CELL-DYN 3200 Service Manual page 172

6#0#3DUWV#/LVWV •#
PL-13 Central Processing Unit/Device Control Module (2 of 2)
PL-13 Central Processing Unit/Device Control Module (2 of 2)
Item Part #
1 8960182001
2 8952084901
3 8952086401
4 8952084701
5 8952084601
6 8952089301
7 8952089201
8 8952084101
9 8952050001
10 8952086501
11 8952085001
12 8952050601
13 8952085201
14 8952050501
15 8952085101
®
CELL-DYN 3200 SYSTEM SERVICE MANUAL
Description
Bd, CPU/DCM
Cable, Serial Periph Bus
Cable, HSSL (Internal)
Cable, CPU-J6 to MPM-J1
Cable, External CPU Bus
Cable, CPU-J17 to SHM2-J16
Cable, CPU-J1 to SHM1-J16
Cable, MUX DAC CTRL Bus
Cable, CPU-J3 to SPM-J4
Cable, PDM-J4 to MAM-J3
Cable, CPU-J12 to SPM-J7
Cable, MAM-J4 to CPU-J9
Cable, CPU-J7 to FCM-J25
Cable, CPU-J10 to SPM-J5
Cable, CPU-J8 to FCM-J22
–
Part Number 9140300 August 1998
3 - 41
