Summary of Contents for Simrad FS70
- Page 1 M A X I M I Z I N G Y O U R P E R F O R M A N C E S E A...
- Page 2 FS system. In addition all the data from the wireless sensors can be received wireless by the vessel making it the ultimate back up system if the third wire breaks. Simrad PI sensor family with 6”, 10” and 15” bridge unit.
- Page 3 The Simrad FS70 full screen presentation in a polar- sounder mode indicates the position of the trawl close to the bottom and the opening of the net by displaying the Cursor 1 and 2. In addition, the sounder display provides an accurate depth of the bottom and the foot rope.
- Page 4 • PI Catch Sensor: No 1, 2, 3 and 4 Catch Sensor frequency: 40kHz or 70kHz Operating system: MS Window XP Depth rating: 2000 meters Sonar operating system: Simrad “Winson” 40GB hard drive RS232 serial port Communication channel: Selectable and programmable Dual graphic monitor output •...
