8. AES/EBU Input. Professional digital input that accepts up to 192kHz. Accepts DSD DOP standard
input. This input can also be used to transmit digital data to computer via USB connection.
9. S/PDIF Coaxial Input 1 and S/PDIF Coaxial Input 2 . These are digital inputs which accept up to
192kHz/24bit. They also accept DSD DOP standard input up to DSD64. This input can also be used
to transmit digital audio into computer via USB2 connection. To obtain best results, use a high
quality 75 ohm digital RCA interconnect cable.
Note – these two inputs can also operate as stereo SDIF2/3 DSD input with 2 BNC->RCA
adapters for use with professional DSD recording equipment
(such as Tascam Master Recorders).
10. Analog outputs, unbalanced, RCA
11 Analog outputs, balanced, XLR
12. Analog inputs, unbalanced RCA
13. Analog inputs, unbalanced RCA
14. Analog inputs, balanced, XLR
15. Optional „ROON READY" NETWORK/Wi-Fi CARD. Turns the Manhattan II into network streamer
with 24/192k andDSD64 maximum throughput. Compatible w/ Roon, Airplay, DLNA/UpnP, Spotify
Connect, IOS, Android
16. Power switch: Linear power supply 115 and 230V AC 50/60 Hz. There is a special Japanese version
of 100V/230V available through distributor in Japan.
17. Fuse, 20mm 2 Amp T (slow blow) can be replaced here. There is a spare inside fuse assembly.
18. IEC Power socket. Standard 115/230V receptacle. (100V/230V for Japanese Models)
Quick Start – Immediate Playback AES/EBU, SPDIF and Toslink
Connect the analog outputs to your powered speakers, power amplifier or preamplifier. Alternatively
use headphones. Connect the digital source (CD player) to the DAC. Power up the player, power
amplifier and the Manhattan II DAC. Upon power up, the DAC will default to its default settings hand
picked by our team to produces the optimal sound quality. Choose the input you would like to use.
Attention! To prevent damage, do not turn on your speakers until all connections
have been made

5. Windows installation and configuration

• Turn off your amplifier then connect the Manhattan II DAC Analog Outputs to your amplifier's
analog inputs. Balanced connections (XLR) are typically for professional audio equipment while
unbalanced connections (RCA) are typically for consumer audio equipment.
• Note that for proper operation it is necessary to install the USB2 driver (Windows only) and Mytek
Control application. Both of these have separate installers.
5.1 Windows – USB 2.0 driver installation
To simplify installation it is recommended to first install the drivers before the unit is connected to the
computer. The latest drivers are available at mytekdigital.com
Mytek Manhattan II DAC User's Manual
1. Locate the MytekUSB2Drv.v3.xx.x.zip file
and extract the contents of the archive by right
clicking on the zip archive icon and selecting
„Extract Here".
2. Installation works automatically by a double-
click on MytekUSB2Drv.v3.xx.x.exe file.
3. Once the Setup.exe opens click „Next".
4. Choose the location of installation.Default
location is „C:\Program Files\Mytek Digital\Mytek
USB 2.0 Driver".We recommend leaving this as it
is.If you wish to customize the install choose the
location by selecting browse. Click „Install".
5. Setup.exe will now install the Mytek Driver.This
process may take a few minutes.
6. Upon completion of „Setup.exe" press the
„Next" button.
7. To complete installation of the driver simply
click the „Finish" button.
8. Connect the Manhattan II DAC to USB2 port in
your computer.
