Altronix AL400ULX Installation Manual page 4

Power Supply Output Specifications:
Output VDC Switch Position
12VDC SW1 CLOSED
Stand-by Specifications (total current shown):
Output
12VDC / 40 AH Battery
24VDC / 12 AH Battery
24VDC / 40 AH Battery
Fig. 1
Fig. 1A
BAT FAIL
NC C NO NC C NO AC FAIL
Battery & AC Supervision
Circuit
(power limited)
Fig. 1B
24V - OPEN
12V - CLOSED
Output VDC
24VDC
4 hr. of Stand-by &
5 Minutes of Alarm
Stand-by = 4 amp
Alarm = 4 amp
Stand-by = 3 amp
Alarm = 3 amp
CAUTION: De-energize unit prior to servicing. For continued protection
against risk of electric shock and fire hazard replace fuse with the same type
and rating 3.5A, 250V. Replace fuse cover before energizing.
Do not expose to rain or moisture.
Door
Green
Wire
Strap Lead
(from
Enclosure
to Door)
115VAC
power mains
non-power
limited
Class 1
Battery 1
Keep power limited wiring separate from non-power limited.
Use minimum .25" spacing.
Switch Position
SW1 OPEN
24 hr. of Stand-by &
5 Minutes of Alarm
Stand-by = 1.0 amp
Alarm = 4 amp
Stand-by = 200mA
Alarm = 3.0 amp
Stand-by = 1.0 amp
Alarm = 3 amp
Fuse Cover
+ +
BAT --- --- DC
power limited
- 3 -
60 hr. of Stand-by &
5 Minutes of Alarm
Stand-by = 300mA
Alarm = 4 amp
Stand-by = 300mA
Alarm = 3 amp
Power
Distribution
Module(s)
Divider
Battery connection (non power limited)
Battery 2
