CELL-DYN 3200 Service Manual page 138

6#0#3DUWV#/LVWV •
Alphabetical Parts List Cross Reference
Description
Cable, SVDM-J2 to FCM-J8
Cable, Vac1 Wet Sensor
Cable, Vac2 Wet Sensor
Cable, VPM-J13 to FCM-J23
Cable, VPM-J14 to FCM-J24
Cable, VPM-J18 to PRM-J1
Cable, VPM-J6 to CDM2-J4
Cable, Waste Full Sensor
Cable, Y-Valve Sensor
Calibrator, CELL-DYN 3000
Cap Assy, Diluent/Sheath
Cap Assy, HGB/NOC Lyse
Cap Assy, WBC, Lyse
Cbl, SDM/CDM-J1 to SDM1-J10
Cbl, SDM/CDM-J2 to SDM2-J10
Chamber, Mixing, RBC/WBC
Clamp, Tubing 1/4 O.D.
Computer Assy, CD3200
Connector, Ser Loopback
Cord, Power 125Vac 10A
Cover, Front Nose Section
Cover, Keyboard
Cover, Left Front Door
Cover, Left Side
Cover, Right Front Door
CELL-DYN® 3200 SYSTEM SERVICE MANUAL
List #
PL-9
PL-5
PL-5
PL-5
PL-5
PL-5
PL-5
PL-3
PL-8 PL-9
Rea/Sup
PL-3
PL-3
PL-3
PL-15
PL-15
PL-4
TM
PL-17
Rea/Sup
PL-1
PL-19
PL-17
PL-19
PL-19
PL-19
Part Number 9140300
Description
Cover, Right Side
Cover, SL Bottom
Cover, SL Left Side Front
Cover, SL Right Side Front
Cover, SL Top Skirt
Cover, Top
Cylinder, Air, Mixer Lift
Cylinder, Air, X & Y Index
Disk Drive, Floppy, 1.44MB
Disk Drive, Hard, 540MB
Disk, Service
Disk, Setup
Disks, Installation (1 & 2)
Driver Assy, Y-Valve, Complete
Enzymatic Cleaner
Fan Guards & Filter, 3 Pcs
Fan, 115VAC, 4.69" SQ
Filter, 5 Micron, In-line
Filter, In-line, Sheath
Filter, Pressure Pump
Filter, Vent Accumulator
Fitting, Luer Lock
Fitting, Reagent Inlet
Fitting, Waste Outlet
Fixture, Voltage Divider
–
August 1998
List #
PL-19
PL-19
PL-19
PL-19
PL-19
PL-19
PL-18
PL-18
PL-17
PL-17
Rea/Sup
Rea/Sup
Rea/Sup
PL-8
Rea/Sup
PL-3
PL-3
TM
PL-4
PL-5
PL-4
PL-7
PL-3
PL-3
Rea/Sup
3 - 7
