7. Firmware update Windows and OS X

The current revision of the
Manhattan II DAC firmware is shown
in the MytekControl „General" tab.
• The firmware can be updated by using USB2 port and Mytek Control Panel application. It requires
already installed USB2 driver (PC only) and Mytek Contro Panel application. To download the
current firmware as well as drivers please visit mytekdigital.com
• It is recommended to turn off any powered speakers / power amps connected to the
Manhattan II DAC before proceeding with the firmware update.
Follow the steps below to update the firmware:
1. Download the latest firmware (*.mfb) file from mytekdigital.com
2. Click „Load firmware file" button and browse to the new firmware file then click „Open".
3. Press the „Update" button to confirm uploading the firmware file to device's memory.
4. Confirm your choice by clicking „Yes" when warning dialog appears. A progress bar will indicate
when the flash process is finished.
5. When the update is finished the DAC will reset and start in sleep mode. To switch it on press the
knob once. Once the DAC has been restarted the firmware update is complete. A reboot of the
computer is not necessary.
When the update fails:
1. Disconnect power cord.
2. Press and hold the first (from the left) button and connect the power cord again.
3. The DAC runs in Bootloader mode. The logo becomes white and blinks constantly.
4. The update process should then be tried again.
Mytek Manhattan II DAC User's Manual

8. Menu

8.1 Menu Navigation

The four buttons, one encoder and the display enable the user to quickly change and configure the
device's settings.
Use triangle buttons (left <-> right) to navigate in the menu. When you select an option turn the
knob round to change available settings. You do not need to confirm your choices. When the setting is
choosen it is also automatically activated.
Turn the knob round to navigate between all available parameters.
Two square buttons (FB1 and FB2) located next to the display are user assignable. Press and hold one
of them to assign a function you need to enable quickly. Following parameters can be assigned:
• MUTE
• MONO
• L-R
• MS
• PHASE
• INPUT
• MQA decoder
