Figure 2C-5 Sample Aspiration Flow Diagram
SAMPLE
SENSOR 2
MOTOR-X
BLOOD
SAMPLE
VALVE
PS5
SENSOR
CELL-DYN® 3200 SYSTEM SERVICE MANUAL
Figure 2C-5 Sample Aspiration Flow
WBC
20 uL
HGB
12 uL
RBC
1.67 uL
ULTRASONIC
SENSOR
12
Y-VALVE
TO AIR
47,48
OPEN
SAMPLE
PROBE
38
MOTOR-E
VENT
TRAP
CLOSED
MODE
VAC 2 (BRN)
ACC 5
VAC 2
(VAR.)
2 WAY PINCH VALVE NORMALLY OPEN
2 WAY PINCH VALVE NORMALLY CLOSED
AIR FLOW RESTRICTOR
CHECK VALVE. ARROW SHOWS
DIRECTION OF FLOW
VAC 2 (BRN)
Part Number 9140300
TRAP
17
WC-2
32064
OPEN MODE SAMPLE
CLOSED MODE SAMPLE
OPEN/CLOSED MODE SAMPLE
VACUUM #2
−
August 1998
2C - 6
