- Page 1 Simrad MS70 Scientific multibeam sonar system We are proud to introduce the world’s first quantitative multibeam sonar for fishery research applications www.SIMRAD.com M A X I M I Z I N G Y O U R P E R F O R M A N C E...
- Page 2 System overview Key points low beam interleakage is obtained by using Frequency Rotated Sector The Simrad MS70 offers a new • The Simrad MS70 operates in dimension to fishery research. It the 75 to 112 kHz frequency Transmission (FRST) where the provides an acoustic matrix of range.
- Page 3 (Data kindly provided by IMR, Norway.) System diagram Operator station Beamforming The Simrad MS70 Operator Station comprises a workstation computers running Windows XP ® operating system. It is connected to Operator station the ship’s network, and can communicate with external post- Network processing applications.
- Page 4 Receiving • Receiver dynamic range: 150 dB (instantaneous) The transducer array set up for test and calibration at Simrad’s test facility Calibration • Calibration software included • Target: Tungsten sphere Note that technical specifications can be altered without prior notification! (306694 / Rev.A / November 2006)
