible and for all voltage measurements to
the point with the lowest potential against earth.
