Proprietary Information

4#0#,QWURGXFWLRQ

Table of Contents

1.1 Proprietary Information . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.2 Revision Log. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.3 About This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Service Manual Section Descriptions . . . . . . . . . . . . . 3
Section 1: Introduction & General Data . . . . . . . . . . . . 3
Section 2: Troubleshooting . . . . . . . . . . . . . . . . . . . . . . 3
Section 3: Parts Lists . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Section 4: Removal & Replacement . . . . . . . . . . . . . . . 3
Section 5: Verification Procedures . . . . . . . . . . . . . . . . 3
Section 6: Preventive Maintenance & Total Call. . . . . . 3
1.4 CELL-DYN 3200 Operator's Manual . . . . . . . . . . . . . . 3
1.5 Warranty Information. . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.6 System Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
The CELL-DYN 3200 Hematology System . . . . . . . . . . 4
System External Components . . . . . . . . . . . . . . . . . . . 4
System Internal Components . . . . . . . . . . . . . . . . . . . . 5
1.7 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Signal Words and Graphic Warning Conventions . . . 5
Signal Words . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Graphic Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Biosafety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Electrical Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Laser Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.8 CELL-DYN 3200 Hematology Parameters . . . . . . . . . . 9
1.9 System Specifications . . . . . . . . . . . . . . . . . . . . . . . . . 10
CELL-DYN® 3200 SYSTEM SERVICE MANUAL
1.1 Proprietary Information
This CELL- DYN 3200 System Service Manual was developed
solely for use with Abbott Laboratories equipment as specified
in the operating instructions. The Manual is copyrighted by
Abbott Laboratories. No part of this document may be
reproduced, stored, or transmitted in any form or by any means
electronic, mechanical, photocopied, recorded, or otherwise
without the prior written permission of Abbott Laboratories.
This CELL- DYN 3200 System Service Manual is published by
Abbott Diagnostics, a Division of Abbott Laboratories, Abbott
Park, IL 60064-3500, U. S. A. Please direct all inquiries
concerning information in this manual to the foregoing address.
®
CELL- DYN is a registered trademark of Abbott Laboratories.
®
Vacutainer is a registered trademark of Becton-Dickinson and
Company.
This service manual was developed to be used by trained
Abbott Laboratories Field Service Personnel. The revision
status of this manual is the responsibility of the manual holder.
In no event shall Abbott Laboratories or its subsidiaries be
liable for any damages incurred in connection with or arising
from the use of this manual by persons not fully trained by
Abbott Laboratories.
©
1998 by Abbott Laboratories. All rights reserved.
−
Part Number 9140300 August 1998
1 - 1
