3-1-4. Connecting the Equipments
Connecting the measuring instruments as shown in Fig. 5-3-2 and
perform the adjustments.
Connecting the TV Monitor and Regulated Power Supply
Battery terminal
Regulated power supply
+ _
8.4 0.1Vdc
Main Unit
VIDEO
VIDEO terminal
Fig. 5-3-2.
5-37
TV monitor
Connect when using the camera
mode or playing back.
