CyberView MPHB-17 User Manual

High brightness displays 17'', 19'' and 22''

Advertisement

Quick Links

User Manual

17", 19"
Options :
- BNC + S-Video
- Audio
22" creen ize
High Bright LCD Panel
Models
MPHB-17 / MPHB-19
High Bright Widescreen LCD Panel
Models
MPHBW-19 / MPHBW-22
High Bright LCD Drawer
Models
MDHB-17 / MDHB-19
High Bright LCD Keyboard Drawer
Models
ERHB-17 / ERHB-19
- Optional KVM
- DVI
- DC power
- Touchscreen

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MPHB-17 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for CyberView MPHB-17

  • Page 1: User Manual

    User Manual 17", 19" 22" creen ize High Bright LCD Panel Models MPHB-17 / MPHB-19 High Bright Widescreen LCD Panel Models MPHBW-19 / MPHBW-22 High Bright LCD Drawer Models MDHB-17 / MDHB-19 High Bright LCD Keyboard Drawer Models ERHB-17 / ERHB-19...
  • Page 2: Table Of Contents

    Contents Chapter 1 Getting Started Important Safeguards............1 Regulatory Notice...............2 Before Installation...............3 Unpacking................3 Optional Accessories............3 Peripheral Products............4 MPHB-17 & MPHB-19 Part 1 Chapter 2 Installation Package Contents..............5 Installation................6 Structure Diagram...............7 Connection.................7 MPHBW-19 / MPHBW-22 Part 2 Chapter 3 Installation Package Contents...............8 Structure Diagram...............9...
  • Page 3 MDHB-17 / MDHB-19 Part 3 Chapter 4 Installation Package Contents.............12 Structure Diagram.............13 Connection...............13 How to Install “One Man” Installation Slides....14-15 How to Use The Slides............16 ERHB-17 / ERHB-19 Part 4 Chapter 5 Installation Package Contents.............17 Optional Accessories............18 Structure Diagram.............18 How to Install “One Man” Installation Slides....19-20 How to Use The Slides............21 ERHB-17 / 19 (Single Console) .......22...
  • Page 4 Chapter 6 Operation On-screen Display Operation...........25 On-screen Menu...............26 Chapter 7 LCD Specifi cation ..........27-28 Chapter 8 Optional Specifi cation DVI-D Option..............29 BNC + S-Video Option............30 Audio Option..............31-33 Chapter 9 Touchscreen Options .........34-35 Chapter 10 Front NEMA 4 / IP65 Options ......36 Chapter 11 Quad Display Option ..........37...
  • Page 5: Important Safeguards

    Chapter 1 1.1 Important Safeguards Please read all of these instructions carefully before you use the device. Save this manual for future reference. What the warranty does not cover ■ Any product, on which the serial number has been defaced, modifi ed or removed. ■...
  • Page 6: Regulatory Notice

    Chapter 1 1.2 Regulatory Notice Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without no- tice.
  • Page 7: Before Installation

    Chapter 1 1.3 Before Installation ■ It is very important to locate the Rackmount LCD Drawer / Display in a suitable environment. ■ The surface for placing and fi xing the Rackmount LCD Drawer / Display should be stable and level or mounted into a suitable cabinet.
  • Page 8: Peripheral Products

    Chapter 1 1.6 Peripheral Products Item Model No. Description 16-Cat6-M2X / M3X / M4X Matrix Cat 6 16-Port KVM 16-Cat6-M3X-IP / M4X-IP / M4X-2IP Matrix IP Cat 6 16-Port KVM Matrix Cat 6 KVM 16-Cat6-M2X / M3X / M4X Matrix Cat 6 32-Port KVM 16-Cat6-M3X-IP / M4X-IP / M4X-2IP Matrix IP Cat 6 32-Port KVM 8-M2X / M3X / M4X...
  • Page 9: Package Contents

    Chapter 2 2.1 Package Contents MPHB-17 & MPHB-19 Rackmount LCD display x 1 pc 6' VGA cable (male to male) x 1 pc User manual (As of Sept 2011, all user manuals will be download-only. Physical copies are available upon request)
  • Page 10: Mphb-17 & Mphb-19

    Chapter 2 2.2 Installation MPHB-17 & MPHB-19 ■ Install each screw shown in Figure 1. Figure 1. ■ Fixed the LCD into the rack. * M6 screws are not provided. Figure 2.
  • Page 11: Structure Diagram

    Chapter 2 2.3 Structure Diagram MPHB-17 & MPHB-19 LCD interchangeable module kit LCD membrane 2.4 Connection MPHB-17 & MPHB-19 DB-15 VGA female connector Power input Caution : The Rackmount LCD Drawer & Display are hot-pluggable, but components of connected devices, such as the servers and KVM switch, may not be hot-pluggable. Plug- ging and unplugging cables while servers and KVM are powered on may cause irreversible damage of the servers, KVM and Rackmount LCD Drawer.
  • Page 12: Package Contents

    Chapter 3 3.1 Package Contents MPHBW-19 & MPHBW-22 Rackmount LCD display x 1 pc 6' VGA cable (male to male) x 1 pc User manual (As of Sept 2011, all user manuals will be download-only. Physical copies are available upon request) Power cord x 1 pc Auto switch power adapter x 1 pc...
  • Page 13: Structure Diagram

    Chapter 3 3.2 Structure Diagram MPHBW-19 & MPHBW-22 LCD interchangeable module kit LCD membrane 3.3 Connection MPHBW-19 & MPHBW-22 DB-15 VGA female connector Power input Caution : The Rackmount LCD Drawer & Display are hot-pluggable, but components of connected devices, such as the servers and KVM switch, may not be hot-pluggable. Plug- ging and unplugging cables while servers and KVM are powered on may cause irreversible damage of the servers, KVM and Rackmount LCD Drawer.
  • Page 14: Installation

    Chapter 3 3.4 Installation MPHBW-19 ■ Install each screw shown in Figure 3. Figure 3. ■ Install the LCD into the rack. * M6 screws are not provided. Figure 4. P.10...
  • Page 15 Chapter 3 3.4 Installation MPHBW-22 Figure 5. Figure 6. ■ ■ Install each screw shown in Figure 5. Insert the upper part of the LCD display to the rack shown in Figure 6. * M6 screws are not provided. Figure 7. Figure 8.
  • Page 16: Package Contents

    Chapter 4 4.1 Package Contents MDHB-17 & MDHB-19 LCD drawer x 1 pc 6’ VGA cable (male to male) x 1 pc User manual (As of Sept 2011, all user manuals will be download-only. Physical copies are available upon request) Auto switch power adapter x 1 pc Power cord x 1 pc Mounting bracket x 2 pcs...
  • Page 17: Structure Diagram

    Chapter 4 4.2 Structure Diagram MDHB-17 & MDHB-19 LCD interchangeable module kit Carry handle to release the 2-pt lock “One Man” Installation Slide 2-point lock LCD membrane 4.3 Connection MDHB-17 & MDHB-19 Caution : The Rackmount LCD Drawer & Display are hot-pluggable, but components of connected devices, such as the servers and KVM switch, may not be hot-pluggable.
  • Page 18: How To Install "One Man" Installation Slides

    Chapter 4 4.4 How to Install "One Man" Installation Slides Installing into rack Rear side Right bracket ■ Attach the left and right mounting bracket to rack 19” mounting rails. ■ Adjust the rear mouting bracket to fi t your rack. ■...
  • Page 19: How To Install "One Man" Installation Slides

    Chapter 4 4.4 How to Install “One Man” Installation Slides ■ Attach front left and right mounting ears of the LCD keyboard drawer to vertical mounting rails. ■ M6 screw and cup washer x 2 pcs included. Complete the installation ■...
  • Page 20: How To Use The Slides

    Chapter 4 4.5 How to Use the Slides MDHB-17 & MDHB-19 ■ A black arrow release button is located on the outside of each slide. (shown in Figure 9). Figure 9. ■ Pull and hold the black arrow button on either side of the LCD drawer to unlock.
  • Page 21: Erhb-17 / Erhb-19

    Chapter 5 5.1 Package Contents ERHB-17 & ERHB-19 LCD keyboard drawer x 1 pc CE-6 Combo 4-in-1 KVM cable x 1 pc User manual (As of Sept 2011, all user manuals will be download-only. Physical copies are available upon request) Power cord x 1 pc Auto switch power adapter ( for external power version) x 1 pc Mounting bracket x 2 pcs...
  • Page 22: Optional Accessories

    Chapter 5 5.2 Optional Accessories 1. Combo 4-in-1 KVM cable 1.1 CAE-6 (CE-6) 6 feet 1.2 CAE-10 (CE-10) 10 feet 1.3 CAE-15 (CE-15) 15 feet 2. Power Cord 2.1 IEC power cord 2.2 NEMA 5-15 power cord (US) 2.3 BS 1363 power cord (UK) 2.4 CEE 7/4 power cord (German) 2.5 AS 3112 power cord (Australia) 5.3 Structure Diagram...
  • Page 23: How To Install "One Man" Installation Slides

    Chapter 5 5.4 How to Install "One Man" Installation Slides Installing into rack Rear side Right bracket ■ Attach the left and right mounting bracket to rack 19” mounting rails. ■ Adjust the rear mouting bracket to fi t your rack. ■...
  • Page 24: How To Install "One Man" Installation Slides

    Chapter 5 5.4 How to Install "One Man" Installation Slides ■ Attach front left and right mounting ears of the LCD keyboard drawer to vertical mounting rails. ■ M6 screw and cup washer x 2 pcs included. Complete the installation ■...
  • Page 25: How To Use The Slides

    Chapter 5 5.5 How to Use the Slides ■ A black arrow release button is located on the outside of each slide. (shown in Figure 12). Figure 12. ■ Pull and hold the black arrow button on either side of the LCD keyboard drawer to unlock. (shown in Figure 13).
  • Page 26: Erhb-17 / 19 (Single Console)

    Chapter 5 5.6 ERHB-17 / 19 (Single Console) - Use CE-6 to connect to server via PS/2 interface Figure 15. Example of connecting CE-6 4-in-1 Combo KVM cable to server via PS/2 interface 5.7 ERHB-17 / 19 (Single Console) - Use CE-6 to connect to KVM via PS/2 interface CE-6 KVM Cable Figure 16.
  • Page 27: Erhb-17 / 19 (Single Console)

    Chapter 5 5.8 ERHB-17 / 19 (Single Console) - Use CE-6 to connect to server via USB interface Figure 17. Example of connecting CE-6 4-in-1 Combo KVM cable to server via USB interface 5.9 ERHB-17 / 19 (Single Console) - Use CE-6 to connect to KVM via USB interface CE-6 KVM Cable Figure 18.
  • Page 28: Keyboard & Mouse

    Chapter 5 5.10 Keyboard & Mouse ERHB-17 & ERHB-19 Supporting layouts N keyboard integrated with touch pad keyboard integrated with track ball P.24...
  • Page 29: On-Screen Display Operation

    Chapter 6 6.1 On-screen Display Operation 17 & 19 & 17 & 17 & LCD membrane Membrane Switch Function Power light Green = On Orange = Power saving Power on / off LCD Display the OSD menu Scrolls through menu options and adjusts the displayed control (To auto adjustment by pressing the button for 5 seconds) Exit the OSD screen...
  • Page 30: On-Screen Menu

    Chapter 6 6.2 On- creen Menu OSD Confi guration Page Image: the brighness, contrast, color temp, red, green, and blue Geometry: the auto adjust, H position, V position, phase and clock Video: the colour, tint, sharpness, noise reduction, DCDi and TV Setup Audio: volume, bass, treble, balance, AVL and mute...
  • Page 31: Chapter 6 Operation

    Chapter 7 7.1 LCD Specifi cations 17 & 17 & 17 & Item Description Grade A industrial TFT LCD panel LCD Grade Diagonal Size 17" TFT 19" TFT Max. Resolution 1280 x 1024 1280 x 1024 Brightness (cd/m²) 1000 1000 Color Support 16.7 M 16.7 M...
  • Page 32: Chapter 7 Lcd Specifi Cation

    Chapter 7 7.1 LCD Specifi cations 19 & Item Description Grade A industrial TFT LCD panel LCD Grade Diagonal Size Wide 19" TFT Wide 22” TFT Max. Resolution 1440 x 900 1680 x 1050 Brightness (cd/m²) Color Support 16.7 M 16.7 M Contrast Ratio (typ.) 900:1...
  • Page 33: Dvi-D Option

    Chapter 8 8.1 DVI-D Option 17 & 19 & DVI-D Power ■ Package includes 1 x 6ft DVI-D cable 17 & 17 & Power DVI-D ■ Package includes 1 x 6ft DVI-D cable P.29...
  • Page 34: Bnc + S-Video Option

    Chapter 8 8.2 BNC + S-Video Option 17 & 19 & S-Video BNC Power 17 & 17 & Power S-Video BNC ■ Package includes 1 x 6ft S-Video cable P.30...
  • Page 35: Audio Option

    Chapter 8 8.3 Audio Option 17 & 19 & Audio Power ■ Audio input is 35mm audio plug ■ The speaker is sharing the same power with LCD. P.31...
  • Page 36 Chapter 8 8.3 Audio Option 17 & Power Audio ■ Audio input is 35mm audio plug ■ The speaker is sharing the same power with LCD. P.32...
  • Page 37 Chapter 8 8.3 Audio Option 17 & Power Audio ■ Audio input is 35mm audio plug ■ The speaker is sharing the same power with LCD. P.33...
  • Page 38: Touchscreen Options

    Chapter 9 9.1 Touchscreen Options 17 & 19 & USB interface Power Serial interface Serial Power 17 & USB interface Power Serial interface Power Serial P.34...
  • Page 39: Chapter 9 Touchscreen Options

    Chapter 9 9.1 Touchscreen Options 17 & USB interface Power Serial interface Power Serial e-Resistive -17TRB / -19TRB / -19WTRB / -22WTRB / Model -17TRS -19TRS -19WTRS -22WTRS Screen size 17" 19" 19" wide 22" wide Interface USB / serial Optical transmittance 80% ±...
  • Page 40: Chapter 10 Front Nema 4 / Ip65 Options

    Chapter 10 10.1 Front NEMA 4 / IP65 Options 17 & 19 & Rear case LCD panel 4mm protective glass (Front NEMA 4 / IP65 protection) Aluminum front panel ■ 4mm thickness of protective glass is not toughened one, please handle it carefully. P.36...
  • Page 41: Chapter 11 Quad Display Option

    Chapter 11 11.1 Quad Display Option Specifi cations Video IN 1 ~ 4 RS-232 VCR in Video Loop Alarm I/O VCR out AV BNC VGA Power 1 ~ 4 Item Description Model Number QD (NTSC) QD (PAL) Number of Color 16.7 M 16.7 M Imaging System...
  • Page 42: Chapter 12 Dc Power Options

    Chapter 12 12.1 DC Power Options & 19 & DC Power input 17 & DC Power input 17 & DC Power input Model Input rating Input voltage: 24-Volt 48-Volt Input range: 18 ~ 36V 36 ~ 75V Input current - No load 50 mA 50 mA - Full load...
  • Page 43: Chapter 13 Dimensions

    Chapter 13 13.1 Dimensions MPHB-17 & MPHB-19 MPHBW-19 & MPHBW-22 MDHB-17 & MDHB-19 ERHB-17 & ERHB-19 Product Dimension Packing Dimension Gross Model Net Weight (W x D x H) (W x D x H) Weight 480 x 57 mm 565 x 450 x 156 mm 7 kg 8.5 kg...
  • Page 44: Chapter 14 Troubleshooting

    Chapter 14 14.1 Troubleshooting 1. How do I adjust the resolution? To change monitor resolution, click Start -> Control Panel -> Display. Select Setting tab to adjust the monitor resolution in Desktop Area. The available resolutions, "640 x 480", "800 x 600", "1024 x 768", "1152 x 864", "1280 x 1024", are deter- mined by the display card in your computer.
