Parker IQAN-XA2 Instruction Book

Expansion controller
Hide thumbs
Table of Contents

Advertisement

Quick Links

IQAN-XA2
Instruction book
Publ no HY33-8385-IB/UK
Edition 2016-12-16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IQAN-XA2 and is the answer not in the manual?

Questions and answers

Related Manuals for Parker IQAN-XA2

Summary of Contents for Parker IQAN-XA2

  • Page 1 IQAN-XA2 Instruction book Publ no HY33-8385-IB/UK Edition 2016-12-16...

  • Page 2: Table Of Contents

    IQAN-XA2 Technical Overview ........

  • Page 3: Introduction

    Contact the manufacturer if there is anything you are not sure about or if you have any questions regarding the product and its handling or maintenance. The term "manufacturer" refers to Parker Hannifin Corporation. Instruction book, IQAN...

  • Page 4: Overview Of Relevant Documentation

    Overview of relevant documentation Introduction Overview of relevant documentation The following publications are relevant for users of this product. The main documentation contains information that is not found elsewhere. The additional documentation contains product information in a compact format, for details on the information found in those documents, consult this manual.

  • Page 5: Precautions

    Read This Precautions Precautions Work on the hydraulics control electronics may only be carried out by trained personnel who are well-acquainted with the control system, the machine and its safety regulations. ARNING Make sure that you have sufficient knowledge before designing, modifiying or servicing the control system.
  • Page 6 Read This Precautions Start-up, maintenance, and diagnostics For all personnel carrying out installation, commissioning, maintenance or troubleshooting. ARNING Work on the hydraulics control electronics may only be carried out by trained personnel who are well-acquainted with the control system, the machine and its safety regulations.

  • Page 7: Product Description

    PORT 2 Inputs The IQAN-XA2 module has eight (8) voltage inputs VIN-A thru VIN-H for connection of 0-5 Vdc signals. The inputs VIN-E thru VIN-H are multi-purpose and for flexibility may be configured in other ways. The two input pins VIN-E and VIN-G can be configured as frequency inputs for measuring frequency.
  • Page 8 IQAN-XA2 Product description Proportional outputs The XA2 module has six (6) double proportional outputs for controlling proportional valves. These outputs can control six bi-directional valve sections or six single solenoid devices (ie. proportional cartridge valves). The proportional outputs can be used in two different modes.

  • Page 9: Safety

    Internal diagnostics Safety Safety Internal diagnostics The module performs a number of self-checks that improve safety. Checks include monitoring of voltage supplies, checksums on memory and a watchdog that monitors software execution. The module is using a real time operating system which supervises software execution.

  • Page 10: Mounting

    Mounting the module Mounting Mounting Mounting the module The IQAN module should be mounted according to the following instructions: • Locate the module eliminating the risk for the cabling to be folded, crushed or dam- aged in any way. Ensure the cabling cannot pull, twist or induce sideload on the con- nector.

  • Page 11: Installation

    Installation Installation Connector C1 Connector kit Parker no. 5031063 Housing Amp no. 1-963226-1 Casing Amp no. 0-965643-1 *= The connector contains two types of terminals; Plane sealing, 42 p installed in module MT (Micro Timer) and JPT (Junior Power Timer).
  • Page 12 Installation Logical (I)nput or Function description Symbol (O)utput and/or Signal name(s) P0 is an 8 pin input port with alternate functions on four inputs. DFIN P0.0 VIN-A DIN-A P0.1 VIN-B DIN-B P0.2 VIN-C DIN-C P0.3 VIN-D DIN-D P0.4 VIN-E DIN-E DFIN-A+ FIN-A P0.5...

  • Page 13: Supply Voltage

    Supply voltage Supply voltage Before any installation of the IQAN system can take place, make sure the ignition lock is turned off and the battery is disconnected. Emergency stop Make sure an Emergency Stop disconnecting the power supply, is easily accessible at any time.

  • Page 14: Addressing/Terminating

    Addressing/terminating Addressing/terminating Addressing Each IQAN expansion module will have a specific address, enabling the master module to communicate with the modules through the CAN-bus. When operating, the system distinguishes between different modules by first verifying the module type and secondly, through the modules having unique addresses. EXAMPLE If having an expansion module with address 0, the system will denote this one as [module type]-A0, The letter "A"...

  • Page 15: Reference Voltage, Vref

    Reference voltage, VREF Reference voltage, VREF The IQAN module is internally equipped with a voltage regulator to generate the reference voltage VREF. The standard reference voltage will feed different kinds of sensors and potentiometers. IQAN module +VREF -VREF VREF positions. OTICE It is strongly recommended to use the module’s -VREF and +VREF to all sensors and potentiometers that are connected to the module inputs.

  • Page 16: Voltage Inputs

    Voltage inputs Voltage inputs Connecting sensors to the voltage inputs The sensor signal range must be 0-5 Vdc. To detect signal errors such as short circuits or interruptions the active signal range be within 0.5-4.5 Vdc. Error detection range Active signal range Error detection range Active signal range.
  • Page 17 Voltage inputs Connecting a 2-wire temperature sensor to voltage in When you connect a PTC (positive temperature coefficient) temperature sensor you may need to use a pull up resistor on the input signal. Please check the technical data for your specific temperature sensor. EXAMPLE Connect the negative terminal of the temperature sensor to -VREF, and the signal to VIN-X.
  • Page 18 Voltage inputs Connecting switches to the voltage inputs using +BAT It is recommended to connect system voltage +BAT to the input through a switch in order to reserve 5Vdc VREF for sensors and potentiometers. EXAMPLE Connect the positive and negative terminals of the switch to supply or the unit’s +BAT, and DIN-X, respectively.

  • Page 19: Digital Inputs

    Digital inputs Digital inputs DIN that share pins with VIN These digital inputs share pins with the module voltage inputs and have high impedance characteristics. The preceding switch examples apply to these inputs. DIN that share pins with CRET These digital inputs share pins with the return pins of the proportional output channels, e.g.
  • Page 20 Digital inputs 2 The switch supply could be connected through a high impedance resistor. EXAMPLE Connect the supply of the switch to +BAT through a high impedance resistor, and the signal to DIN-X , respectively. +BAT IQAN module Resistor DIN-X, (shares RET pin) Switch Connecting a switch to DIN-X and supply through a resistor.

  • Page 21: Frequency Inputs

    Frequency inputs Frequency inputs Connecting sensors to the frequency inputs Frequency inputs can operate in 2 modes. Speed which is frequency and position which is a pulse count. For the frequency ranges and trigger levels, see Appendix A. Simple frequency sensor The positive terminal of the frequency sensor is connected to the +VREF and the negative terminal to the -VREF respectively.

  • Page 22: Quadrature And Directional Frequency Inputs

    Quadrature and directional frequency inputs Quadrature and directional frequency inputs Connecting sensors to the inputs Quadrature sensors are phase dependent. These sensors have two 90 degree out of phase "square wave" type signals for direction indication, and frequency. Directional sensors are level dependent. These sensors have one "square wave" type signal for speed or position and one signal that is high or low to indicate the direction.

  • Page 23: Proportional Outputs

    Proportional outputs Proportional outputs The current /PWM outputs control proportional valves and devices. For the current range and loads, see Appendix A. Frequency To obtain the best performance from proportional valves the controller produces a current mode (closed loop) output signal or a PWM mode (open loop) output signal. The type of output is selectable in IQAN software.

  • Page 24: Connecting Loads To Proportional Pwmout Outputs

    PWMRET-X- Directional Valve Connecting a load to a proportional output. OTICE DO NOT install diodes across coils for PWMOUT mode for Parker Pulsar solenoids! OTICE DO install diodes across coils for PWMOUT mode on all other solenoids! If maximum load inductance is exceeded, or if PWM outputs are externally grounded, a clamping diode must be used.

  • Page 25: Digital Outputs

    Digital outputs Digital outputs The digital outputs control relays and on/off valves. For the maximum load per output see Appendix A. Connecting loads to digital outputs Connecting of loads to the digital outputs such as on/off valves is done by using the DOUT positions and the negative battery terminal as ground.

  • Page 26: Start-Up

    Start-up procedures Start-up Start-up Start-up procedures This chapter contains instructions for action to be taken in connection with the initial start. ARNING Risk of injury! If the control system is not fitted properly, the machine could move uncontrollably. The machine’s engine shall not be started before the control system is completely fitted and its signals are verified.

  • Page 27: System Diagnostics

    System Diagnostics System Diagnostics The yellow blinking LED on the top of the module indicates normal status. If there is an error detected, the IQAN module will indicate error status through the red blinking LED. This gives an immediate diagnosis as to the nature of the error that has occurred. Yellow/ red, status LED Green, power on The location of the LED indicators on the IQAN module.

  • Page 28: Iqan-Xa2 Technical Overview

    IQAN-XA2 Technical Overview Appendix A Appendix A IQAN-XA2 Technical Overview System Parameter Remark Temperature Operating temperature -40 to 70 °C Absolute maximum temperature -40 to 85 °C Storage temperature -40 to 100 °C Voltage supply 9-32 V Power on threshold 6.2 V...
  • Page 29 IQAN-XA2 Technical Overview Appendix A Sensor supply, VREF = -40 °C to +70 °C (unless otherwise specified) Parameter Remark Maximum load current 150 mA Protection overload, SCB, SCG Diagnostics over/under voltage Under/over voltage threshold ±250 mV from nominal value = -40 °C to +70 °C (unless otherwise specified)
  • Page 30 IQAN-XA2 Technical Overview Appendix A = -40 °C to +70 °C (unless otherwise specified) Parameter Remark PCNT (Pulse Count input) / DPCNT (Directional Pulse Count input) Number of PCNT / DPCNT 2 / 1 (configuration may reduce number) Frequency range...
  • Page 31 IQAN-XA2 Technical Overview Appendix A = -40 °C to +70 °C (unless otherwise specified) Parameter Remark Power driver, DOUT (on/off output) Number of DOUT Maximum load Power driver voltage drop typ. 0.30 V @ 1.5 A load Leakage current in OFF state DOUT-A to DOUT-F <100 uA...
  • Page 32 IQAN-XA2 Technical Overview Appendix A Frequency The table below shows the PWM frequency possibilities. Any frequency may be entered in your application and is translated according to this table. The bold values are the actual frequencies in Hz output by the module for proportional valve control.

  • Page 33: Error Codes, Messages And Actions

    Yellow/ red, status LED Green, power on The location of the LED indicators on the IQAN-XA2 module. ARNING Don’t use the machine if an error message or error code is activated. The following sections will present what measures to take for different error situations put into appropriate context.

  • Page 34: Dimensioning Of The Iqan Module

    Dimensioning of the IQAN module Appendix C Appendix C Dimensioning of the IQAN module Instruction book, IQAN...

  • Page 35: Failure Modes

    No CAN communication. All output turned off. CAN-L to CAN-H No CAN communication. All output turned off. CAN-termination failure, termina- No effect tion on CAN-termination failure, termina- Dependent on CAN size and number of CAN nodes. tion off Instruction book, IQAN-XA2...
  • Page 36 No effect on module, not detected Failure modes for DFIN Failure mode Effect DFIN Open No effect on module, not detected DFIN Short-circuit to +BAT No effect on module, not detected DFIN Short-circuit to -BAT No effect on module, not detected Instruction book, IQAN-XA2...
  • Page 37 CAN master and therefore delayed by maximum 2 bus cycles. If local error handling is enabled the output will turn off locally without delay. b.Turned off by integrated protection functions in IC. Instruction book, IQAN-XA2...
  • Page 38 Turning off outputs are controlled by CAN master and therefore delayed by maximum 2 bus cycles. If local error handling is enabled the output will turn off locally without delay. b. Turned off by integrated protection functions in IC. Instruction book, IQAN-XA2...
  • Page 39 For latest information visit our website www.iqan.com Information in this instructionbook is subject to change without notice Publ no HY33-8385-IB/UK Edition 2016-12-16 Parker Hannifin Parker Hannifin Mobile Hydraulic Systems Europe Electronic Controls Division SE-435 35 Mölnlycke 1651 N. Main Street...
