INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
These instructions are supplementary to the Installation and
Operating Instructions supplied with the replace and should be
kept together. Refer to the Installation and Operating Instructions for
proper gas supply, safety requirements and operating instructions
Visit www. townandcountryfi replaces.net for the most recent version of this manual
100117-12
TC42
COUNTRY HOME
BURNER KIT
INSTALLATION
INSTRUCTIONS
(NATURAL GAS ONLY)
PART# TC42.NG02DN
For TC42 Series D
Fireplaces
TC42_NG02DN
5056.426C8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TC42.NG02DN and is the answer not in the manual?

Questions and answers

Related Manuals for Town & Country Fireplaces TC42.NG02DN

Summary of Contents for Town & Country Fireplaces TC42.NG02DN

  • Page 1 TC42 COUNTRY HOME BURNER KIT INSTALLATION INSTRUCTIONS (NATURAL GAS ONLY) PART# TC42.NG02DN For TC42 Series D Fireplaces Visit www. townandcountryfi replaces.net for the most recent version of this manual 100117-12 TC42_NG02DN 5056.426C8...

  • Page 2: Contents Of Package

    Contents of Package • Ember material • 7 Piece log set • Log grate • Burner assembly (including pilot and manifold) • Hardware package (not shown) • Air deflector Figure 1: TC42 NG02 kit contents Burner Installation 1. Place the keyhole slots in the burner (Figure 2) over the two screws located in the rebox base (Figure 3). 2.
  • Page 3 4. Attach the manifold and pilot supply tubes to the bulk head tting and tighten (Figure 5). Ensure that all connections are gas tight. Figure 5: Gas and pilot supply tubes. 5. Feed the ignition and sensor wires through the bulkhead plate (Figure 6) to the inter- face.
  • Page 4 6. Attach the ignition and sensor Flame sensor wires to the module (Figure 7) wire (white) Ignition wire (red) Interface module 7. Reinstall the access panel to the valve control box. A panel set must now be installed. See Installation and Operating Instructions manual for details.

  • Page 5: Ember Material Placement

    9. Attach rear de ector to rear of grate using the two screws provided (Figure 9). Figure 9: Rear de ector. Ember Material Placement A large bag of ember material is shipped with the replace and needs to be installed to ensure optimum performance and ame appearance.

  • Page 6: Log Placement

    Log Placement Gas plumbing and vent con- nections should be completed before proceeding. The logs are fragile, and should be handled with care. Unpack and inspect log set. There should be a total of seven logs. Position the logs as indicated by the following pictures.
  • Page 7 Figure 13: 3rd log placement. Figure 14: 4th log placement. TC42_NG02DN_100117-12 5056.426C8...
  • Page 8 Figure 15: 5th log placement. Figure 16: 6th log placement. TC42_NG02DN_100117-12 5056.426C8...
  • Page 9 Note: Figure 17: 7th log placement. Improper placement of logs will cause sooting on internal parts and glass. The logs may need to be repositioned slightly to avoid excessive flame impingement. Figure 18: Completed log set placement. TC42_NG02DN_100117-12 5056.426C8...

  • Page 10: Burner Flame Adjustment

    Burner Flame Adjustment The air shutter on the burner tube controls the primary combustion air to the gas burner and is pre-set closed at the factory for natural gas fuel. Some adjustment may be necessary to obtain desired ame and to elimi- nate carbon deposits.

  • Page 11: Replacement Parts

    Replacement Parts (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. BURNER ASSEMBLY ......TC42.NG02CN2 MAIN SUPPLY TUBE ........5019.223 PILOT TUBE ..........5019.225 *2 7 PCS LOG SET ........... 5098.311 ORIFICE, NATURAL GAS (4.09mm) ... 5022.78-A *NOT SHOWN PILOT ASSEMBLY .......
  • Page 12 © 2017 Copyright Paci c Energy Fireplace Products LTD Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws. For technical support, please contact your retailer Web site: www.townandcountryfireplaces.net 2975 Allenby Rd., Duncan, BC V9L 6V8 Printed in Canada...
