Installation Manual
Simrad SC90
Fish finding sonar
www.simrad.com
T E C H N O L O G Y
F O R
S U S T A I N A B L E
F I S H E R I E S

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SC90 and is the answer not in the manual?

Questions and answers

Related Manuals for Simrad SC90

Summary of Contents for Simrad SC90

  • Page 1 Installation Manual Simrad SC90 Fish finding sonar www.simrad.com T E C H N O L O G Y F O R S U S T A I N A B L E F I S H E R I E S...
  • Page 3 SC90. The manual is intended for technical personnel; such as skilled shipyard workers, electricians, qualified engineers and naval architects. For information about the practical use of the SC90, refer to the SC90 Reference Manual and/or the SC90 Operator Manual. You can also find information in the SC90 Context Sensitive On-line Help.
  • Page 4 Support information If you require maintenance or repair, contact your local dealer. You can also contact us using the following address: simrad.support@simrad.com. If you need information about our other products, visit https: //www.simrad.com.

  • Page 5: Table Of Contents

    Dry docking requirements ..................46 Requirement for classification approval..............46 Network security......................46 Support information ......................47 PREPARATIONS ..............50 Installation summary......................51 About installation drawings .....................53 Tools, equipment and consumables required for SC90 installation.........54 Personnel qualifications ....................55 Choosing the best location for the hull unit ..............56 419050/B...
  • Page 6 Requirements for bilge pump and decking.............67 Lifting requirements ....................68 Orientation of the Hull Unit ...................69 Sonar room arrangement: Top view SC90 .............70 Sonar room arrangement: Side view SC90 ............71 Sonar room arrangement: Side view SC90 ............72 Sonar room arrangement: Top view SC94 .............73 Sonar room arrangement: Side view SC94 ............74...
  • Page 7 Installing the gate valve ....................113 Installing the transducer dock ..................115 Installing the hydraulic units..................117 Verifying the quality of the gate valve installation ............118 MOUNTING THE SC90 INSTALLATION TRUNK...... 120 About the installation trunk ...................121 Rubber gasket .......................122 Mechanical support brackets ................122 Design and installation drawings .................123...
  • Page 8 Simrad SC90 INSTALLING THE SC90 HULL UNIT ........140 About the hull unit installation ..................141 Mechanical support brackets ................142 Rubber gasket .......................142 Design and installation drawings .................143 Hull unit installation example: Top view .............144 Hull unit installation example: Side view ............145 Hull unit installation example: Side view ............146...
  • Page 9 Øverland UPC-5000P Serial line splitter description...........218 Øverland UPC-5000P Technical specifications............219 Øverland UPC-5000P Connections..............220 Øverland UPC-5000P Dimensions...............221 Setting up the SC90 in a synchronized system ..............222 About synchronization ..................222 Synchronization modes ..................223 Synchronization using Clear To Send (CTS) and Request To Send (RTS) signals ......................224...
  • Page 10 RJ45 High speed Ethernet cable (From Processor Unit to Transceiver Unit).........................240 K-Sync interface to generic RS-232 synchronization input .........241 Simrad TU40 interface to generic RS-232 synchronization input .......243 Communication and power cable for the Operating Panel........245 DC power cable from Power Supply Unit to Transceiver Unit......246 Ethernet cable with noise suppressor from Transceiver Unit to Motor Control Unit ........................247...
  • Page 11 Configuring the SC90 for normal operation ..............313 Selecting which hull unit to be used with the SC90..........313 Aligning the SC90 presentation to the direction of the transducer (SC90) ...315 Aligning the SC90 presentation to the direction of the transducer (SC94) ...317 Defining the value for sound speed (sound velocity) ...........319...
  • Page 12 Testing the Operating Panel to verify basic functionality ........345 Testing the user interface to verify basic functionality ........349 Verifying SC90 operation by means of the BITE functionality ......351 Measuring the Echo level in Passive mode............355 Measuring the output voltages from the Power Supply Unit .......357 Making a noise/speed curve to determine vessel noise ........358...
  • Page 13 NMEA VWR datagram ..................416 NMEA ZDA datagram ..................417 Proprietary datagram formats ..................418 Simrad DBS datagram format ................418 Simrad FS3300 Binary depth datagram format............419 Simrad GLL datagram format ................419 Simrad HFB datagram format ................420 Simrad MDS datagram format ................420 Simrad MTW datagram format ................422 Simrad PSIMP-D datagram format ..............422...
  • Page 14 385609 Processor Unit dimensions................438 422358 Transceiver Unit dimensions ................442 204688 Operating Panel dimensions ................445 422321 Power Supply Unit dimensions.................447 413125 Hull Unit dimensions SC90 ................449 426919 Hull Unit dimensions SC94 ................452 402509 Installation trunk dimensions................455 427176 Installation trunk dimensions................458 434524 Installation trunk dimensions................460 051344 Blind panel dimensions (ø370 mm)..............463...
  • Page 15 Installation Manual Cleaning an electronic cabinet or unit ..............508 Cleaning a mechanical or electromechanical unit ..........510 Cleaning the hull unit ...................510 Handling instructions for printed circuit boards and electronic modules ......512 Circuit board unpacking and handling ..............512 Returning a printed circuit board or an electronic module to Kongsberg Maritime ......................514 About Electrostatic Discharge (ESD)..............515 Disposal of old products ....................516...
  • Page 16 Simrad SC90 419050/B...

  • Page 17: About This Manual

    Information about third party products and/or services may not be included in this manual, even though these may be provided as a part of the SC90 delivery. Refer to the relevant end-user documentation provided by the manufacturer.
  • Page 18 The shipowner and shipyard doing the installation are responsible for obtaining and paying for such approval. The outline dimensions of the SC90 units are found in the Drawing file chapter in this manual. The source drawings (normally in AutoCad format) can be downloaded from our website.

  • Page 19: Simrad Sc90

    Before you power up the SC90, make sure that you have sufficient water depth to lower the transducer! Caution You must never power up the SC90 when the ship is in dry dock The transducer may be damaged if it transmits in open air. 419050/B...
  • Page 20 When you are docking your vessel You must never power up the SC90 when the ship is in dry dock The transducer may be damaged if it transmits in open air. To prevent inadvertent use of the SC90, pull out the mains plug on the Processor Unit whenever your vessel is in dry dock.

  • Page 21: System Description

    The Simrad SC90 is an omnidirectional high frequency fish finding sonar. The SC90 is designed for fishing vessels of all sizes, both purse seiners and trawlers. The centre operational frequency is 84 kHz, but you can select any operational frequency from 82.5 to 85.0 kHz in steps of 0.5 kHz.

  • Page 22: Key Features

    Scope of supply, page 32 Key features The Simrad SC90 is a perfect "catching machine", ideal for mackerel, tuna and fish close to bottom detection. The combination of horizontal and vertical beams shows you the fish as "birds eye" and "slice" simultaneously. This provides vital school data without having to pass over the target.

  • Page 23: System Diagram

    Simrad SC90 System diagram The system diagram identifies the main components of a basic SC90 system. Only the main connections between the units are shown. Detailed interface capabilities and power cables are not shown. Processor Unit Display Operating Panel Operating Panel Power Supply...

  • Page 24: System Units

    Note The display is not a standard part of the SC90 delivery. This is a commercial item that can be purchased locally. Kongsberg Maritime may provide a suitable display. The chosen display must be designed for maritime use, and it must meet the minimum performance specifications.

  • Page 25: Processor Unit Description

    Simrad SC90 Processor Unit description The SC90 Processor Unit is a rugged and powerful computer. It is designed for long life in a demanding maritime environment. It contains the operational software, and offers the user interface that allows you to control the SC90. It also controls the interface to peripheral devices.

  • Page 26: Transceiver Unit Description

    The connectors for power and interfaces are located at the bottom of the cabinet. Note To extend the lifetime of the SC90 Transceiver Unit, it must be mounted at dry and clean location with sufficient ventilation. Observe the sonar room requirements Related topics...

  • Page 27: Operating Panel Description

    Operating Panel and the menu system shown in the SC90 presentation. You can also use a standard computer mouse to control the SC90. The mouse can be connected to either the Operating Panel or directly to the Processor Unit.

  • Page 28: Power Supply Unit Description

    422321 Power Supply Unit dimensions, page 447 Hull unit description The hull unit provided with the SC90 is designed to lower the transducer down below the ship’s hull when the SC90 shall be used. When the SC90 is switched off, the transducer is hoisted for protection.
  • Page 29 Note If you forget to hoist the transducer before the SC90 is switched off, the transducer is hoisted automatically before the power is disconnected. The transducer is also hoisted automatically if a serious malfunction occurs to the communication between the bridge and the hull unit.
  • Page 30 For added protection, a gate valve can then be added to mechanically shut off the bottom of the installation trunk when the SC90 is not used. Two different gate valves types are used.

  • Page 31: Transducer Description

    SC90 is turned off. By lowering the transducer into the water, you may also be able to reduce the noise created by the laminar flow of water along the hull.

  • Page 32: Installation Trunk Description

    The installation trunk provides the physical foundation for the entire hull unit. The installation trunk penetrates the hull. It is therefore a crucial part of the hull unit assembly. In order to ensure proper SC90 operation, the physical location of the installation trunk must be carefully selected.
  • Page 33 Simrad SC90 Related topics Installation trunk, page 35 System units, page 22 Mounting the SC90 installation trunk, page 120 402509 Installation trunk dimensions, page 455 051344 Blind panel dimensions (ø370 mm), page 463 Mounting the SC94 installation trunk, page 130...

  • Page 34: Scope Of Supply

    329512 Ethernet cable, 100 m The SC90 Fish finding sonar can be provided with one of the following hull units.The same transducer is used on all hull unit types. Due to the different flange diameters, different installation trunks are used.
  • Page 35 Simrad SC90 Item Part number In the box 424294 Hull Unit SC90 Hull Unit Lowering depth: 1 m, Transducer ca- ble: 10 m Transducer Hull Unit SC94 426967 Hull Unit Lowering depth: 2.1 m, Transducer cable: 4.6 m Transducer Operational software Operational software is provided on a suitable media.

  • Page 36: Additional Required Items

    Course gyro, page 37 Display The display is not a standard part of the SC90 delivery. This is a commercial item that can be purchased locally. Any commercial display can be used with the SC90 Fish finding sonar, provided that the display meets the minimum requirements.
  • Page 37 Maritime as an option. For information purposes, the drawings of the installation trunk and the blind cover are included in this manual. The SC90 Fish finding sonar can be provided with one of the following hull units. Hull Unit Lowering depth...
  • Page 38 Installation trunk description, page 30 System units, page 22 Speed log In order to operate correctly, the SC90 requires input from a speed log. A speed log is normally not a part of the SC90 delivery. Note Without the input from a speed log, the SC90 will neither be able to present correct navigational information, nor compensate for vessel movements.
  • Page 39 SC90 delivery. Note Without the input from a course gyro, the SC90 will not be able to present correct navigational information. In most cases a suitable course gyro is already installed on the vessel. A global positioning system (GPS) with a fitting output format can also be used.

  • Page 40: Additional Optional Items

    Secondary display The Processor Unit offers two video outputs. Two displays may therefore be used to see the SC90 presentations. The display is not a standard part of the SC90 delivery. This is a commercial item that can be purchased locally.
  • Page 41 A secondary Operating Panel may be connected to the SC90 Processor Unit. This may be useful in conjunction with a secondary display if you wish to control the SC90 from two different locations on your vessel. The secondary operating panel will allow you to do all SC90 operations except power on/off.
  • Page 42 Global Positioning System (GPS) A Global Positioning System (GPS) may be connected to the SC90 to establish the vessel's position, and provide cursor and marker latitude and longitude. In addition to navigational data, the GPS may also be used to provide speed information.
  • Page 43 In order to operate correctly, the SC90 requires input from a motion reference unit (MRU). By default, the SC90 uses a built-in motion sensor. It is placed inside the Motor Control Unit. For improved operational accuracy, an external motion reference unit (MRU) may be used.
  • Page 44 Simrad SC90 Installation Manual Item Part number In the box Serial line splitter 337775 Serial line splitter (Øverland UPC-5000P) The Øverland UPC-5000P serial line splitter offers two separate inputs and fifteen RS-232 and RS-422 outputs. Serial line splitter 317156 Serial line splitter (Øverland UPC-3005) The Øverland UPC-3005 serial line...

  • Page 45: General Safety Rules

    Safety is important. The safety precautions must be followed at all times during installation and maintenance work. WARNING The SC90 operates on 115 and/or 230 VAC 50/60 Hz. This voltage is lethal! You must never work alone on high-voltage equipment! The hull unit is powered by a 3-phase high voltage.

  • Page 46: Installation Requirements

    Supply power requirements Observe the general requirements related to the supply power. The supply voltage to the SC90 must be kept within ±10% of the installation’s nominal voltage. Maximum transient voltage variations on the main switchboard’s bus-bars are not to exceed -15% to +20% of the nominal voltage (except under fault conditions).

  • Page 47: Cables And Wiring Requirements

    For more detailed information about cables and wiring, refer to the basic cable requirements. Compass deviation requirements SC90 units that are installed on the bridge may have an effect on the compass. Once the installation is complete, the vessel must be swung with the SC90 in both operative and inoperative modes.

  • Page 48: Dry Docking Requirements

    Label the Processor Unit and/or the circuit breaker clearly to prevent anyone from powering up the SC90 accidentally. Note The location of the SC90 installation trunk must be noted on the vessel’s docking plan for future reference. Requirement for classification approval Classification approval is required for the SC90 installation.

  • Page 49: Support Information

    The computers are thus not protected against viruses, malware or unintentional access from external users. Securing the SC90 system itself has no meaning unless there is a policy in place that secures all computers in the network. This policy must include physical access by trained and trusted users.
  • Page 50 : +33 298 582 388 Telefax • http://www.simrad.fr Website • simrad.france@simrad.com E-mail address • : Kongsberg Underwater Technology Inc / Simrad Fisheries Company name • : 19210 33rd Ave W, Lynnwood, WA 98036, USA Address • : +1 425 712 1136 Telephone •...
  • Page 51 Simrad SC90 China • : Kongsberg Maritime China Ltd Company name • : 555 Chuanqiao Road, China (Shanghai) Pilot Free Trade Zone, 201206, Address China • : +86-21-3127-9888 Telephone • : +86-21-3127-9555 Telefax • https://www.simrad.com Website • simrad.china@simrad.com E-mail address...

  • Page 52: Preparations

    Topics Installation summary, page 51 About installation drawings, page 53 Tools, equipment and consumables required for SC90 installation, page 54 Personnel qualifications, page 55 Choosing the best location for the hull unit, page 56 Location of hardware units on the bridge, page 59...

  • Page 53: Installation Summary

    Note In order to obtain maximum safety and SC90 performance, it is very important that the installation procedures in this manual are complied to. You must do the tasks in the order they are described.
  • Page 54 • Installing the SC94 Hull Unit, page 158 Install the SC90 system units. Note that some SC90 system units may be commercial. Unless ordered specifically these are not included in the delivery, and must be purchased locally. • Location of hardware units on the bridge, page 59 •...

  • Page 55: About Installation Drawings

    Cable layout and interconnections, page 190 Power up the SC90 for the first time, and set it to work. Note In order to power up of the SC90 in a safe and correct manner, the relevant procedures must be complied to! •...

  • Page 56: Tools, Equipment And Consumables Required For Sc90 Installation

    Tools, equipment and consumables required for SC90 installation In order to do the SC90 installation, all necessary tools and equipment for mechanical work, cabinet installation and electrical wiring must be available. It is not practical to provide a detailed list of all necessary tools and equipment. You must be equipped with a standard set of tools.

  • Page 57: Personnel Qualifications

    Preparations Personnel qualifications The installation of the SC90 is a demanding task. It is very important that the personnel involved in the installation tasks are competent and experienced craftsmen. As a minimum, the following certified craftsmen must be available. • Naval architects •...

  • Page 58: Choosing The Best Location For The Hull Unit

    Selecting the best possible location for the hull unit is of vital importance for the overall SC90 performance. The hull unit location must be selected by a skilled engineer with experience in sonar theory and hull unit installation. Simrad will assist if required.

  • Page 59: Defining The Fore And Aft Location Of The Hull Unit

    The hull unit should preferably be located within 1/3 to 1/10 of the vessel’s Length Between Perpendiculars (LBP) from its Forward Perpendicular (FP). Deviations should not be made without consulting Simrad. Water level at normal trim Welding marks to indicate hull unit location when docking...

  • Page 60: Important Considerations Related To Noise

    The operational performance of all hydroacoustic systems depend on the noise conditions. It is essential that the noise signature is as low as possible. Careful planning of the SC90 installation may reduce the acoustic noise. The installation trunk must be mounted so that it remains vertical during normal operating conditions.

  • Page 61: Location Of Hardware Units On The Bridge

    Preparations Location of hardware units on the bridge Topics Basic requirements for the location of bridge units, page 59 Maximum distance between each bridge unit, page 60 Choosing the best location for the display, page 61 Choosing the best location for the Processor Unit, page 62 Choosing the best location for the Operating Panel, page 62 Choosing the best location for the Operating Panel Power Supply, page 62 Basic requirements for the location of bridge units...

  • Page 62: Maximum Distance Between Each Bridge Unit

    Description Length This is a commercial cable. The cable is not supplied with the SC90 delivery, and must be obtained locally. This is a commercial cable. The cable is not supplied with the SC90 delivery, and must be obtained locally.

  • Page 63: Choosing The Best Location For The Display

    A display selector will allow you to set up the SC90 (or any other system) to be viewed on any display, and this may be chosen depending on the current operations taking place.

  • Page 64: Choosing The Best Location For The Processor Unit

    Choosing the best location for the Operating Panel The Operating Panel contains all necessary control functions for normal operation of the SC90. The Operating Panel must be mounted in a nearly horizontal position, and within easy viewing range of the display.
  • Page 65 Preparations Any location can be used, provided that the cables are long enough, and that the ventilation is adequate.. Compass safe distance The compass safe distance for the Operating Panel Power Supply has not been defined. If it is installed close to the Processor Unit, the compass safe distance required by the Processor Unit gives sufficient protection.

  • Page 66: Sonar Room Requirements

    The SC90 units must be installed in a dry and dust-free environment. The units are not fully protected against humidity, dust or water. It is important that the sonar room is kept dry. The SC90 units must not be exposed to excessive temperatures, moisture or humidity. Such conditions can cause corrosive attacks and subsequent failures to the electronic circuitry.

  • Page 67: Requirement For Watertight Integrity

    Preparations Requirement for watertight integrity The size, location and design of the sonar room must fulfil all the requirements to the vessel’s watertight integrity. In the event of a major leak, it must be possible to close all watertight hatches and/or doors to the room to maintain the vessel stability and safety.

  • Page 68: Requirements For Insulation, Heating And Ventilation

    If the vessel is likely to operate in tropical conditions, a suitable air conditioning system must be installed. The air conditioning system must be able to provide an ambient temperature that does not exceed the maximum operating temperatures of the SC90 units that are installed in the room.

  • Page 69: Requirements For Electrical Installations, Cables And Communication

    Proper vessel ground must be provided. Cabling requirements The sonar room units are connected to other SC90 units located in different compartments on the vessel. The units may also be connected to peripheral devices. If these cables pass through hatches or areas where they may be damaged, they must be run in conduits.

  • Page 70: Lifting Requirements

    Simrad SC90 Installation Manual Decking requirement Once the installation has been completed, the sonar room must be suitably decked without restricting access to the equipment and the cables. Lifting requirements An attachment point for supporting a lifting device must be located above the hull unit.

  • Page 71: Orientation Of The Hull Unit

    Ethernet and power cables. Note Irrespective of the physical hull unit orientation, the transducer shall not be mechanically aligned. Hull unit alignment is done in the SC90 software by rotating the echo presentation in the display view. 419050/B...

  • Page 72: Sonar Room Arrangement: Top View Sc90

    Simrad SC90 Installation Manual Sonar room arrangement: Top view SC90 The sonar room must provide ample space for all the items provided with the SC90. This example shows a typical sonar room seen from above. Mechanical support brackets Due to its height and weight,...

  • Page 73: Sonar Room Arrangement: Side View Sc90

    Preparations Sonar room arrangement: Side view SC90 The sonar room must provide ample space for all the items provided with the SC90. This example shows a typical sonar room and hull unit seen from the side. A blister is added for streamlining and protection.

  • Page 74: Sonar Room Arrangement: Side View Sc90

    Simrad SC90 Installation Manual Sonar room arrangement: Side view SC90 The sonar room must provide ample space for all the items provided with the SC90. The hull unit is mounted on the centre axis of the vessel, on top of the keel.

  • Page 75: Sonar Room Arrangement: Top View Sc94

    Preparations Sonar room arrangement: Top view SC94 The sonar room must provide ample space for all the items provided with the SC90. This example shows a typical sonar room seen from above. Mechanical support brackets Due to its height and weight,...

  • Page 76: Sonar Room Arrangement: Side View Sc94

    Simrad SC90 Installation Manual Sonar room arrangement: Side view SC94 The sonar room must provide ample space for all the items provided with the SC90. This example shows a typical sonar room and hull unit seen from the side. A blister is added for streamlining and protection.

  • Page 77: Sonar Room Arrangement: Side View Sc94

    Preparations Sonar room arrangement: Side view SC94 The sonar room must provide ample space for all the items provided with the SC90. The hull unit is mounted on the centre axis of the vessel, on top of the keel. Fixing point for lifting device,...

  • Page 78: Acoustic Noise

    Some means to reduce acoustic noise, page 82 Introduction to the acoustic noise challenge As with any other hydroacoustic systems, the quality of the SC90 echo data and presentations are subject to unwanted acoustic noise. The echoes from any large and small target must be detected inside the noise.
  • Page 79 Preparations our end user documentation aims to help the user to make the right filter settings during operation. As for the target properties, there is nothing any of us can do with those. The signal-to-noise ratio, however, can be improved by making the correct choices during installation.

  • Page 80: Self Noise

    Simrad SC90 Installation Manual The transducer cable is long, and may pick up electric noise from generators, pumps, cooling systems and other electric or electromechanical devices. The preamplifiers are very sensitive, and they can easily pick up electrical noise from internal and external power supplies. The preamplifiers are also vulnerable for analogue noise created by their own electronic circuitry.
  • Page 81 Preparations Cavitation Cavitation is the formation of small air bubbles close to the transducer face. The bubbles appear because the local pressure becomes negative during parts of the acoustic pressure cycles. The cavitation threshold increases with the hydrostatic pressure. The noise is made when the bubbles implode.

  • Page 82: Ambient Noise

    Simrad SC90 Installation Manual thickness depends on ships speed and on the roughness of the hull. All objects sticking out from the hull, or dents in the hull, will disturb the flow and will increase the thickness of the boundary layer. When the flow speed is high, the turbulence can be violent enough to destroy the integrity of the water.

  • Page 83: Electrical Self Noise

    The energy reflected from these "unwanted" objects is referred to as reverberation. Reverberation is generated when the echoes from your SC90 transmission are reflected not only by fish and valid targets in the water, but also from the seabed and from the sea surface.

  • Page 84: Some Means To Reduce Acoustic Noise

    Some means to reduce acoustic noise Several factors are contributing to the performance of the hydroacoustic equipment used on board a vessel. Careful planning of the SC90 installation may reduce the acoustic noise. Unfortunately, it is impossible to simply provide a number of specific procedures to reduce the noise.
  • Page 85 • Make sure that all units are properly grounded, as this is important to avoid electrical noise. • Use shielded cables with correct grounding. • Separate SC90 cables from other cables with high voltages, large currents or transients. • Place all high voltage power cables in metal conduits.

  • Page 86: Installing The Optional Gate Valve Dn350

    Simrad SC90 Installation Manual Installing the optional gate valve DN350 Topics About the optional gate valve, page 85 Gate valve system description, page 87 Gate valve installation principles, page 88 Mechanical support brackets, page 89 Installing the mounting flange, page 90...

  • Page 87: About The Optional Gate Valve

    For added protection, a gate valve can then be added to mechanically shut off the bottom of the installation trunk when the SC90 is not used. Illustration:...
  • Page 88 The depths are further decreased with the height of the mounting flange. • The SC90 allows you to define a middle position for the transducer. When you define the middle position, you must take the total height of the gate valve and the mounting flange into consideration.

  • Page 89: Gate Valve System Description

    Installing the optional gate valve DN350 Gate valve system description The gate valve can either be manually operated, or controlled by a hydraulic system. On the manual type, a hand operated wheel is used to open and close the valve. On the hydraulic version, a single button does the same job.

  • Page 90: Gate Valve Installation Principles

    Simrad SC90 Installation Manual A control cable connects the hydraulic gate valve and the Gate Valve Control Unit to the Motor Control Unit. Gate valve installation principles The gate valve is placed at the bottom of the transducer dock. The gate valve must be mounted so that its top mating surface is in parallel with the sea surface during normal operating conditions.

  • Page 91: Mechanical Support Brackets

    Installing the optional gate valve DN350 The gate valve is manufactured by LK Valves. Technical information about this unit is not included in this SC90 Installation Manual. Refer to the relevant end-user documentation provided by the manufacturer. Mechanical support brackets Together, the gate valve, transducer dock and hull unit form a tall and heavy construction.

  • Page 92: Installing The Mounting Flange

    Simrad SC90 Installation Manual Installing the mounting flange The mounting flange must be mounted so that its top mating surface is in parallel with the sea surface during normal operating conditions. The transducer dock on top of the gate valve must remain vertical during the same conditions.
  • Page 93 Make sure that the hull plating surrounding the mounting flange is even and smooth without protruding objects that can cause noise. Objects protruding from the hull will generate turbulence and flow noise. This will reduce the SC90 performance. If necessary, grind and polish all surfaces.
  • Page 94 Simrad SC90 Installation Manual 10 Verify that the mounting flange has been installed correctly. Inspect the mounting flange. Inspect the installation of the mounting flange, the blister, hull plating and all surfaces thoroughly. Make sure that the mating surface is clean and undamaged, and well protected until the gate valve is mounted.

  • Page 95: Mounting Flange And Manual Gate Valve Installation

    Installing the optional gate valve DN350 Mounting flange and manual gate valve installation This illustration demonstrates the mounting principles for a manual gate valve. The mounting flange and the gate valve are shown. The drawings are not to scale. Frames Knee-plates (stiffeners) Gate valve Knee-plates (stiffeners)

  • Page 96: Mounting Flange And Hydraulic Gate Valve Installation

    Simrad SC90 Installation Manual Mounting flange and hydraulic gate valve installation This illustration demonstrates the mounting principles for a hydraulic gate valve. The mounting flange and the gate valve are shown. The drawings are not to scale. Frames Knee-plates (stiffeners)

  • Page 97: Installation Example

    As short a possible As short a possible As short a possible Note The SC90 Hull Unit is designed to lower the transducer 1.0 meter below the ship’s hull. This depth is decreased with the physical height of the gate valve.

  • Page 98: Installing The Gate Valve

    Simrad SC90 Installation Manual Installing the gate valve The gate valve must be mounted so that its top mating surface is in parallel with the sea surface during normal operating conditions. The transducer dock on top of the gate valve must remain vertical during the same conditions.

  • Page 99: Installing The Transducer Dock

    The transducer dock is mounted on the top of the gate valve. The top mating surface is in parallel with the sea surface during normal operating conditions. The transducer dock protects the transducer when the SC90 is not used. Prerequisites This task must take place in dry dock.
  • Page 100 Simrad SC90 Installation Manual It is assumed that the gate valve has been installed. Note The transducer dock is heavy. Always use appropriate lifting equipment to minimize risk of personnel injury or equipment damages. Only certified equipment must be used.

  • Page 101: Installing The Hydraulic Units

    Installing the optional gate valve DN350 Lower the transducer dock carefully onto the gate valve while tightening the nuts. Disconnect and remove the tackles from the transducer dock. Tighten the nuts to torque 472 Nm. 10 Depending on mechanical support provided by the existing decks and/or bulkheads, design, manufacture an install additional mechanical support for the transducer dock.

  • Page 102: Verifying The Quality Of The Gate Valve Installation

    Objects protruding from the hull will generate turbulence and flow noise. This will reduce the SC90 performance. Protruding objects may be zinc anodes, transducers or even the vessel's keel. Holes and pipe outlets are also important noise sources, as well as rough surfaces caused by bad welding.
  • Page 103 Installing the optional gate valve DN350 • If relevant, the hydraulic system has been installed as specified in the relevant documentation. • The hull plating surrounding the mounting flange is even and smooth without protruding objects that can cause noise. •...
  • Page 104 Simrad SC90 Installation Manual Results Requirements All necessary preparations have been made to design and install sufficient support brackets. Date and signature: Further requirements If the inspection reveals errors, inaccuracies or unfortunate dispositions related to units, devices or cables, use the Installation remarks form to document these. If necessary, write a full report, and attach high resolution photos.

  • Page 105: Installing The Optional Gate Valve Dn500

    Installing the optional gate valve DN500 Installing the optional gate valve DN500 Topics About the optional gate valve, page 104 Gate valve system description, page 105 Gate valve installation principles, page 106 Mechanical support brackets, page 107 Installing the mounting flange, page 108 Installing the gate valve, page 113 Installing the transducer dock, page 115 Installing the hydraulic units, page 99...

  • Page 106: About The Optional Gate Valve

    For added protection, a gate valve can then be added to mechanically shut off the bottom of the installation trunk when the SC90 is not used. The gate valve is not manufactured by Kongsberg Maritime.

  • Page 107: Gate Valve System Description

    Installing the optional gate valve DN500 Gate valve system description The gate valve can either be manually operated, or controlled by a hydraulic system. On the manual type, a hand operated wheel is used to open and close the valve. On the hydraulic version, a single button does the same job.

  • Page 108: Gate Valve Installation Principles

    The gate valve is manufactured by LK Valves. Technical information about this unit is not included in this SC90 Installation Manual. Refer to the relevant end-user documentation provided by the manufacturer. 419050/B...

  • Page 109: Mechanical Support Brackets

    The dimensions and strength of the support brackets must be adequate to prevent vortex induced vibration. This a requirement to ensure the safety of the SC90 and the vessel. The forces to which the gate valve,...

  • Page 110: Installing The Mounting Flange

    Simrad SC90 Installation Manual Installing the mounting flange The mounting flange must be mounted so that its top mating surface is in parallel with the sea surface during normal operating conditions. The transducer dock on top of the gate valve must remain vertical during the same conditions.
  • Page 111 Make sure that the hull plating surrounding the mounting flange is even and smooth without protruding objects that can cause noise. Objects protruding from the hull will generate turbulence and flow noise. This will reduce the SC90 performance. If necessary, grind and polish all surfaces.
  • Page 112 Simrad SC90 Installation Manual 10 Verify that the mounting flange has been installed correctly. Inspect the mounting flange. Inspect the installation of the mounting flange, the blister, hull plating and all surfaces thoroughly. Make sure that the mating surface is clean and undamaged, and well protected until the gate valve is mounted.

  • Page 113: Mounting Flange And Manual Gate Valve Installation

    Installing the optional gate valve DN500 Mounting flange and manual gate valve installation This illustration demonstrates the mounting principles for a manual gate valve. The mounting flange and the gate valve are shown. The drawings are not to scale. Frames Knee-plates (stiffeners) Gate valve Knee-plates (stiffeners)

  • Page 114: Mounting Flange And Hydraulic Gate Valve Installation

    Simrad SC90 Installation Manual Mounting flange and hydraulic gate valve installation This illustration demonstrates the mounting principles for a hydraulic gate valve. The mounting flange and the gate valve are shown. The drawings are not to scale. Frames Knee-plates (stiffeners)

  • Page 115: Installation Example

    Installing the optional gate valve DN500 Installation example This illustration demonstrates the mounting principles for a hydraulic gate valve. The mounting flange, gate valve and transducer dock are shown. The drawing is not to scale. Blister Blister (shown 90 degrees) Deflection brackets must only be welded to the shell-plating.
  • Page 116 Simrad SC90 Installation Manual • Anti-seize lubricant • Torque wrench • Lifting arrangement • O-ring • Mounting hardware Note The gate valve is heavy. Appropriate lifting equipment (lifting tackle, portable crane or ship’s crane) is required. Always use appropriate lifting equipment to minimize risk of personnel injury or equipment damages.

  • Page 117: Installing The Transducer Dock

    The transducer dock is mounted on the top of the gate valve. The top mating surface is in parallel with the sea surface during normal operating conditions. The transducer dock protects the transducer when the SC90 is not used. Prerequisites This task must take place in dry dock.
  • Page 118 Simrad SC90 Installation Manual is clean and undamaged, because it must be watertight after the transducer dock has been installed. • The top mating surface of the transducer dock must be protected with a wooden cover at all times until the hull unit is installed. It is very important that this surface is clean and undamaged, because it must be watertight after the hull unit has been installed.

  • Page 119: Installing The Hydraulic Units

    Installing the optional gate valve DN500 Installing the hydraulic units If a hydraulic system has been chosen to control the gate valve operation, additional units must be installed. Prerequisites You must be equipped with a standard set of tools. This tool set must comprise the normal tools for mechanical tasks.

  • Page 120: Verifying The Quality Of The Gate Valve Installation

    Objects protruding from the hull will generate turbulence and flow noise. This will reduce the SC90 performance. Protruding objects may be zinc anodes, transducers or even the vessel's keel. Holes and pipe outlets are also important noise sources, as well as rough surfaces caused by bad welding.
  • Page 121 Installing the optional gate valve DN500 Procedure Write down the key measurements. This is for future reference. Do a close visual inspection of the mounting flange, gate valve and transducer dock, and inspect the way they have been installed. Check the upper surface of the transducer dock to ensure that it is level, undamaged and clean.

  • Page 122: Mounting The Sc90 Installation Trunk

    Simrad SC90 Installation Manual Mounting the SC90 installation trunk Topics About the installation trunk, page 121 Mounting the installation trunk, page 123 Verifying the quality of the installation, page 126 Installation example: Standard type, page 128 Installation example: Oil filled type, page 129...

  • Page 123: About The Installation Trunk

    The installation trunk is not used when a gate valve is mounted. The installation trunk is replaced with a transducer dock. The SC90 Fish finding sonar can be provided with one of the following hull units. Hull Unit Lowering depth...

  • Page 124: Rubber Gasket

    The hull unit gantry must be secured to the bulkhead by means of mechanical support brackets. The dimensions and strength of the support brackets must be adequate to prevent vortex induced vibration. This a requirement to ensure the safety of the SC90 and the vessel.

  • Page 125: Design And Installation Drawings

    If required, all documents provided by the shipyard for the physical installation of the SC90 must be approved by the vessel’s national registry and corresponding maritime authority and/or classification society. Such approval must be obtained before the installation can begin.
  • Page 126 Important In order to obtain optimal SC90 performance, the total height of the installation trunk must be as close as possible to its stated minimum height. The top flange must be parallel to the water line in both the fore-and-aft and athwartship directions.
  • Page 127 Make sure that the hull plating surrounding the trunk is even and smooth without protruding objects that can cause noise. Objects protruding from the hull will generate turbulence and flow noise. This will reduce the SC90 performance. If necessary, grind and polish all surfaces.

  • Page 128: Verifying The Quality Of The Installation

    Objects protruding from the hull will generate turbulence and flow noise. This will reduce the SC90 performance. Protruding objects may be zinc anodes, transducers or even the vessel's keel. Holes and pipe outlets are also important noise sources, as well as rough surfaces caused by bad welding.
  • Page 129 Mounting the SC90 installation trunk Make sure that all surfaces are protected with a high quality coating. Fill in the result tables. Result Horizontal distance from Height from the bottom Total height of the installation the keel to the centre of the...

  • Page 130: Installation Example: Standard Type

    Simrad SC90 Installation Manual Installation example: Standard type The illustration demonstrates the mounting principles for a standard trunk. The drawing is not to scale. All measurements are in mm. The key measurements are: Horizontal distance from the keel to the centre of the...

  • Page 131: Installation Example: Oil Filled Type

    Mounting the SC90 installation trunk Installation example: Oil filled type The illustration demonstrates the mounting principles for an oil filled trunk. The drawing is not to scale. All measurements are in mm. The key measurements are: Horizontal distance from the keel to...

  • Page 132: Mounting The Sc94 Installation Trunk

    Simrad SC90 Installation Manual Mounting the SC94 installation trunk Topics About the installation trunk, page 131 Mounting the installation trunk, page 133 Verifying the quality of the installation, page 126 Installation example: Standard type, page 138 Installation example: Oil filled type, page 139...

  • Page 133: About The Installation Trunk

    The installation trunk is not used when a gate valve is mounted. The installation trunk is replaced with a transducer dock. The SC90 Fish finding sonar can be provided with one of the following hull units. Transducer cable Hull Unit...

  • Page 134: Rubber Gasket

    The hull unit gantry must be secured to the bulkhead by means of mechanical support brackets. The dimensions and strength of the support brackets must be adequate to prevent vortex induced vibration. This a requirement to ensure the safety of the SC90 and the vessel.

  • Page 135: Design And Installation Drawings

    If required, all documents provided by the shipyard for the physical installation of the SC90 must be approved by the vessel’s national registry and corresponding maritime authority and/or classification society. Such approval must be obtained before the installation can begin.
  • Page 136 Important In order to obtain optimal SC90 performance, the total height of the installation trunk must be as close as possible to its stated minimum height. The top flange must be parallel to the water line in both the fore-and-aft and athwartship directions.
  • Page 137 Make sure that the hull plating surrounding the trunk is even and smooth without protruding objects that can cause noise. Objects protruding from the hull will generate turbulence and flow noise. This will reduce the SC90 performance. If necessary, grind and polish all surfaces.

  • Page 138: Verifying The Quality Of The Installation

    Objects protruding from the hull will generate turbulence and flow noise. This will reduce the SC90 performance. Protruding objects may be zinc anodes, transducers or even the vessel's keel. Holes and pipe outlets are also important noise sources, as well as rough surfaces caused by bad welding.
  • Page 139 Mounting the SC94 installation trunk Make sure that all surfaces are protected with a high quality coating. Fill in the result tables. Result Horizontal distance from Height from the bottom Total height of the installation the keel to the centre of the of keel to the top of the trunk (with optional blister) installation trunk...

  • Page 140: Installation Example: Standard Type

    Simrad SC90 Installation Manual Installation example: Standard type The illustration demonstrates the mounting principles for a standard trunk. The drawing is not to scale. All measurements are in mm. The key measurements are: Horizontal distance from the keel to the centre of the...

  • Page 141: Installation Example: Oil Filled Type

    Mounting the SC94 installation trunk Installation example: Oil filled type The illustration demonstrates the mounting principles for an oil filled trunk. The drawing is not to scale. All measurements are in mm. The key measurements are: Horizontal distance from the keel to the centre of the installation trunk: As short a possible...

  • Page 142: Installing The Sc90 Hull Unit

    Installing the SC90 Hull Unit Topics About the hull unit installation, page 141 SC90 Hull unit familiarization, page 147 Unpacking the hull unit from its transport box, page 148 Mounting the hull unit on top of the installation trunk, page 150...
  • Page 143 Installing the SC90 Hull Unit About the hull unit installation The hull unit provided with the SC90 is designed to lower the transducer down below the ship’s hull when the SC90 shall be used. When the SC90 is switched off, the transducer is hoisted for protection.

  • Page 144: Mechanical Support Brackets

    The hull unit gantry must be secured to the bulkhead by means of mechanical support brackets. The dimensions and strength of the support brackets must be adequate to prevent vortex induced vibration. This a requirement to ensure the safety of the SC90 and the vessel.

  • Page 145: Design And Installation Drawings

    If required, all documents provided by the shipyard for the physical installation of the SC90 must be approved by the vessel’s national registry and corresponding maritime authority and/or classification society. Such approval must be obtained before the installation can begin.

  • Page 146: Hull Unit Installation Example: Top View

    This a requirement to ensure the safety of the SC90 and the vessel. If the hull unit is placed on a transducer dock and a gate valve, additional support...

  • Page 147: Hull Unit Installation Example: Side View

    Installing the SC90 Hull Unit Hull unit installation example: Side view The hull unit is located in the sonar room. This example shows a typical sonar room and hull unit seen from the side. The hull unit is mounted on the centre axis of the vessel, on top of the keel.

  • Page 148: Hull Unit Installation Example: Side View

    Simrad SC90 Installation Manual Hull unit installation example: Side view The hull unit is located in the sonar room. This example shows a typical sonar room and hull unit seen from the side. The hull unit is mounted on the side of the keel. A blister is added for streamlining and protection.

  • Page 149: Sc90 Hull Unit Familiarization

    Motor Control Unit. The transducer shaft is supported by the gantry, and penetrates the mounting flange. The complete arrangement is mounted on top of the installation trunk. The SC90 transducer is bolted to the bottom of the transducer shaft. The transducer cables are placed inside the shaft.

  • Page 150: Unpacking The Hull Unit From Its Transport Box

    Simrad SC90 Installation Manual Unpacking the hull unit from its transport The hull unit is delivered in a large wooden transport box. Prerequisites The shipyard must provide all necessary tools and manpower. The following specific items are required for this task: •...
  • Page 151 Installing the SC90 Hull Unit Procedure Remove the top cover of the wooden transport box. Pull out all the nails marked with Indian ink. Remove the support hardware (wooden cradle and support construction). If you wish to reuse the transport box, make sure that you keep all the support hardware used to secure the hull unit.

  • Page 152: Mounting The Hull Unit On Top Of The Installation Trunk

    Simrad SC90 Installation Manual Mounting the hull unit on top of the installation trunk The upper parts of the hull unit include the mechanical gantry, the hoist motor and the Motor Control Unit. The transducer shaft is supported by the gantry, and penetrates the mounting flange.
  • Page 153 Installing the SC90 Hull Unit the transducer surface will allow water to penetrate the transducer. If a leak occurs, the transducer must be replaced. • The top mating surface of the installation trunk must be protected with a wooden cover at all times until the hull unit is installed. It is very important that this surface is clean and undamaged, because it must be watertight after the hull unit has been installed on top of the installation trunk.

  • Page 154: Designing And Mounting Mechanical Support Brackets To Secure The Hull Unit

    The dimensions and strength of the support brackets must be adequate to prevent vortex induced vibration. This a requirement to ensure the safety of the SC90 and the vessel. Prerequisites The shipyard must provide all necessary tools and manpower.
  • Page 155 Installing the SC90 Hull Unit Note The final design and the installation must be approved by the classification society. Without a proper mechanical support for the hull unit gantry, the guarantee will be void! Procedure Locate the two holes provided on the hull unit gantry.

  • Page 156: Hull Unit And Transducer Alignment

    Irrespective of the physical hull unit orientation, the transducer shall not be mechanically aligned. Hull unit alignment is done in the SC90 software by rotating the echo presentation in the display view. This is described in the Setting to work chapter. The alignment is further verified during customer acceptance testing.

  • Page 157: Verifying The Quality Of The Hull Unit Installation

    If you suspect damage, take a high resolution photo. Contact your dealer or the Simrad support organization for advice. Use the hand crank to hoist the transducer. Turn the crank until the transducer is fully retracted.
  • Page 158 Simrad SC90 Installation Manual Make sure that the unit is not physically damaged, and that the paint-work is clean without dents or scratches. The physical handling of the unit during the installation may have caused some minor scratches to the paint-work. This can be accepted. However, if rough handling has caused serious damage to the unit, this must be recorded with a written statement and necessary photos, so that corrective actions can be made.
  • Page 159 Installing the SC90 Hull Unit Results Requirements The sonar room meets all requirements related to insulation, heating and ventilation. The sonar room meets all requirements related to electrical installations, including light, power, communication and cabling. A bilge pump is installed.

  • Page 160: Installing The Sc94 Hull Unit

    Simrad SC90 Installation Manual Installing the SC94 Hull Unit Topics About the hull unit installation, page 159 SC94 Hull unit familiarization, page 164 Unpacking the hull unit from its transport box, page 165 Mounting the hull unit on top of the installation trunk, page 167...

  • Page 161: About The Hull Unit Installation

    Installing the SC94 Hull Unit About the hull unit installation The hull unit provided with the SC90 is designed to lower the transducer down below the ship’s hull when the SC90 shall be used. When the SC90 is switched off, the transducer is hoisted for protection.

  • Page 162: Rubber Gasket

    If required, all documents provided by the shipyard for the physical installation of the SC90 must be approved by the vessel’s national registry and corresponding maritime authority and/or classification society. Such approval must be obtained before the installation can begin.

  • Page 163: Hull Unit Installation Example: Top View

    This a requirement to ensure the safety of the SC90 and the vessel. If the hull unit is placed on a transducer dock and a gate valve, additional support...

  • Page 164: Hull Unit Installation Example: Side View

    Simrad SC90 Installation Manual Hull unit installation example: Side view The hull unit is located in the sonar room. This example shows a typical sonar room and hull unit seen from the side. The hull unit is mounted on the centre axis of the vessel, on top of the keel.

  • Page 165: Hull Unit Installation Example: Side View

    Installing the SC94 Hull Unit Hull unit installation example: Side view The hull unit is located in the sonar room. This example shows a typical sonar room and hull unit seen from the side. The hull unit is mounted on the side of the keel. A blister is added for streamlining and protection.

  • Page 166: Sc94 Hull Unit Familiarization

    Motor Control Unit. The transducer shaft is supported by the gantry, and penetrates the mounting flange. The complete arrangement is mounted on top of the installation trunk. The SC90 transducer is bolted to the bottom of the transducer shaft. The transducer cables are placed inside the shaft.

  • Page 167: Unpacking The Hull Unit From Its Transport Box

    Installing the SC94 Hull Unit Unpacking the hull unit from its transport The hull unit is delivered in a large wooden transport box. Prerequisites The shipyard must provide all necessary tools and manpower. The following specific items are required for this task: •...
  • Page 168 Simrad SC90 Installation Manual Procedure Remove the top cover of the wooden transport box. Pull out all the nails marked with Indian ink. Remove the support hardware (wooden cradle and support construction). If you wish to reuse the transport box, make sure that you keep all the support hardware used to secure the hull unit.

  • Page 169: Mounting The Hull Unit On Top Of The Installation Trunk

    Installing the SC94 Hull Unit Mounting the hull unit on top of the installation trunk The upper parts of the hull unit include the mechanical gantry, the hoist motor and the Motor Control Unit. The transducer shaft is supported by the gantry, and penetrates the mounting flange.
  • Page 170 Simrad SC90 Installation Manual the transducer surface will allow water to penetrate the transducer. If a leak occurs, the transducer must be replaced. • The top mating surface of the installation trunk must be protected with a wooden cover at all times until the hull unit is installed. It is very important that this surface is clean and undamaged, because it must be watertight after the hull unit has been installed on top of the installation trunk.

  • Page 171: Connecting A Ventilation Pipe To The Air Bleeding Cock

    Installing the SC94 Hull Unit Important The transducer is covered with a thick red protective coating made of a special plastic type. The red protective coating is an vital part of the transducer. It is very important that neither this coating nor the internal parts of the transducer are damaged during the handling, installation or cleaning.

  • Page 172: Designing And Mounting Mechanical Support Brackets To Secure The Hull Unit

    The dimensions and strength of the support brackets must be adequate to prevent vortex induced vibration. This a requirement to ensure the safety of the SC90 and the vessel. Prerequisites The shipyard must provide all necessary tools and manpower.

  • Page 173: Hull Unit And Transducer Alignment

    Irrespective of the physical hull unit orientation, the transducer shall not be mechanically aligned. Hull unit alignment is done in the SC90 software by rotating the echo presentation in the display view. This is described in the Setting to work chapter. The alignment is further verified during customer acceptance testing.

  • Page 174: Inspecting The Transducer

    If you suspect damage, take a high resolution photo. Contact your dealer or the Simrad support organization for advice. Use the hand crank to hoist the transducer. Turn the crank until the transducer is fully retracted.

  • Page 175: Verifying The Quality Of The Hull Unit Installation

    Installing the SC94 Hull Unit Remove the hand crank from the stub shaft, and mount it in its storage position in the Motor Control Unit. Result Requirements Results The transducer is new, clean and free from scratches, dents or other physical damage.
  • Page 176 Simrad SC90 Installation Manual Make sure that the bolts, screws or studs holding the unit are of the correct size. Make sure that the correct flat and shake-proof washers have been used. Make sure that all nuts have been tightened properly.
  • Page 177 Installing the SC94 Hull Unit Results Requirements If a gate valve is used, the welds and mechanical brackets that support the mounting flange are strong enough to hold the hull unit securely in place under all operating conditions. The welds and brackets have been painted with the correct preservation medium to prevent corrosion.

  • Page 178: Installing The Sc90 Hardware Units

    Simrad SC90 Installation Manual Installing the SC90 hardware units Topics Installing the display, page 177 Installing the Enix Processor Unit, page 178 Installing the Operating Panel, page 180 Installing the Operating Panel Power Supply, page 182 Installing the Power Supply Unit, page 183...

  • Page 179: Installing The Display

    Installing the SC90 hardware units Installing the display A display is a required part of the SC90 Fish finding sonar. For best readability, the display must be located so that it is protected from glare, and with the correct height and angle.

  • Page 180: Installing The Enix Processor Unit

    Simrad SC90 Installation Manual Related topics Display description, page 22 Minimum display requirements, page 401 Installing the Enix Processor Unit The Processor Unit can be installed inside a console, inside a suitable cabinet, in a 19" rack or on a desk. When mounted on a horizontal foundation, for example inside a cabinet, rack or console, use the bottom plate with the two base rails.
  • Page 181 Installing the SC90 hardware units Make sure that enough space is made available for maintenance purposes. Make sure that adequate ventilation is available to avoid overheating. Make sure that the installation method allows for the physical vibration, movements and forces normally experienced on a vessel.

  • Page 182: Installing The Operating Panel

    The Operating Panel contains all necessary control functions for normal operation of the SC90. The Operating Panel is normally placed on the bridge near the display. The length of the cables limit the physical distance between the Operating Panel and the Processor Unit.

  • Page 183: Operating Panel Cut-Out Drawing

    Installing the SC90 hardware units Drill and cut the panel opening as shown in the illustration. Mount the Operating Panel using the supplied hardware. The necessary mounting hardware (four screws, four nut plates and four bolt covers) are supplied in the standard delivery.

  • Page 184: Installing The Operating Panel Power Supply

    Simrad SC90 Installation Manual Installing the Operating Panel Power Supply A small commercial power supply is used to provide stand-by power to the SC90 Operating Panel. The Operating Panel Power Supply must be placed on the bridge close to the Processor Unit. The length of the cable limits the physical distance between the power supply and the Processor Unit.

  • Page 185: Installing The Power Supply Unit

    Installing the SC90 hardware units Installing the Power Supply Unit The purpose of the Power Supply Unit is to provide the SC90 Transceiver Unit with the necessary DC power for operation. The Power Supply Unit must be mounted on the bulkhead close to the Transceiver Unit.

  • Page 186: Installing The Transceiver Unit

    422321 Power Supply Unit dimensions, page 447 Installing the Transceiver Unit The SC90 Transceiver Unit is normally positioned close to the hull unit. It can also be installed in a dedicated compartment. The physical length of the transducer cable limits the distance between the hull unit and the Transceiver Unit.
  • Page 187 Note If required, all documents provided by the shipyard for the physical installation of the SC90 must be approved by the vessel’s national registry and corresponding maritime authority and/or classification society. Such approval must be obtained before the installation can begin. The shipowner and shipyard doing the installation are responsible for obtaining and paying for such approval.
  • Page 188 Simrad SC90 Installation Manual • Make sure that adequate ventilation is available to avoid overheating. • Make sure that the installation method allows for the physical vibration, movements and forces normally experienced on a vessel. Make sure that the chosen location meets the installation requirements.

  • Page 189: Location Of The Mounting Brackets

    Installing the SC90 hardware units Location of the mounting brackets Deckhead Bulkhead Deck Angle bars with threaded holes for shock absorbers. These bars are supplied by Kongsberg Maritime. 419050/B...

  • Page 190: Installation Of The Mounting Brackets

    Simrad SC90 Installation Manual Installation of the mounting brackets Deckhead Bulkhead Deck Angle bars with threaded holes for shock absorbers. These bars are supplied by Kongsberg Maritime. 419050/B...

  • Page 191: Connecting The Transceiver Unit To Vessel Ground

    Installing the SC90 hardware units Connecting the Transceiver Unit to vessel ground Upper shock absorber Transceiver Unit cabinet Cabinet door Grounding cable Grounding cable, detail 419050/B...

  • Page 192: Cable Layout And Interconnections

    Installing the SC90 cables, page 198 Processor Unit graphic adapter, page 208 Processor Unit serial adapter, page 210 Serial line splitters, page 213 Setting up the SC90 in a synchronized system, page 222 Cable drawings and specifications, page 228 Basic cable requirements, page 257 419050/B...

  • Page 193: Read This First

    : These cables may be provided by Kongsberg Maritime as a Commercial cables part of the SC90 delivery. They may also be included with third party items that are used with the SC90. All electronic installations and corresponding wiring must be in accordance with the vessel's national registry and corresponding maritime authority and/or classification society.

  • Page 194: Topside Cable Plan

    You must use CAT-5E STP (Shielded Twisted Pair) quality or better. Using a cable with lower bandwidth capacity will reduce the SC90 performance. Do not connect the Processor Unit to the Transceiver Unit using an existing local area network (LAN).

  • Page 195: Sonar Room Cable Plan

    List of SC90 cables, page 195 Sonar room cable plan The sonar room cables include those used to connect the SC90 units to AC mains power, as well as the control cables between the units. One high capacity Ethernet cable connects the Transceiver Unit to the topside Processor Unit.
  • Page 196 Simrad SC90 Installation Manual Related topics Topside cable plan, page 192 Sonar room cable plan, page 193 List of SC90 cables, page 195 419050/B...

  • Page 197: List Of Sc90 Cables

    Cable layout and interconnections List of SC90 cables A set of cables is required to connect the SC90 units to each other, and to the relevant power source(s). Additional cables are required to connect the SC90 to peripheral devices. Topside cables...
  • Page 198 Simrad SC90 Installation Manual Type Cable From/To Minimum requirements Control cable From Processor Unit to Operating Panel This is a standard commercial USB data cable. It has a quadratic USB connector in the Operating Panel end (B-plug), and rectangular USB connector in the Processor Unit end (A-plug).
  • Page 199 To identify these cables, use postfix letters. (C13A, C13B, C13C...). The SC90 is often a part of a project delivery. For such deliveries, specific project cable drawings are established to show all the main cables, and how the various products are connected.

  • Page 200: Installing The Sc90 Cables

    Refer to the cable plans and the list of cables. Detailed information about cable specifications, termination and connectors are provided in the relevant cable drawings. Unless otherwise specified, all cables are provided with the SC90 delivery. In order to ease the access for maintenance purposes, and to allow for vibration, make sure that some slack is provided for each cable.

  • Page 201: Installing The Sc90 Topside Cables

    Installing the SC90 cables, page 198 Installing the SC90 topside cables The topside/bridge cables include those used to connect the SC90 Processor Unit (computer) and the display to each other, to AC mains power, and to external devices. One high capacity Ethernet cable connects the Processor Unit to the Transceiver Unit.
  • Page 202 It is very important that a high quality Ethernet cable is used. You must use CAT-5E STP (Shielded Twisted Pair) quality or better. Using a cable with lower bandwidth capacity will reduce the SC90 performance. Do not connect the Processor Unit to the Transceiver Unit using an existing local area network (LAN).
  • Page 203 Processor Unit rear connectors (Enix 3820), page 204 Installing the SC90 cables, page 198 Processor Unit serial adapter, page 210 Serial line splitters, page 213 Basic cable requirements, page 257 Setting up the SC90 in a synchronized system, page 222 419050/B...

  • Page 204: Installing The Sc90 Sonar Room Cables

    Simrad SC90 Installation Manual Installing the SC90 sonar room cables The sonar room cables include those used to connect the SC90 units to AC mains power, as well as the control cables between the units. One high capacity Ethernet cable connects the Transceiver Unit to the topside Processor Unit.
  • Page 205 DO NOT connect the transceiver plug to the socket on the Transceiver Unit. Note This connection is made as a part of the Setting to work procedures. Related topics Transceiver Unit connectors, page 206 Power Supply Unit connectors, page 207 Installing the SC90 cables, page 198 Basic cable requirements, page 257 419050/B...

  • Page 206: Processor Unit Rear Connectors (Enix 3820)

    Simrad SC90 Installation Manual Processor Unit rear connectors (Enix 3820) The rear panel on the Processor Unit holds connectors for the various SC90 cables. Additional connectors are provided on the front panel. These are not used. Control cable: From Processor Unit to Operating Panel (C10, C11) A dedicated serial line cable is used to connect the Operating Panel to the Processor Unit.
  • Page 207 Ground cable: From Processor Unit to vessel ground (C6) AC power cable: From Processor Unit to uninterruptible power supply (UPS) (C3) Audio cable: Not used Related topics Installing the SC90 topside cables, page 199 Installing the SC90 cables, page 198 419050/B...

  • Page 208: Transceiver Unit Connectors

    DO NOT connect the transceiver plug to the socket on the Transceiver Unit. This connection is made as a part of the Setting to work procedures. Related topics Installing the SC90 sonar room cables, page 202 Installing the SC90 cables, page 198 419050/B...

  • Page 209: Power Supply Unit Connectors

    AC power cable: From Power Supply Unit to uninterruptible power supply (UPS) (C24) Ground cable: From Power Supply Unit to vessel ground (C30) Related topics Installing the SC90 sonar room cables, page 202 Installing the SC90 cables, page 198 419050/B...

  • Page 210: Processor Unit Graphic Adapter

    Simrad SC90 Installation Manual Processor Unit graphic adapter The graphic adapter used by the Enix Processor Unit is the manufactured by ER93F TUL Embedded. Description The manufacturer’s website offers the following description of the ER39F graphic adapter. The ER93F Graphic Card is provided with...
  • Page 211 Cable layout and interconnections Graphic output formats The outputs from the graphic adapters are positioned as follows: DisplayPort output DisplayPort output HDMI output DVI-I output DVI-D output Note The two DVI outputs are not identical. If you wish to connect a standard VGA display using a DVI-to-VGA adapter, you must use the left output (D).

  • Page 212: Processor Unit Serial Adapter

    Simrad SC90 Installation Manual Processor Unit serial adapter serial adapter board is used in the SC90 Processor Unit to provide Moxa CP114EL-I serial communication. Topics Moxa CP114EL-I overview, page 210 Moxa CP114EL-I connectors, page 211 Setting up the Moxa CP114EL-I serial ports in Windows XP, page 212 Moxa CP114EL-I overview The Processor Unit is equipped with a Moxa CP114EL-I serial adapter board.

  • Page 213: Moxa Cp114El-I Connectors

    The serial lines are connected using a large D-connector on the rear side of the Processor Unit cabinet. Adapter A dedicated adapter cable is provided with the SC90 delivery. It splits the large front mounted connector to four 9–pin D-connectors. To make the individual connections...

  • Page 214: Setting Up The Moxa Cp114El-I Serial Ports In Windows Xp

    Simrad SC90 Installation Manual Setting up the Moxa CP114EL-I serial ports in Windows XP The interface ports provided by the serial adapter board are configured Moxa CP114EL-I using a dedicated driver application in Windows XP. Context This dedicated software utility is incorporated in the device driver, and you can access it from the operating system’s...

  • Page 215: Serial Line Splitters

    One or more serial line splitters are then used to distribute the information from a single sensor to several different recipients. The following serial line splitters are often used on SC90 installations. • Øverland UPC-3005 • Øverland UPC-5000P...

  • Page 216: Øverland Upc-3005 Serial Line Splitter Description

    Simrad SC90 Installation Manual Øverland UPC-3005 Serial line splitter description The Øverland UPC-3005 is a serial line splitter with one input and eight outputs. UPC 3005 is a serial line splitter with 1 signal input, 3 x RS-232 and 5 x RS-422 outputs.

  • Page 217: Øverland Upc-3005 Technical Specifications

    Cable layout and interconnections Øverland UPC-3005 Technical specifications The Øverland UPC-3005 serial line splitter offers one input and eight RS-232 and RS-422 outputs. • : +15 - 30 VDC (2 W) Power requirements • : NMEA0183, RS-232, RS422, Input RS484, Current loop •...

  • Page 218: Øverland Upc-3005 Connections

    Simrad SC90 Installation Manual Øverland UPC-3005 Connections The Øverland UPC-3005 serial line splitter offers one input and eight RS-232 and RS-422 outputs. The serial line splitter requires a dedicated power supply providing 15 to 30 VDC. Power requirements: +15 - 30 VDC...

  • Page 219: Øverland Upc-3005 Dimensions

    Cable layout and interconnections Øverland UPC-3005 Dimensions 419050/B...

  • Page 220: Øverland Upc-5000P Serial Line Splitter Description

    Simrad SC90 Installation Manual Øverland UPC-5000P Serial line splitter description The Øverland UPC-5000P is a serial line splitter with two separate inputs and fifteen outputs. Dual power input with autoswitch. The two inputs A and B are separated with A as the primary input. If there is data on both A and B inputs, input A is used.

  • Page 221: Øverland Upc-5000P Technical Specifications

    Cable layout and interconnections Øverland UPC-5000P Technical specifications The Øverland UPC-5000P serial line splitter offers two separate inputs and fifteen RS-232 and RS-422 outputs. • Power requirements – Primary +15 - 30 VDC (2 W) – Secondary +15 - 30 VDC (2 W) •...

  • Page 222: Øverland Upc-5000P Connections

    Simrad SC90 Installation Manual Øverland UPC-5000P Connections The Øverland UPC-5000P serial line splitter offers two separate inputs and fifteen RS-232 and RS-422 outputs. The serial line splitter requires a dedicated power supply providing 15 to 30 VDC. Outputs: 5 x RS-232...

  • Page 223: Øverland Upc-5000P Dimensions

    Cable layout and interconnections Øverland UPC-5000P Dimensions 419050/B...

  • Page 224: Setting Up The Sc90 In A Synchronized System

    April 2016 The Simrad SC90 may be set up to be synchronized with other hydroacoustic instruments. Synchronization is necessary to prevent several hydroacoustic systems from transmitting simultaneously. Individual transmission is often a necessity to prevent interference.

  • Page 225: Synchronization Modes

    Cable layout and interconnections Synchronization modes The purpose of the synchronization modes are to set up the SC90 to operate alone, or as a "master" or "slave" in a synchronized system. Whenever more than one hydroacoustic system is installed on a vessel, interference may occur. To avoid this, you have these options: •...

  • Page 226: Synchronization Using Clear To Send (Cts) And Request To Send (Rts) Signals

    When the SC90 is set up in Slave mode, it must receive a trigger signal from a peripheral system every time the SC90 shall transmit. This trigger signal is connected to a serial port on the Processor Unit, and the Clear To Send (CTS) pin is used to give the SC90 an 419050/B...

  • Page 227: Selecting Synchronization Port

    Send (RTS) outputs on the "Slave" systems can not be connected. Selecting synchronization port If you wish to use the SC90 as a master or slave in a synchronized system, you must set it up for such operation. To do this, you must select which communication port to use for the synchronization interface, and you must select the requested synchronization mode.

  • Page 228: Selecting Synchronization Mode

    Installation Menu Selecting synchronization mode If you wish to use the SC90 as a master or slave in a synchronized system, you must set it up for such operation. To do this, you must select which communication port to use for the synchronization interface, and you must select the requested synchronization mode.
  • Page 229 • One of the acoustic systems is set up as "master", and controls the transmissions on the other systems. The SC90 offers functionality for remote transmit synchronisation. It can be set up to operate in either Master or Slave mode.

  • Page 230: Cable Drawings And Specifications

    RJ45 High speed Ethernet cable (From Processor Unit to Transceiver Unit), page 240 K-Sync interface to generic RS-232 synchronization input, page 241 Simrad TU40 interface to generic RS-232 synchronization input, page 243 Communication and power cable for the Operating Panel, page 245...

  • Page 231: Ac Power Cable Using Iec C13 Inline Socket

    Cable layout and interconnections AC power cable using IEC C13 inline socket This cable is used to connect any unit or device to AC mains supply. It is commercial, and normally used for 115 and 230 VAC. The inline socket and plug comply to the IEC60320 standard.
  • Page 232 Simrad SC90 Installation Manual Minimum cable requirements • : 2 x 1.5 mm² + Ground Conductors • : None Screen • : 750 V Voltage • : Defined by the plugs and/or the cable gland Maximum outer diameter Related topics...

  • Page 233: Ground Cable

    Cable layout and interconnections Ground cable Correct grounding is essential for safe operation and maximum performance. Ground tag on unit Vessel ground The ground connection is made using a thick stranded (or yellow/green) cable making a solid connection between the cabinet and the bulkhead. It is normally provided with a green/yellow colour.

  • Page 234: Rs-232 Serial Line Connection Using Three Wires

    Simrad SC90 Installation Manual RS-232 serial line connection using three wires An RS-232 serial line connection using three (3) wires and NMEA datagrams is a common way to connect the SC90 to external devices. Local connection Connection on remote device...

  • Page 235: Rs-232 Serial Line Connection Using Five Wires

    Cable layout and interconnections RS-232 serial line connection using five wires An RS-232 serial line connection using five (5) wires and NMEA datagrams is a common way to connect the SC90 to external devices. Local connection Connection on remote device...

  • Page 236: Serial Line Connection Using Five Wires

    Simrad SC90 Installation Manual RS-422 serial line connection using five wires An RS-422 serial line connection can transmit data at rates as high as 10 million bits per second, and may be sent on cables as long as 1500 meters.

  • Page 237: Used As Synchronization Trigger (Input Or Output)

    RS-232 used as synchronization trigger (input or output) An RS-232 serial line connection using the Request To Send (RTS) and Clear To Send (CTS) signals is common way to connect the SC90 to external devices for synchronization purposes. Local connection...

  • Page 238: Rs-485 Serial Line Connection Using Two Or Four Wires

    RS-485 serial line connection using two or four wires An RS-485 serial line connection using two or four wires is common way to connect the SC90 to external devices. This format is recommended if the serial cable needs to be very long.

  • Page 239: Moxa Cp114El-I Serial Line Adapter

    Cable layout and interconnections Moxa CP114EL-I Serial line adapter The Processor Unit is equipped with a Moxa CP114EL-I serial adapter board. The board provides four serial lines. The serial lines are connected using a large D-connector on the rear side of the Processor Unit cabinet. The Moxa CP114EL-I serial adapter supports RS-232, RS-422 and RS-485 (both 2 and 4-wire).
  • Page 240 Simrad SC90 Installation Manual Pin assignments Moxa CP114EL-I 9-pin D-connector converter RS-232 RS-422 RS485 (4–wire) RS485 (2–wire) TXD-(A) TXD-(A) TXD+(B) TXD+(B) RXD+(B) RXD+(B) Data-(B) RXD-(A) RXD-(A) Data-(A) Minimum cable requirements • : 2 x 5 x 0.5 mm² Conductors •...

  • Page 241: Rj45 High Speed Ethernet Cable (1000Base-T)

    Cable layout and interconnections RJ45 High speed Ethernet cable (1000Base-t) Most high speed data connections between the SC90 system units are made using Ethernet cables. These cables may also be used between the SC90 and peripheral equipment. Local Ethernet connection...

  • Page 242: Rj45 High Speed Ethernet Cable

    You must use CAT-5E quality or better. Using cables with lower bandwidth capacity will reduce the SC90 performance. Do not connect the Processor Unit to the Transceiver Unit using an existing local area network (LAN).

  • Page 243: K-Sync Interface To Generic Rs-232 Synchronization Input

    Cable layout and interconnections Related topics Cable drawings and specifications, page 228 K-Sync interface to generic RS-232 synchronization input For transmission synchronization purposes, the K-Sync will interface a generic RS-232 serial line communication port using the CTS (Clear To Send) and RTS (Request To Send) signals.
  • Page 244 Simrad SC90 Installation Manual Connectors 1 through 6 as indicated by the arrows. Note that each of the two connector elements can be pulled out of the IO Module for easy access. Configuration board Unless otherwise specified, this cable must be provided by the installation shipyard.

  • Page 245: Simrad Tu40 Interface To Generic Rs-232 Synchronization Input

    Cable layout and interconnections Simrad TU40 interface to generic RS-232 synchronization input For transmission synchronization purposes, the Simrad TU40 will interface a generic RS-232 serial line communication port using the CTS (Clear To Send) and RTS (Request To Send) signals.
  • Page 246 Simrad SC90 Installation Manual Screen (Cable screen) (Green) Make the connections here. Channels (From left) The default version of the Trigger Unit has eight channels to control eight hydroacoustic systems. Optionally, the Trigger Unit can control up to 12 hydroacoustic systems.

  • Page 247: Communication And Power Cable For The Operating Panel

    The cable length is 4.5 meters. It can not be extended. A spare cable be ordered using part number 380–202101. Minimum cable requirements Not applicable. The cable is supplied with the SC90 delivery. Related topics Cable drawings and specifications, page 228...

  • Page 248: Dc Power Cable From Power Supply Unit To Transceiver Unit

    Simrad SC90 Installation Manual DC power cable from Power Supply Unit to Transceiver Unit A dedicated power cable is used to connect the DC power from the Power Supply Unit to the Transceiver Unit. This cable is provided fixed to the Power Supply Unit.

  • Page 249: Ethernet Cable With Noise Suppressor From Transceiver Unit To Motor Control Unit

    Motor Control Unit. • : 9.7 meters Length • : 338859 Part number Minimum cable requirements Not applicable. The cable is supplied with the SC90 delivery. Related topics Cable drawings and specifications, page 228 419050/B...

  • Page 250: Ethernet Cable With Noise Suppressor From Transceiver Unit To Power Supply Unit

    Simrad SC90 Installation Manual Ethernet cable with noise suppressor from Transceiver Unit to Power Supply Unit One Ethernet cable connects the Transceiver Unit to the Power Supply Unit. In order to reduce the electrical noise, a noise suppressor device is fitted to the Ethernet cable.

  • Page 251: Ac Mains Power Cable (3-Phase) To The Motor Control Unit

    Cable layout and interconnections AC mains power cable (3-phase) to the Motor Control Unit A dedicated power cable is required to connect 3-phase mains supply and ship’s ground to the hoisting motor on the hull unit. The connections are made to the Motor Control Unit.

  • Page 252: Emergency Hoist Connections

    Simrad SC90 Installation Manual Emergency hoist connections Emergency hoist functionality is provided by the Hull Unit Control circuit board in the Motor Control Unit. We does not offer any optional products or kits to put this functionality to use. In order to use the emergency hoist functionality you will need to design your own interface and switch box.
  • Page 253 Cable layout and interconnections an immediate hoist pulse to the motor. Simultaneously, optocoupler U2 will be opened, and the suggested LED on pin 1 will be lit to indicate that the transducer is hoisted. Minimum cable requirements • : 4 x 0.75 mm² Conductors •...

  • Page 254: Connection Between The Gate Valve And The Motor Control Unit

    Simrad SC90 Installation Manual Connection between the gate valve and the Motor Control Unit This connection is only required if the optional hydraulic gate valve is installed. This interface prevents the transducer to be lowered while the gate valve is closed. It also prevents the gate valve from closing when the transducer is lowered.
  • Page 255 Cable layout and interconnections The gate valve is manufactured by LK Valves. For more detailed information about the gate valve and the Gate Valve Control Unit, refer to the technical documentation provided by the manufacturer. How it works When the gate valve is open, the limit switch "NC" on the is also open. Once the gate valve leaves the "open position"...

  • Page 256: About Serial Lines

    Simrad SC90 Installation Manual About serial lines A preferred method to establish communication between the SC90 and peripheral devices, is by means of serial lines. Several serial line standards are available, each with different qualities. Unless otherwise specified, these cables must be provided by the installation shipyard.
  • Page 257 Cable layout and interconnections Note There are no common standard for RS-422 pin configuration. Any manufacturer may choose their own connector pins for the various signals used. In order to make the RS-422 connection to your peripheral device work properly, you must always consult the relevant instructions provided by the device manufacturer.
  • Page 258 RS-485 serial line connection using two or four wires, page 236 Moxa CP114EL-I Serial line adapter, page 237 K-Sync interface to generic RS-232 synchronization input, page 241 Simrad TU40 interface to generic RS-232 synchronization input, page 243 Cable drawings and specifications, page 228 419050/B...

  • Page 259: Basic Cable Requirements

    Cable layout and interconnections Basic cable requirements It is very important that all systems cables are installed correctly. All cables must be properly supported and protected, and all relevant precautions must be made to prevent unwanted noise. Topics Cable trays, page 257 Radio frequency interference, page 258 Physical protection of cables, page 258 Grounding of system cables, page 259...

  • Page 260: Radio Frequency Interference

    Simrad SC90 Installation Manual conduit or duct). When this is impractical, the cables must be carefully arranged such that the maximum temperature expected in any cable in the group is within the specifications of the lowest-rated cable. Cables with protective coverings which may damage other cables should not be grouped with other cables.

  • Page 261: Grounding Of System Cables

    Cable layout and interconnections Grounding of system cables All metallic cable coverings (armour, metallic sheathing and other protection) must be electrically connected to the vessel's hull at both ends except in the case of final sub-circuits where they should be connected at the supply end only. Grounding connections should be made using a conductor which has a cross-sectional area appropriate for the current rating of the cable, or with a metal clamp which grips the metallic covering of the cable and is bonded to the hull of the vessel.

  • Page 262: Cable Glands And Termination Procedures

    Simrad SC90 Installation Manual Cable glands and termination procedures Cable glands are used to attach and secure the end of a cable to the equipment. Cable glands may also be used for sealing cables passing through bulkheads or gland plates.
  • Page 263 Cable glands are used whenever a cable passes through a watertight bulkhead or into a cabinet, to seal the opening through which the cable passes and to protect the cable from abrasion on the edges of the hole. The cable glands are not supplied with the SC90. Note There are many different types of cable gland on the market.
  • Page 264 Simrad SC90 Installation Manual Leaving an appropriate length of the screen exposed from the insulation, cut off the remainder. Securing and terminating cables Once a cable has been prepared for termination, it must be connected to a unit or cabinet.
  • Page 265 Cable layout and interconnections Using multi-diameter cable sealing Cable sealing systems are available from several manufacturers, and multi-diameter types are becoming increasingly popular due to their ease of use. Prerequisites Electrical installations can only be done by certified electricians. All necessary tools and instruments required must be available.
  • Page 266 Simrad SC90 Installation Manual Illustration: Roxtec steps (Image from Roxtec website) The Roxtec system is available with a large number of various modules and compression units. The system complies with current screening and EMC requirements. Procedure Cut an opening in the structure (bulkhead, cabinet etc) you wish to penetrate.

  • Page 267: Setting To Work

    Testing the interfaces with peripheral devices, page 363 Verifying the installation parameters, page 371 Creating a backup with the SC90 configuration and software installation, page 383 Installation remarks, page 388 Opening the BITE (Built-In Test Equipment) dialog box, page 388...

  • Page 268: Setting To Work Summary

    You must never start SC90 transmissions ("pinging") when the ship is in dry dock. The transducer may be damaged if it transmits in open air. It is therefore very important that the SC90 system remains switched off when the vessel is in dry dock, and that no one tries to use it.
  • Page 269 Configure the SC90 for operational use by inserting the relevant installation parameters. To allow the SC90 to provide correct data, you must define and insert the location of each navigation and motion sensor, as well as the location of the transducer. Do this as accurately as possible.

  • Page 270: Inspecting The Sc90 Installation

    Environmental inspection of the Transceiver Unit, page 279 Verifying that all SC90 cables are properly connected, page 280 Visual inspection of the display A visual inspection of the SC90 display is required to verify that the unit has not been physically damaged during the installation. Prerequisites The SC90 is installed as specified in this manual.
  • Page 271 Setting to work Make sure that ample space is provided around the unit to allow for maintenance and replacement of parts. Make sure that the bolts, screws or studs holding the unit are of the correct size. Make sure that the correct flat and shake-proof washers have been used. Make sure that all nuts have been tightened properly.

  • Page 272: Visual Inspection Of The Processor Unit

    Simrad SC90 Installation Manual Visual inspection of the Processor Unit A visual inspection of the SC90 Processor Unit is required to verify that the unit has not been physically damaged during the installation. Prerequisites The SC90 is installed as specified in this manual. The SC90 is turned off. You need the following equipment: •...

  • Page 273: Visual Inspection Of The Operating Panel

    A visual inspection of the Operating Panel is required to verify that the unit has not been physically damaged during the installation.. Prerequisites The SC90 is installed as specified in this manual. The SC90 is turned off. You need the following equipment: • Multimeter...

  • Page 274: Visual Inspection Of The Transceiver Unit

    A visual inspection of the Transceiver Unit is required to verify that the unit has not been physically damaged during the installation. Prerequisites The SC90 is installed as specified in this manual. The SC90 is turned off. You need the following equipment: • Multimeter...
  • Page 275 Setting to work Procedure Make sure that the Transceiver Unit is installed in the correct location, and that it is suitably oriented for easy maintenance and replacement of parts. Make sure that the Transceiver Unit is fully populated with all circuit boards and modules mounted.

  • Page 276: Visual Inspection Of The Power Supply Unit

    A visual inspection of the Power Supply Unit is required to verify that the unit has not been physically damaged during the installation. Prerequisites The SC90 is installed as specified in this manual. The SC90 is turned off. You need the following equipment: • Multimeter...
  • Page 277 Setting to work Make sure that the cabinet door can be fully opened for unrestricted access. Make sure that the bolts, screws or studs holding the unit are of the correct size. Make sure that the correct flat and shake-proof washers have been used. Make sure that all nuts have been tightened properly.

  • Page 278: Visual Inspection Of The Hull Unit

    It is also important to check that the unit has been installed correctly. Prerequisites The SC90 is installed as specified in this manual. The SC90 is turned off. You need the following equipment: • Multimeter...

  • Page 279: Inspecting The Transducer

    Setting to work Repeat the inspection of the transducer cables when the SC90 is turned on and put to operational use. Make sure that the unit is firmly connected to vessel ground. Make sure that the unit is securely connected to the vessel ground with an earthing strap.
  • Page 280 If you suspect damage, take a high resolution photo. Contact your dealer or the Simrad support organization for advice. Use the hand crank to hoist the transducer. Turn the crank until the transducer is fully retracted.

  • Page 281: Environmental Inspection Of The Transceiver Unit

    Transceiver Unit. An environmental inspection of the Transceiver Unit is required to verify the quality of the sonar room. Prerequisites The SC90 is installed as specified in this manual. You need the following equipment: • Thermometer • Hygrometer Context The sonar room is the compartment in which the Transceiver Unit is installed.

  • Page 282: Verifying That All Sc90 Cables Are Properly Connected

    Before you can do this task, the following prerequisites must be met: • The SC90 is installed as specified in this manual. • The SC90 has been set up with its hardware units connected as specified in this manual. • All system cables are installed.
  • Page 283 Setting to work Procedure For each cable that is in used on the SC90: Make sure that the cable has been installed as specified in the Cable layout and interconnections chapter. Note Pay special attention to signal cables. These must not be installed too close to power cables.

  • Page 284: Starting Up The Hull Unit

    Removing trapped air from the installation trunk (SC90), page 297 Hull unit description The hull unit provided with the SC90 is designed to lower the transducer down below the ship’s hull when the SC90 shall be used. When the SC90 is switched off, the transducer is hoisted for protection.
  • Page 285 Note If you forget to hoist the transducer before the SC90 is switched off, the transducer is hoisted automatically before the power is disconnected. The transducer is also hoisted automatically if a serious malfunction occurs to the communication between the bridge and the hull unit.
  • Page 286 Related topics Basic items provided with a standard delivery, page 32 System units, page 22 Installing the SC90 Hull Unit, page 140 Installing the SC94 Hull Unit, page 158 Technical specifications, page 391 413125 Hull Unit dimensions SC90, page 449...

  • Page 287: Sc90 Hull Unit Familiarization

    Motor Control Unit. The transducer shaft is supported by the gantry, and penetrates the mounting flange. The complete arrangement is mounted on top of the installation trunk. The SC90 transducer is bolted to the bottom of the transducer shaft. The transducer cables are placed inside the shaft.

  • Page 288: Sc94 Hull Unit Familiarization

    Motor Control Unit. The transducer shaft is supported by the gantry, and penetrates the mounting flange. The complete arrangement is mounted on top of the installation trunk. The SC90 transducer is bolted to the bottom of the transducer shaft. The transducer cables are placed inside the shaft.

  • Page 289: Motor Control Unit Familiarization

    The purpose of the Motor Control Unit is to control the hoisting motor on the hull unit. When you make the appropriate commands on the SC90 sonar, the Motor Control Unit will start and stop the motor. It will also make sure that the motor rotates the correct way.

  • Page 290: Initial Safety Check Of The Motor Control Unit

    High voltages are used. The initial settings must be verified before the Hull Unit can be started for the first time. Prerequisites • The SC90 is turned off. • The circuit breaker for the 3-phase AC power is disengaged. • All cable connections are made.

  • Page 291: Connecting The 3-Phase Ac Power To The Motor Control Unit

    The electric hoisting motor on the hull unit requires 3-phase AC power for operation. The AC power is connected to terminal block E301 inside the Motor Control Unit. Prerequisites • The SC90 is turned off. • The circuit breaker for the 3-phase AC power is disengaged.
  • Page 292 Simrad SC90 Installation Manual Adjust the release current on the (S301) according to the Motor Protecting Switch 3-phase voltage in use. Hull Unit SC90: • 230 VAC: 5.5 A (Maximum) • 380/440 VAC: 4 A Hull Unit SC94: • 230 VAC: 10 A (Maximum) •...

  • Page 293: Checking The 3-Phase Connection For Correct Rotation

    3-phase AC power connections are wrong with respect to the motor's rotational direction. Prerequisites • The SC90 is turned off. • The circuit breaker for the 3-phase AC power is closed. AC power is connected.
  • Page 294 Simrad SC90 Installation Manual Locate terminal block E301 at the bottom of the Motor Control Unit. Reverse two of the three 3-phase cable connections. To apply power, close the circuit breaker for the 3-phase AC voltage. Verify that LED on the front of the (K303) is lit.

  • Page 295: Checking The Operation Of The Hoisting And Lowering Contactors

    Prerequisites Before you can do this task, the following prerequisites must be met: • The SC90 is turned off. • The circuit breaker for the 3-phase AC power is closed. AC power is connected. • The transducer is in its upper...
  • Page 296 Simrad SC90 Installation Manual • The (S305) must be deactivated (with the transducer in upper Lower Limit Switch position or on its way down). • The (S203) must be closed with the hand crank in its storage Hand Crank Switch position.

  • Page 297: Checking The Transducer Lowering And Hoisting Functionality

    Control Unit. Prerequisites Before you can do this task, the following prerequisites must be met: • The SC90 is turned off. • The circuit breaker for the 3-phase AC power is closed. AC power is connected. • The transducer is in its upper...
  • Page 298 Simrad SC90 Installation Manual Locate (S302). Set the switch to position LOWER. Hoist/Lower Switch Locate the (S303). Hand Crank Safety Switch Check the training direction of the hoisting motor by very briefly pressing the Hand (S303). Crank Safety Switch If the transducer was hoisted: To disconnect power, disengage the circuit breaker for the 3-phase AC voltage.

  • Page 299: Removing Trapped Air From The Installation Trunk (Sc90)

    Date and signature: Removing trapped air from the installation trunk (SC90) Once the vessel is set afloat after the SC90 installation, the installation trunk will contain trapped air. During normal use, the installation trunk will be filled with air due to the laminar flow and the air bubble in the water.

  • Page 300: Turning On The Sc90 For The First Time

    Turning on the SC90 for normal use, page 311 Verifying that operational power is correct The SC90 operates on AC power from the vessel’s mains supply. Before you apply AC power to any SC90 unit, you must verify the power is correct.

  • Page 301: Powering Up The Processor Unit For The First Time

    SC90. Powering up the Processor Unit for the first time To turn on the SC90 for the first time, you must first turn on the Processor Unit. Prerequisites The SC90 is installed as specified in the SC90 Installation manual. All cables are properly connected.

  • Page 302: Turning On The Transceiver Unit For The First Time

    Turning on the Transceiver Unit for the first time To turn on the SC90 for the first time, you must first turn on the Processor Unit. When the Processor Unit and the SC90 software is up and running, you can turn on the Transceiver Unit.

  • Page 303: Measuring The Echo Level With The Transducer Disconnected From The Transceiver Unit

    Low noise is a key factor for high quality and reliable measurements. The performance of the SC90 will always be limited by different noise sources. A high noise level will mask the echoes and make them difficult to read and interpret. The noise is measured while the SC90 operates in Passive mode with the transducer disconnected.
  • Page 304 Echo Level System Test Adjust the until the echoes on the images on the SC90 presentation are Gain dynamic, and you can distinguish between the individual echoes. Read the current echo level displayed by the "button".

  • Page 305: Measuring The Bite Noise With The Transducer Disconnected From The Transceiver Unit

    Low noise is a key factor for high quality and reliable measurements. The performance of the SC90 will always be limited by different noise sources. A high noise level will mask the echoes and make them difficult to read and interpret. The noise is measured while the SC90 operates in Passive mode with the transducer disconnected.
  • Page 306 Simrad SC90 Installation Manual Select the tab to open the page. B-Scan Select Element amplitude to 1500 Start sample to 10,000 Sample range Make sure that the channels are uniform. Record the noise value at the bottom of the page.

  • Page 307: Connecting The Transducer Cables To The Transceiver Unit

    We recommend that all tools are demagnetized to protect your equipment. Context Once the transceiver plug is connected to the Transceiver Unit, and the transducer is submerged in water, the SC90 can be set to transmit ("ping"). Caution You must never start SC90 transmissions ("pinging") when the ship is in dry dock.
  • Page 308 Simrad SC90 Installation Manual Secure the transceiver plug with all the bolts provided. Tighten the fastening screws evenly and a little at a time, alternating between screws on opposite sides of the plug, until all the screws are adequately tightened.

  • Page 309: Turning On The Entire Sc90 System For The First Time

    The transducer may be damaged if it transmits in open air. In order to power up the SC90 for the first time in a controlled manner, two tasks must be done simultaneously. Two persons are required.
  • Page 310 When all cables have been properly connected, the SC90 can be started. In order to power up the SC90 for the first time in a controlled manner, two tasks must be done simultaneously. These tasks are done on the bridge.
  • Page 311 After these tasks, the SC90 is turned on, but it is not transmitting ("pinging"). The transducer is hoisted to its upper position. If you wish to proceed with the setting to work tasks, leave the SC90 in this state. If you wish to proceed later, turn the SC90 off. Related topics...
  • Page 312 When all cables have been properly connected, the SC90 can be started. In order to power up the SC90 for the first time in a controlled manner, two tasks must be done simultaneously. These tasks are done in the sonar room.

  • Page 313: Turning On The Sc90 For Normal Use

    TX Power is by default set to Off. Caution You must never start SC90 transmissions ("pinging") when the ship is in dry dock. The transducer may be damaged if it transmits in open air. Procedure Make sure that the water depth under the keel permits you to lower the transducer.
  • Page 314 Result The SC90 starts up even if transceiver boards in the Transceiver Unit are malfunctioning. The SC90 will then need more time to finish the start-up sequence, and a short message will be provided. dialog box opens automatically when you switch the SC90 on or off.

  • Page 315: Configuring The Sc90 For Normal Operation

    Selecting which hull unit to be used with the SC90 The SC90 can be provided with different hull units. The main difference between these hull units is the length of the transducer shaft, and thus also the physical height of the entire hull unit construction.
  • Page 316 Test Setup System Test Select to open the menu. Installation menu Observe that the menu opens across the top of the SC90 Installation presentation. → On the menu, select Installation Installation Hull Unit Observe that the...

  • Page 317: Aligning The Sc90 Presentation To The Direction Of The Transducer (Sc90)

    When the hull unit is placed on the trunk, the "forward" mark on the transducer shaft sleeve - and thus also the transducer - are both misaligned. To obtain accurate SC90 presentations, this must be adjusted. Note that this task is only relevant for the SC90 Hull Unit.
  • Page 318 Insert the estimated alignment angle. Select to save the settings and close each parameter dialog box. Result Requirements Results The SC90 presentation is aligned to the direction of the transducer. The alignment value is recorded. Alignment value: Date and signature: 419050/B...

  • Page 319: Aligning The Sc90 Presentation To The Direction Of The Transducer (Sc94)

    When the hull unit is placed on the trunk, the "forward" mark on the transducer shaft sleeve - and thus also the transducer - are both misaligned. To obtain accurate SC90 presentations, this must be adjusted. Note that this task is only relevant for the SC94 Hull Unit.
  • Page 320 Insert the estimated alignment angle. Select to save the settings and close each parameter dialog box. Result Requirements Results The SC90 presentation is aligned to the direction of the transducer. The alignment value is recorded. Alignment value: Date and signature: 419050/B...

  • Page 321: Defining The Value For Sound Speed (Sound Velocity)

    In order to obtain accurate echoes, it is very important that the sound speed through the water is set correctly. Context The SC90 allows you to enter a manual value for sound speed. This setting is made on the menuThe...

  • Page 322: Defining The Physical Dimensions Of The Ship

    Prerequisites For the accurate locations of the ship dimensions, you need the detailed vessel drawings. Neither tools nor instruments are required. The SC90 is turned on, and it is working normally. Context This information is used to show the correct size of the vessel in the SC90 presentations.

  • Page 323: Defining The Installation Parameters For The Transducer

    Setting to work Defining the installation parameters for the transducer Information from a few key sensors are vital for the SC90 accuracy. In order to achieve maximum accuracy, the physical locations of these sensors - normally referred to the Ship Origin - must be recorded in the SC90 setup. For future reference, the offset values for each sensor is recorded.

  • Page 324: Defining The Installation Parameters For The Global Positioning System (Gps) Antenna

    Defining the installation parameters for the global positioning system (GPS) antenna Information from a few key sensors are vital for the SC90 accuracy. In order to achieve maximum accuracy, the physical locations of these sensors - normally referred to the Ship Origin - must be recorded in the SC90 setup.
  • Page 325 Test Setup System Test Select to open the menu. Installation menu Observe that the menu opens across the top of the SC90 Installation presentation. → → Select to open the OwnShip Instrument Position Offsets GPS Offset parameter dialog box.

  • Page 326: Setting Up The Interfaces To Peripheral Devices

    About NMEA and standard datagram formats, page 338 Setting up the interface for course gyro input In order to operate correctly, the SC90 requires input from a course gyro. In most cases a suitable course gyro is already installed on the vessel. A global positioning system (GPS) with a fitting output format can also be used.
  • Page 327 Test Setup menu. System Test Select to open the menu. Installation menu Observe that the menu opens Installation across the top of the SC90 presentation. → On the menu, select Installation Installation → Setup Sensors On the submenu, select Heading...

  • Page 328: Setting Up The Interface For Speed Log Input

    Installation Setting up the interface for speed log input In order to operate correctly, the SC90 requires input from a speed log. In most cases a suitable sensor is already installed on the vessel. A global positioning system (GPS) with a fitting output format can also be used. The current speed is shown in the Status parameter dialog box.
  • Page 329 Test Setup menu. System Test Select to open the menu. Installation menu Observe that the menu opens Installation across the top of the SC90 presentation. → On the menu, select Installation Installation → Setup Sensors On the submenu, select Speed...

  • Page 330: Setting Up The Input From A Navigation System (Gps)

    Setting up the input from a navigation system (GPS) Accurate and reliable information from navigation systems are vital to the SC90 operation. The information provided by the navigation systems are used by the SC90 software. Navigational information (position, heading and speed) is shown in the Status parameter dialog box.
  • Page 331 Test Setup menu. System Test Select to open the menu. Installation menu Observe that the menu opens Installation across the top of the SC90 presentation. → On the menu, select Installation Installation → Setup Sensors On the submenu, select Pos.System...

  • Page 332: Setting Up The Input From A Simrad Catch Monitoring System

    Prerequisites The SC90 is turned on, and it is working normally. The new sensor is physically connected to the SC90 using a serial or network cable. It is switched on and in normal operation. Neither tools nor instruments are required.

  • Page 333: Setting Up The Input From A Simrad Trawl System

    Prerequisites The SC90 is turned on, and it is working normally. The new sensor is physically connected to the SC90 using a serial or network cable. It is switched on and in normal operation. Neither tools nor instruments are required.
  • Page 334 Test Setup System Test Select to open the menu. Installation menu Observe that the menu opens across the top of the SC90 Installation presentation. → → On the menu, select Installation Installation I/O Setup...

  • Page 335: Configuring And Testing The Interface To The Motion Reference Unit (Mru)

    The information from a motion reference unit (MRU) (normally heave, roll and pitch information) is imported into the SC90 to increase the accuracy of the echo data. The SC90 is provided with a built-in motion sensor. It is placed inside the Motor Control Unit.
  • Page 336 System Test This is the offset angle Select Installation 0° transducer mark to open the menu menu. Observe that the menu opens across the top of the SC90 Installation presentation. → → On the menu, select Installation Installation I/O Setup...
  • Page 337 Setting to work Locate the 0° transducer mark. Estimate the approximate alignment angle clockwise from the 0° transducer mark to the 0° reference mark for the motion sensor. Insert the estimated alignment offset angle. Open the menu. Installation → Select Installation Alignment Select...

  • Page 338: Fine Tuning The Motion Reference Unit (Mru) Offset Values

    Context A motion reference unit (MRU) measures the vessel’s pitch and roll movements in the sea. The information provided by the motion sensor is used by the SC90 to stabilize the echo presentation. Two methods are used for fine tuning.
  • Page 339 Use a flat bottom Tilt down the sonar beam to make a bottom ring appear on the SC90 presentation. Use the Variable Range Marker to mark the diameter of the bottom ring.

  • Page 340: About Nmea And Standard Datagram Formats

    Standard NMEA 0183 communication parameters, page 340 About the NMEA datagram formats The SC90 can send and receive information to and from several different peripherals. All transmissions take place as datagrams with data sentences. Each datagram has a defined format and length.
  • Page 341 Setting to work National Marine Electronics Association For more information about the National Marine Electronics Association and the NMEA 0183 standard, refer to the organization's web site at: • http://www.nmea.org NMEA sentence structure A defines sentence structure is defined by NMEA to establish the communication between two units.
  • Page 342 Standard NMEA 0183 communication parameters The SC90 uses both NMEA and proprietary datagram formats to communicate with peripheral systems and sensors.The majority of the datagrams used by the SC90 are defined by the National Marine Electronics Association (NMEA). NMEA defines a fixed set of transmission parameters.

  • Page 343: Testing The Sc90 Operational Functionality

    The hull unit provided with the SC90 is designed to lower the transducer down below the ship’s hull when the SC90 shall be used. This is a key functionality of the SC90. It is very important that the hoist/lower function is tested before the SC90 is put to operational use.
  • Page 344 The hull unit provided with the SC90 is designed to lower the transducer down below the ship’s hull when the SC90 shall be used. This is a key functionality of the SC90. It is very important that the hoist/lower function is tested before the SC90 is put to operational use.
  • Page 345 (S302). Set the switch to position STOP. Hoist/Lower Switch 12 Power down the SC90. If the transducer is lowered when you power off the SC90, it is automatically retracted to its upper position. The Transceiver Unit powers down. The SC90 program closes down.
  • Page 346 The hull unit provided with the SC90 is designed to lower the transducer down below the ship’s hull when the SC90 shall be used. This is a key functionality of the SC90. It is very important that the hoist/lower function is tested before the SC90 is put to operational use.

  • Page 347: Testing The Operating Panel To Verify Basic Functionality

    Testing the Operating Panel to verify basic functionality The Operating Panel contains all necessary control functions for normal operation of the SC90. A test is required to verify that the Operating Panel is fully functional, and that the communication with Processor Unit is operational.
  • Page 348 • The vessel is berthed or at sea. Neither tools nor instruments are required. Caution You must never set the SC90 to "ping" unless the transducer is submerged in water. The transducer may be damaged if it transmits in open air. Context The Operating Panel contains all necessary control functions for normal operation of the SC90.
  • Page 349 Setting to work : Use the buttons to store interesting screen captures, and zoom Various Various in on details. : The buttons offer manual control of the beam training. They also Train Train control the automatic search and tracking programs. Procedure Check the functions in the field.
  • Page 350 Simrad SC90 Installation Manual Press repeatedly. Verify that the gain read-out on the Gain H- Gain H+ menu and on the top of the tilt indicator changes accordingly. Horizontal Select to open the menu. Vertical Press repeatedly. Verify that the gain read-out on the...

  • Page 351: Testing The User Interface To Verify Basic Functionality

    The Operating Panel is fully functional. Date and signature: Testing the user interface to verify basic functionality It is important that the basic functionality of the SC90 is tested before the system is put to operational use. Prerequisites The SC90 is installed as specified in this manual.
  • Page 352 • The vessel is berthed or at sea. Neither tools nor instruments are required. Caution You must never set the SC90 to "ping" unless the transducer is submerged in water. The transducer may be damaged if it transmits in open air. Procedure Make sure that the SC90 user interface is fully operational.

  • Page 353: Verifying Sc90 Operation By Means Of The Bite Functionality

    The page allows you to monitor the time series of data that is received from each B-Scan of the elements in the SC90 transducer. The start sample and the number of samples to be displayed are adjustable. Prerequisites The SC90 is installed as specified in this manual.
  • Page 354 B-Scan each of the elements in the SC90 transducer. The start sample and the number of samples to be displayed are adjustable. When you move the cursor over the B-Scan presentation of the SC90 transceiver channels, each element in the transducer is clearly identified as a long coloured vertical rectangle.
  • Page 355 Sample range These settings allow you to test the receiver performance. The sample frequency in the SC90 is 5 kHz. Since the sound travels approximately 750 meter back and forth every second, each sample will cover 750 m divided by 5000 Hz, which is approximately 15 cm.
  • Page 356 Simrad SC90 Installation Manual Example Two typical B-Scan screen captures have been provided as examples. Related topics Opening the BITE (Built-In Test Equipment) dialog box, page 388 419050/B...

  • Page 357: Measuring The Echo Level In Passive Mode

    SC90 operates in Passive mode with the transmit pulses disabled. Prerequisites The SC90 is installed as specified in this manual. The vessel is at sea. The SC90 is turned on, and it is working normally. Neither tools nor instruments are required. In order to do this test, the ship must be "silent".
  • Page 358 Echo Level System Test Adjust the until the echoes on the images on the SC90 presentation are Gain dynamic, and you can distinguish between the individual echoes. Read the current echo level displayed by the "button".

  • Page 359: Measuring The Output Voltages From The Power Supply Unit

    Setting to work Measuring the output voltages from the Power Supply Unit The purpose of the Power Supply Unit is to provide the SC90 Transceiver Unit with the necessary DC power for operation. The operation of the Power Supply Unit can be verified by means of a standard multimeter.

  • Page 360: Making A Noise/Speed Curve To Determine Vessel Noise

    Prerequisites The SC90 is turned on, and it is working normally. The vessel is at sea. Recommended minimum depth is 100 metres. If the SC90 is operated from any other compartment than the bridge, an open two-way oral communication channel with the bridge is required.
  • Page 361 Repeat the following cycle for each vessel speed: Ask the bridge to set the speed. Observe the parameter dialog box in the bottom right corner of the SC90 Status presentation. Make sure that the dialog box presents the requested speed.
  • Page 362 Simrad SC90 Installation Manual Result Speed/Noise Speed Bearing –120° –60° 0° +60° +120° +180° Sea state: Water depth: Use this table to record the noise values, or write them straight into a spreadsheet. 419050/B...
  • Page 363 Setting to work Use the following plot to record the noise values for 0° bearing. Make additional copies if required, or use the functionality of the spreadsheet program. 419050/B...
  • Page 364 Simrad SC90 Installation Manual Results Requirements A noise/speed curve is created. Date and signature: 419050/B...

  • Page 365: Testing The Interfaces With Peripheral Devices

    Prerequisites This procedure assumes that: • The sensor is connected to the SC90. It is switched on and in normal operation. • The interface port is set up with the correct communication parameters. • You are familiar with NMEA and other relevant datagram formats.
  • Page 366 Some instruments may offer other parameters and/or choices. You must always check the relevant documentation provided by the manufacturer. Procedure Observe the parameter dialog box in the Status bottom right corner of the SC90 presentation. Make sure that the dialog box presents the current position. Open the menu. Installation Select the tab to open the menu.

  • Page 367: Verifying The Communication With Speed Log

    The relevant communication parameters are recorded. Date and signature: Verifying the communication with speed log In order to operate correctly, the SC90 requires input from a speed log. The current speed is shown in the parameter dialog box. The communication with the sensor is tested.
  • Page 368 Procedure Observe the parameter dialog box in the Status bottom right corner of the SC90 presentation. Make sure that the dialog box presents the current information from the navigation sensors: Position, Heading and Speed. Open the menu.

  • Page 369: Verifying The Communication With The Course Gyro

    Neither tools nor instruments are required. Context The input from a course gyro is essential for SC90 operation. Without the input from a course gyro, the SC90 will not be able to present correct navigational information. In most cases a suitable course gyro is already installed on the vessel. A global positioning system (GPS) with a fitting output format can also be used.

  • Page 370: Verifying The Communication With The Motion Reference Unit (Mru)

    Prerequisites This procedure assumes that: • The sensor is connected to the SC90. It is switched on and in normal operation. • The interface port is set up with the correct communication parameters. • You are familiar with NMEA and other relevant datagram formats.
  • Page 371 Context A motion reference unit (MRU) measures the vessel’s pitch and roll movements in the sea. The information provided by the motion sensor is used by the SC90 to stabilize the echo presentation. These communication parameters are defined for the motion sensor.
  • Page 372 Simrad SC90 Installation Manual Observe that the parameter dialog box opens. Sensor Configuration For each communication parameter, make sure that the settings are correct. Record the settings in the result table. Result Motion Reference Unit Source system Talker ID Port...

  • Page 373: Verifying The Installation Parameters

    Setting to work Verifying the installation parameters Topics Verifying the alignment of the SC90 presentation (SC90), page 372 Verifying the alignment of the SC90 presentation (SC94), page 374 Verifying the installation parameters for the global positioning system (GPS) antenna, page 376...

  • Page 374: Verifying The Alignment Of The Sc90 Presentation (Sc90)

    When the hull unit is placed on the trunk, the "forward" mark on the transducer shaft sleeve - and thus also the transducer - are both misaligned. To obtain accurate SC90 presentations, this must be adjusted. Note that this task is only relevant for the SC90 Hull Unit.
  • Page 375 Make sure that the estimated alignment angle is correct, adjust the angle if required. Select to save the settings and close each parameter dialog box. Result Requirements Results The SC90 presentation is aligned to the direction of the transducer. The alignment value is recorded. Alignment value: Date and signature: 419050/B...

  • Page 376: Verifying The Alignment Of The Sc90 Presentation (Sc94)

    When the hull unit is placed on the trunk, the "forward" mark on the transducer shaft sleeve - and thus also the transducer - are both misaligned. To obtain accurate SC90 presentations, this must be adjusted. Note that this task is only relevant for the SC94 Hull Unit.
  • Page 377 Make sure that the estimated alignment angle is correct, adjust the angle if required. Select to save the settings and close each parameter dialog box. Result Requirements Results The SC90 presentation is aligned to the direction of the transducer. The alignment value is recorded. Alignment value: Date and signature: 419050/B...

  • Page 378: Verifying The Installation Parameters For The Global Positioning System (Gps) Antenna

    Verifying the installation parameters for the global positioning system (GPS) antenna Information from a few key sensors are vital for the SC90 accuracy. In order to achieve maximum accuracy, the physical locations of these sensors - normally referred to the Ship Origin - must be recorded in the SC90 setup.

  • Page 379: Verifying The Installation Parameters For The Transducer

    Date and signature: Verifying the installation parameters for the transducer Information from a few key sensors are vital for the SC90 accuracy. In order to achieve maximum accuracy, the physical locations of these sensors - normally referred to the Ship Origin - must be recorded in the SC90 setup.
  • Page 380 Simrad SC90 Installation Manual Observe that the menu opens across the top of the SC90 Installation presentation. → → Select to open the OwnShip Instrument Position Offsets Transducer Transducer parameter dialog box. Offset Positions Make sure that the correct offset values have been inserted.

  • Page 381: Verifying The Physical Dimensions Of The Ship

    SC90 software. Prerequisites For the accurate locations of the ship dimensions, you need the detailed vessel drawings. Neither tools nor instruments are required. The SC90 is turned on, and it is working normally. Procedure Open the menu.

  • Page 382: Adjusting The Offset Angle Between The Motion Sensor And The Direction Of The Transducer

    The information from a motion reference unit (MRU) (normally heave, roll and pitch information) is imported into the SC90 to increase the accuracy of the echo data. The SC90 is provided with a built-in motion sensor. It is placed inside the Motor Control Unit.
  • Page 383 Test Setup System Test Select to open the menu. Installation menu Observe that the menu opens across the top of the SC90 Installation presentation. → Select Installation Alignment Select Offset Insert the estimated alignment offset angle.
  • Page 384 Simrad SC90 Installation Manual Result Requirements Results The offset angle between the motion sensor and the direction of the transducer is defined. The offset value is recorded. Offset value: Date and signature: 419050/B...

  • Page 385: Creating A Backup With The Sc90 Configuration And Software Installation

    Prerequisites To create the backup image, you need the bootable USB flash drive provided with the SC90. You can also use any commercial USB flash drive, but it must be bootable, and it must have the necessary storage capacity. 419050/B...
  • Page 386 Simrad SC90 Installation Manual Context The software in use is created by Acronis. For more information about this company and their products, see their website: • http://www.acronis.com Procedure Boot the Processor Unit from the USB flash drive. Connect a mouse and a computer keyboard to the Processor Unit.

  • Page 387: Restoring A Processor Unit Image From A Usb Flash Drive Using The Acronis True Image Program

    If you restore your Processor Unit from a generic image, you must change the Windows license and then activate it before you can use the SC90. You must also reinstall the SC90 software. We recommend that you use the image you made after the SC90 installation was completed.

  • Page 388: Creating A Bootable Usb Flash Drive Using The Acronis True Image Program

    Creating a bootable USB flash drive using the Acronis True Image program A bootable USB flash drive is required for SC90 backup purposes. The software used is Acronis True Image. The software is installed on the Processor Unit. It is also copied onto the USB flash drive that is provided with the SC90.
  • Page 389 Setting to work Start the Acronis True Image program. Select the tab, and then select tool bar. Backup and recovery Create bootable media On page , do nothing. Welcome to Acronis Media Builder Select Next On page , select Rescue media contents selection True Image Select Next...

  • Page 390: Installation Remarks

    Simrad SC90 Installation Manual Installation remarks Use this page to write down comments and remarks related to the SC90 installation. When the installation has been fully completed, and all functional tests have been made to full satisfaction, representatives from each party must sign.
  • Page 391 B-Scan page allows you to monitor the time series of data that is received from B-Scan each of the elements in the SC90 transducer. The start sample and the number of samples to be displayed are adjustable. Procedure On the Processor Unit,...
  • Page 392 Simrad SC90 Installation Manual Related topics Verifying SC90 operation by means of the BITE functionality, page 351 Measuring the BITE noise with the transducer disconnected from the Transceiver Unit, page 303 419050/B...

  • Page 393: Technical Specifications

    Technical specifications Technical specifications Topics Introduction to technical specifications, page 392 Performance specifications, page 392 Power requirements, page 395 Weight and outline dimensions, page 397 Environmental requirements, page 399 Compass safe distance, page 400 Minimum display requirements, page 401 419050/B...

  • Page 394: Introduction To Technical Specifications

    Simrad SC90 Installation Manual Introduction to technical specifications These technical specifications summarize the main functional and operational characteristics of the SC90 Fish finding sonar. It also provides information related to power requirements, physical properties and environmental conditions. Note At Kongsberg Maritime, we are continuously working to improve the quality and performance of our products.
  • Page 395 : ±20 degrees (Automatic) Pitch stabilisation • : Interface to an optional peripheral motion reference unit External stabilisation sensor (MRU) is supported The SC90 has been designed to match the motion reference unit (MRU) sensors manufactured by Kongsberg Seatex. 419050/B...
  • Page 396 Hull Unit The SC90 Fish finding sonar can be provided with one of the following hull units. • The SC90 Hull Unit is designed to lower the transducer 1.0 meter below the ship’s hull. • The SC94 Hull Unit is designed to lower the transducer 2.1 meter below the ship’s hull.

  • Page 397: Power Requirements

    These power characteristics summarize the supply power requirements for the SC90. Display The display is not a part of the SC90 scope of supply. It is not manufactured by Kongsberg Maritime. For more information, refer to the end-user documentation provided by the manufacturer.
  • Page 398 Simrad SC90 Installation Manual • : 20% of nominal voltage, recovery time 3 s Maximum transient • : 600 VA (Approximately) Power consumption Power Supply Unit • : 230 VAC, 47 to 63 Hz, single phase, nominal Voltage requirement •...

  • Page 399: Weight And Outline Dimensions

    The source drawings (normally in AutoCad format) can be downloaded from our website. https://www.simrad.com/sc90 Display The display is not a part of the SC90 scope of supply. It is not manufactured by Kongsberg Maritime. For more information, refer to the end-user documentation provided by the manufacturer.
  • Page 400 422358 Transceiver Unit dimensions, page 442 385609 Processor Unit dimensions, page 438 422321 Power Supply Unit dimensions, page 447 204688 Operating Panel dimensions, page 445 413125 Hull Unit dimensions SC90, page 449 426919 Hull Unit dimensions SC94, page 452 419050/B...

  • Page 401: Environmental Requirements

    SC90 Fish finding sonar. Display The display is not a part of the SC90 scope of supply. It is not manufactured by Simrad. For more information, refer to the end-user documentation provided by the manufacturer. Processor Unit •...

  • Page 402: Compass Safe Distance

    Related topics Technical specifications, page 391 Compass safe distance If you place any of the SC90 Fish finding sonar units on the bridge, you must observe the physical distance to the compass. Display The display is not a part of the SC90 scope of supply. It is not manufactured by Simrad.

  • Page 403: Minimum Display Requirements

    Minimum display requirements Unless specifically ordered, the SC90 is not provided with a display. The display must then be purchased locally. You can use one or two displays on your SC90 Processor Unit depending on personal and/or operational preferences. Note Make sure that the chosen display meets the SC90 requirements.
  • Page 404 • : The screen size depends on personal and/or operational Physical screen size preferences. The SC90 software supports 9:16 displays. Related topics Display description, page 22 Installing the display, page 177 Technical specifications, page 391...

  • Page 405: Datagram Formats

    Datagram formats Datagram formats Topics About NMEA and standard datagram formats, page 404 NMEA datagram formats, page 407 Proprietary datagram formats, page 418 Third party datagram formats, page 429 419050/B...

  • Page 406: About Nmea And Standard Datagram Formats

    Standard NMEA 0183 communication parameters, page 406 About the NMEA datagram formats The SC90 can send and receive information to and from several different peripherals. All transmissions take place as datagrams with data sentences. Each datagram has a defined format and length.

  • Page 407: Nmea Sentence Structure

    Datagram formats The NMEA 0183 Interface Standard defines electrical signal requirements, data transmission protocol and time, and specific sentence formats for a 4800 baud serial data bus. Each bus may have only one talker but many listeners. National Marine Electronics Association For more information about the National Marine Electronics Association and the NMEA 0183 standard, refer to the organization's web site at: •...

  • Page 408: Standard Nmea 0183 Communication Parameters

    Standard NMEA 0183 communication parameters The SC90 uses both NMEA and proprietary datagram formats to communicate with peripheral systems and sensors.The majority of the datagrams used by the SC90 are defined by the National Marine Electronics Association (NMEA). NMEA defines a fixed set of transmission parameters.

  • Page 409: Nmea Datagram Formats

    Datagram formats NMEA datagram formats Topics NMEA DBS datagram, page 407 NMEA DBT datagram, page 408 NMEA DPT datagram, page 408 NMEA GGA datagram, page 409 NMEA GLL datagram, page 410 NMEA HDG datagram, page 411 NMEA HDM datagram, page 411 NMEA HDT datagram, page 412 NMEA MWD datagram, page 412 NMEA MWV datagram, page 413...

  • Page 410: Nmea Dbt Datagram

    Simrad SC90 Installation Manual : Depth in metres y.y,M : Depth in fathoms z.z,F : Checksum If you need the depth below the keel, use the NMEA DBK datagram. If you need the depth below the transducer, use the NMEA DBT datagram.

  • Page 411: Nmea Gga Datagram

    Datagram formats Description This description is not complete. For additional details, refer to the NMEA standard. : Talker identifier $— : Datagram identifier : Depth (Metres), Relative to the transducer : Offset (Metres), Relative to the transducer Positive offset numbers provide the distance from the transducer to the water line.

  • Page 412: Nmea Gll Datagram

    Simrad SC90 Installation Manual : Quality indicator for the GPS (Global Positioning System) Refer to the NMEA standard for further information of the GPS quality indicator. : Number of satellites in use (00 - 12) The number of satellites may be different from the number in view.

  • Page 413: Nmea Hdg Datagram

    The NMEA GLL telegram may be received from other instruments that are using the “ii” talker identifier. The Simrad ITI system uses the same talker identifier “ii”, and this has caused some confusion for some of our users. In order to rectify this, the ITI GLL telegram has been inhibited in the SC90.

  • Page 414: Nmea Hdt Datagram

    Simrad SC90 Installation Manual Description : Talker identifier $— : Datagram identifier : Heading (Degrees Magnetic x.x,M : Checksum NMEA HDT datagram The NMEA HDT datagram provides the true vessel heading. The information is normally provided by a course gyro.

  • Page 415: Nmea Mwv Datagram

    Datagram formats NMEA MWV datagram The NMEA MWV datagram provides the direction from which the wind blows relative to the vessel's centre line. Format $--MWV,x.x,a,y.y,b*hh<CR><LF> Description : Talker identifier $— : Datagram identifier : Wind angle (0 to 359°) : Reference = Relative = Theoretical : Wind speed...

  • Page 416: Nmea Vbw Datagram

    Simrad SC90 Installation Manual : Longitude East/West (Degrees, minutes and hundredths) yyyyy.yy,a = West = East : Speed over ground (knots) : Course over ground (Degrees True) : Date ddmmyy : Magnetic variation, East/West (Degrees) r.r,a = East = West...

  • Page 417: Nmea Vhw Datagram

    Datagram formats : Stern transverse water speed, Status = The data are valid. = The data are not valid. : Stern transverse ground speed (knots) : Stern transverse ground speed, Status = The data are valid. = The data are not valid. : Checksum NMEA VHW datagram The NMEA VHW datagram contains the compass heading to which the vessel points,...

  • Page 418: Nmea Vwr Datagram

    Simrad SC90 Installation Manual Description : Talker identifier $— : Datagram identifier : Course over ground (Degrees True) x.x,T : Course over ground (Degrees Magnetic) y.y,M : Speed over ground (knots) z.z,N : Speed over ground (km/hr) g.g,K : Mode indicator...

  • Page 419: Nmea Zda Datagram

    Datagram formats : Checksum NMEA ZDA datagram The NMEA ZDA datagram contains the universal time code (UTC), day, month, year and local time zone. Format $--ZDA,hhmmss.ss,xx,yy,zzzz,hh,mm*hh<CR><LF> Description This description is not complete. For additional details, refer to the NMEA standard. : Talker identifier $—...

  • Page 420: Proprietary Datagram Formats

    Simrad TPT datagram format, page 427 Simrad TS2 datagram format, page 428 Simrad TTS datagram format, page 428 Simrad DBS datagram format Simrad DBS is a proprietary datagram format created by Kongsberg Maritime to provide the current depth of the trawl sensor. Format @IIDBS,,,x.x,M,,<CR><LF>...

  • Page 421: Simrad Fs3300 Binary Depth Datagram Format

    The GLL datagram may be received from integrated instruments using the “ii” talker identifier. The Simrad ITI system uses the same talker identifier “ii”, and this has caused some confusion. In order to rectify this, the ITI GLL datagram has been inhibited.

  • Page 422: Simrad Hfb Datagram Format

    Simrad SC90 Installation Manual Simrad HFB datagram format Simrad HFB is a proprietary datagram format created by Kongsberg Maritime. It provides the vertical distance (height) from the headrope to the footrope, and from the footrope to the bottom. The heights are measured by an ITI TrawlEye or a height sensor.
  • Page 423 These four characters contain the target identifier on the format AT X, where X is an integer defining the target number. The SC90 will export information from maximum three tracked targets simultaneously. • If one target is tracked, one datagram is exported.

  • Page 424: Simrad Mtw Datagram Format

    : Water temperature (degrees Celcius) xx.x,C Simrad PSIMP-D datagram format Simrad PSIMP-D is a proprietary datagram format created by Kongsberg Maritime to provide the type and configuration of PS and PI sensors used by a Simrad catch monitoring system. Format $PSIMP,D,tt,dd,M,U,S,C,V,Cr,Q,In,SL,NL,G,Cb,error*chksum<CR><LF>...
  • Page 425 Datagram formats • : Catch • : Bottom • : No sensor • : Marker : Unit (meters), (feet) or (fathoms) for depth measurements (Celsius) or (Fahrenheit) for temperature measurements : Source The number (1, 2 or 3) of the sensor providing the current data values : Channel The number (1 to 30) of the communication channel for the current data source : Value...

  • Page 426: Simrad Psimp-F Datagram Format

    PSIMP-D1. Simrad PSIMP-F datagram format Simrad PSIMP-F is a proprietary datagram format created by Kongsberg Maritime to provide the type and configuration of PS and PI sensors used by a Simrad catch monitoring system. Format $PSIMP,F,S1,S2,S3,T1,T2,T3,F1,F2,F3*chksum<CR><LF>...

  • Page 427: Simrad Tds Datagram Format

    Datagram formats Simrad TDS datagram format Simrad TDS is a proprietary datagram format created by Kongsberg Maritime to provide the door spread. That is the distance between the two trawl doors. Format @IITDS,x.x,M<CR><LF> Description : Talker identifier : Datagram identifier : Distance in meters x.x,M...

  • Page 428: Simrad Tpc Datagram Format

    : Off • : On • : No answer Simrad TPC datagram format Simrad TPC is a proprietary datagram format created by Kongsberg Maritime to provide the trawl position in Cartesian coordinates. Format @IITPC,x,M,y,M,z,M<CR><LF> Description : Talker identifier : Datagram identifier : This is the horizontal distance from the vessel’s centre line, in meters.

  • Page 429: Simrad Tpt Datagram Format

    : Bearing in degrees (True, for example relative to North) : Depth in metres (0 – 2000 m) z,z,M Note The Simrad ITI measures the depth differently from the range and the bearing. If the ITI only knows the range and the bearing, the depth field is empty. 419050/B...

  • Page 430: Simrad Ts2 Datagram Format

    Simrad SC90 Installation Manual Simrad TS2 datagram format Simrad TS2 is a proprietary datagram format created by Kongsberg Maritime to provide the door spread in a dual trawl system. That is the distance between the two trawl doors. Format @IITS2,x.x,M<CR><LF>...

  • Page 431: Third Party Datagram Formats

    Datagram formats Third party datagram formats Topics Furuno CIF datagram, page 429 Kaijo VDVCD datagram format, page 432 Ryokosei RBY datagram format, page 433 Serpe BSC datagram format, page 434 Furuno CIF datagram Furuno CIF is a proprietary datagram format created by Furuno (http://www.furuno.jp). It is used to contain information about sea current.
  • Page 432 Simrad SC90 Installation Manual Note The FS field separator immediately prior to the ETX (end transmission) may or may not be present. Data sentence 56: Speed and direction for current layer one Byte # ASCII Comments Data sentence 56: Speed and direction for current layer one...
  • Page 433 Datagram formats Data sentence 66: Current indicator; derived ship speed & course Byte # ASCII Comments Data sentence 66: Current indicator; derived ship speed & course + – C Modes: = Ground tracking = Water tracking – = Check data Current speed x 10 kn Current speed x 1 kn Current speed x 0.1 kn...

  • Page 434: Kaijo Vdvcd Datagram Format

    Simrad SC90 Installation Manual Byte # ASCII Comments Current direction x 0.1° 30/31 : Normal or Abnormal Alert Heading reference: = True north = Ship heading Selected averaging time [s] (1 to 5) Byte 18 – 24: = Valid = Not valid...

  • Page 435: Ryokosei Rby Datagram Format

    Datagram formats Ryokosei RBY datagram format Ryokosei RBY is a proprietary datagram format created by Ryokosei. It is provided with the buoys to provide the geographical location of the buoy as well as the water temperature the buoy measures. The datagram also provides echo sounder information. Note The datagram format described here remains the property of the organization that defined it.

  • Page 436: Serpe Bsc Datagram Format

    Simrad SC90 Installation Manual Serpe BSC datagram format Serpe BSC is a proprietary datagram format created by Serpe. It is provided with the buoys to provide the geographical location of the buoy as well as the water temperature the buoy measures.

  • Page 437: Drawing File

    422358 Transceiver Unit dimensions, page 442 204688 Operating Panel dimensions, page 445 422321 Power Supply Unit dimensions, page 447 413125 Hull Unit dimensions SC90, page 449 426919 Hull Unit dimensions SC94, page 452 402509 Installation trunk dimensions, page 455 427176 Installation trunk dimensions, page 458 434524 Installation trunk dimensions, page 460 051344 Blind panel dimensions (ø370 mm), page 463...
  • Page 438 Simrad SC90 Installation Manual 427177 Transducer dock dimensions, page 494 419050/B...

  • Page 439: About The Drawings In The Drawing File

    Drawing file About the drawings in the drawing file Relevant drawings related to the installation and/or maintenance of the SC90 are provided for information purposes only. Note These drawings are for information and planning purposes only. Information may be omitted. Observe the source drawings for additional details.

  • Page 440: 385609 Processor Unit Dimensions

    Simrad SC90 Installation Manual 385609 Processor Unit dimensions Download the source drawing from the SC90 pages on https://www.simrad.com. 419050/B...
  • Page 441 Drawing file 419050/B...
  • Page 442 Simrad SC90 Installation Manual 419050/B...
  • Page 443 Drawing file Related topics Processor Unit description, page 23 Installing the Enix Processor Unit, page 178 Technical specifications, page 391 Weight and outline dimensions, page 397 419050/B...

  • Page 444: 422358 Transceiver Unit Dimensions

    Simrad SC90 Installation Manual 422358 Transceiver Unit dimensions Download the source drawing from https://www.simrad.com/sc90. 419050/B...
  • Page 445 Drawing file 419050/B...
  • Page 446 Simrad SC90 Installation Manual Related topics Transceiver Unit description, page 24 Installing the Transceiver Unit, page 184 Technical specifications, page 391 Weight and outline dimensions, page 397 419050/B...

  • Page 447: 204688 Operating Panel Dimensions

    Drawing file 204688 Operating Panel dimensions Download the source drawing from the SC90 pages on https://www.simrad.com. 419050/B...
  • Page 448 Simrad SC90 Installation Manual Related topics Operating Panel description, page 25 Installing the Operating Panel, page 180 Installing the Operating Panel Power Supply, page 182 Technical specifications, page 391 Weight and outline dimensions, page 397 419050/B...

  • Page 449: 422321 Power Supply Unit Dimensions

    Drawing file 422321 Power Supply Unit dimensions Download the source drawing from https://www.simrad.com/sc90. 419050/B...
  • Page 450 Simrad SC90 Installation Manual Related topics Power Supply Unit description, page 26 Installing the Power Supply Unit, page 183 Technical specifications, page 391 Weight and outline dimensions, page 397 419050/B...

  • Page 451: 413125 Hull Unit Dimensions Sc90

    Drawing file 413125 Hull Unit dimensions SC90 Download the source drawing from https://www.simrad.com/sc90. 419050/B...
  • Page 452 Simrad SC90 Installation Manual 419050/B...
  • Page 453 Drawing file Related topics Hull unit description, page 282 Installing the SC90 Hull Unit, page 140 Installing the SC94 Hull Unit, page 158 Technical specifications, page 391 Weight and outline dimensions, page 397 419050/B...

  • Page 454: 426919 Hull Unit Dimensions Sc94

    Simrad SC90 Installation Manual 426919 Hull Unit dimensions SC94 Download the source drawing from https://www.simrad.com/sc90. 419050/B...
  • Page 455 Drawing file 419050/B...
  • Page 456 Simrad SC90 Installation Manual Related topics Hull unit description, page 282 Installing the SC90 Hull Unit, page 140 Installing the SC94 Hull Unit, page 158 Technical specifications, page 391 Weight and outline dimensions, page 397 419050/B...

  • Page 457: 402509 Installation Trunk Dimensions

    Drawing file 402509 Installation trunk dimensions Download the source drawing from https://www.simrad.com/sc90. 419050/B...
  • Page 458 Simrad SC90 Installation Manual 419050/B...
  • Page 459 Drawing file Related topics Installation trunk description, page 30 Mounting the SC90 installation trunk, page 120 419050/B...

  • Page 460: 427176 Installation Trunk Dimensions

    Simrad SC90 Installation Manual 427176 Installation trunk dimensions Download the source drawing from https://www.simrad.com/sc90. 419050/B...
  • Page 461 Drawing file Related topics Installation trunk description, page 30 Mounting the SC94 installation trunk, page 130 419050/B...

  • Page 462: 434524 Installation Trunk Dimensions

    Simrad SC90 Installation Manual 434524 Installation trunk dimensions Download the source drawing from https://www.simrad.com/sc90. 419050/B...
  • Page 463 Drawing file 419050/B...
  • Page 464 Simrad SC90 Installation Manual Related topics Installation trunk description, page 30 Mounting the SC94 installation trunk, page 130 419050/B...

  • Page 465: 051344 Blind Panel Dimensions (Ø370 Mm)

    Drawing file 051344 Blind panel dimensions (ø370 mm) Download the source drawing from the SC90 pages on https://www.simrad.com. Related topics Installation trunk description, page 30 Mounting the SC90 installation trunk, page 120 Mounting the SC94 installation trunk, page 130 419050/B...

  • Page 466: 207485 Blind Panel Dimensions (Ø670 Mm)

    Simrad SC90 Installation Manual 207485 Blind panel dimensions (ø670 mm) Download the source drawing from the SC90 pages on https://www.simrad.com. Related topics Installation trunk description, page 30 Mounting the SC94 installation trunk, page 130 419050/B...

  • Page 467: 044140 Mounting Flange Dn350

    Drawing file 044140 Mounting flange DN350 Download the source drawing from the SC90 pages on https://www.simrad.com. 419050/B...
  • Page 468 Simrad SC90 Installation Manual 419050/B...
  • Page 469 Drawing file Related topics Installing the optional gate valve DN350, page 84 419050/B...

  • Page 470: 082973 Mounting Flange Dn500

    Simrad SC90 Installation Manual 082973 Mounting flange DN500 Download the source drawing from the SC90 pages on https://www.simrad.com. 419050/B...
  • Page 471 Drawing file 419050/B...
  • Page 472 Simrad SC90 Installation Manual Related topics Installing the optional gate valve DN500, page 103 419050/B...

  • Page 473: 214043 Gate Valve Installation Dn350

    Drawing file 214043 Gate valve installation DN350 419050/B...
  • Page 474 Simrad SC90 Installation Manual Related topics Installing the optional gate valve DN350, page 84 419050/B...

  • Page 475: 422915 Gate Valve Installation Dn350

    Drawing file 422915 Gate valve installation DN350 419050/B...
  • Page 476 Simrad SC90 Installation Manual Related topics Installing the optional gate valve DN350, page 84 419050/B...

  • Page 477: 083045 Gate Valve Installation Dn500

    Drawing file 083045 Gate valve installation DN500 419050/B...
  • Page 478 Simrad SC90 Installation Manual Related topics Installing the optional gate valve DN500, page 103 419050/B...

  • Page 479: 33414 Gate Valve Dimensions Dn350

    Drawing file 33414 Gate valve dimensions DN350 419050/B...
  • Page 480 Simrad SC90 Installation Manual 419050/B...
  • Page 481 Drawing file Related topics Installing the optional gate valve DN350, page 84 419050/B...

  • Page 482: 33473 Gate Valve Dimensions Dn350

    Simrad SC90 Installation Manual 33473 Gate valve dimensions DN350 419050/B...
  • Page 483 Drawing file Related topics Installing the optional gate valve DN350, page 84 419050/B...

  • Page 484: 33498 Gate Valve Dimensions Dn500

    Simrad SC90 Installation Manual 33498 Gate valve dimensions DN500 419050/B...
  • Page 485 Drawing file 419050/B...
  • Page 486 Simrad SC90 Installation Manual Related topics Installing the optional gate valve DN500, page 103 419050/B...

  • Page 487: 37357 Gate Valve Dimensions Dn500

    Drawing file 37357 Gate valve dimensions DN500 419050/B...
  • Page 488 Simrad SC90 Installation Manual 419050/B...
  • Page 489 Drawing file Related topics Installing the optional gate valve DN500, page 103 419050/B...

  • Page 490: 403038 Transducer Dock Dimensions

    Simrad SC90 Installation Manual 403038 Transducer dock dimensions Download the source drawing from https://www.simrad.com/sc90. 419050/B...
  • Page 491 Drawing file 419050/B...
  • Page 492 Simrad SC90 Installation Manual Related topics Installing the optional gate valve DN350, page 84 Installing the optional gate valve DN500, page 103 419050/B...

  • Page 493: 430192 Transducer Dock Dimensions

    Drawing file 430192 Transducer dock dimensions Download the source drawing from https://www.simrad.com/sc90. 419050/B...
  • Page 494 Simrad SC90 Installation Manual 419050/B...
  • Page 495 Drawing file Related topics Installing the optional gate valve DN350, page 84 419050/B...

  • Page 496: 427177 Transducer Dock Dimensions

    Simrad SC90 Installation Manual 427177 Transducer dock dimensions Download the source drawing from the SC90 pages on https://www.simrad.com. 419050/B...
  • Page 497 Drawing file 419050/B...
  • Page 498 Simrad SC90 Installation Manual Related topics Installing the optional gate valve DN500, page 103 419050/B...

  • Page 499: Equipment Handling

    Equipment handling Equipment handling Observe these basic rules for transportation, storage and handling of units. In this context, a unit may be any large or small part of the system. It can be supplied as part of the initial delivery, or as a spare part. The phrase box is used to describe all kinds of cases, wooden or cardboard boxes etc used to hold the unit.

  • Page 500: Transporting Kongsberg Maritime Equipment

    Simrad SC90 Installation Manual Transporting Kongsberg Maritime equipment Unless otherwise stated in the accompanying documentation, electronic, electromechanical and mechanical units supplied by Kongsberg Maritime can be only transported using methods approved for delicate and fragile equipment. Prerequisites Transportation methods approved for delicate equipment includes transportation by road, rail, air or sea.

  • Page 501: Lifting Units And Transportation Boxes

    Equipment handling Related topics Packing instructions for storage or shipping, page 507 Circuit board unpacking and handling, page 512 Lifting units and transportation boxes, page 499 Lifting units and transportation boxes Some of the boxes used to hold equipment units may be heavy. Use caution when lifting. Prerequisites Units and boxes may be heavy.

  • Page 502: Inspection Of Units And Transportation Boxes After Arrival

    Simrad SC90 Installation Manual Make sure that the unit is properly secured to the truck during the lifting and transportation operations. Handle all units and boxes with care. Note Due to the nature of Kongsberg Maritime’s products, and the extensive use of delicate electronic parts, all units and boxes must be regarded and handled as fragile equipment.

  • Page 503: Specifications For Storage Prior To Installation Or Use

    Equipment handling Specifications for storage prior to installation or use When a system, a unit or a spare part has been delivered to the customer, it may be subject to long time storage prior to installation and use. General specifications During this storage period, certain specifications must be met.

  • Page 504: Unpacking Instructions

    Simrad SC90 Installation Manual Caution Units containing lithium or alkaline batteries must be handled separately and with care. Such units are marked accordingly. Do not attempt to recharge such batteries, open them, or dispose of them by incineration. Refer to the applicable product data sheets or battery handling procedures for further details.

  • Page 505: Unpacking Standard Parts And Units

    Equipment handling Unpacking standard parts and units Prior to installation or use, parts and units must be inspected, and then unpacked from their transport boxes. It is important that this unpacking is done without inflicting damage to the equipment. Context This procedure provides the basic tasks of unpacking units (main unit, spare parts etc) from boxes shipped from Kongsberg Maritime.

  • Page 506: Unpacking Mechanical Units

    Simrad SC90 Installation Manual Once the carton is open, carefully remove all loose packing and insulation material. Check for user manuals and other documents that may have been added to the carton during packing. Check also for special tools, door keys etc.

  • Page 507: Unpacking Electronic And Electromechanical Units

    Equipment handling Place it in a stable position on the floor/work bench. Inspect the unit for visual damage. Remove any packing material that may be inside the unit. Collect and keep the relevant user manuals and/or documents provided with the unit. Related topics Unpacking standard parts and units, page 503 Unpacking electronic and electromechanical units...

  • Page 508: Specifications For Storage After Unpacking

    Simrad SC90 Installation Manual Remove any packing and desiccant material that may be inside the unit. Collect and keep the relevant user manuals and/or documents provided with the unit. Related topics Unpacking standard parts and units, page 503 Specifications for storage after unpacking The unit must whenever possible be stored in its original transportation crate until ready for installation.

  • Page 509: Packing Instructions For Storage Or Shipping

    Equipment handling If a unit needs temperature protection, the box to be used for storage and transportation must be lined on all walls, base and lid, using minimum 5 cm thick polyurethane or polystyrene foam. Most system units can normally be stored in temperatures between -30° C and +70° C. Refer to the relevant technical specifications for details.

  • Page 510: Storage After Use

    Simrad SC90 Installation Manual Take the necessary precautions if the unit must be protected against high or low temperatures, and mark the box accordingly. Mark the box clearly to identify its contents. Stored the box in a dry and dust-free area.
  • Page 511 Equipment handling Inspect all surfaces for signs of corrosion, flaking, bubbling paint, stains etc. Clean damaged or suspect areas, prepare and preserve these areas using the correct preservation mediums. Open the unit. Use a dedicated vacuum cleaner with an anti static nozzle to remove all dust from inside the unit.

  • Page 512: Cleaning A Mechanical Or Electromechanical Unit

    Simrad SC90 Installation Manual Cleaning a mechanical or electromechanical unit If an mechanical unit has been exposed to s salt atmosphere, it must be thoroughly cleaned to prevent corrosion. Prerequisites In order to clean a mechanical or electromechanical unit, you will need relevant tools and detergents.
  • Page 513 Equipment handling • The “wet parts” include the lower part of the transducer shaft, the installation trunk, the bottom of the mounting flange, the zinc anodes and the transducer. These parts are all exposed to the sea. • The “dry parts” are the rest of the hull unit, all contained inside the hull. This includes the electric motor and the Motor Control Unit.

  • Page 514: Handling Instructions For Printed Circuit Boards And Electronic Modules

    Simrad SC90 Installation Manual If the hull unit shall be sent to storage or shipped, spray it externally using a corrosion inhibitor (for example a light oil) prior to packing. 10 If relevant, place a suitably sized bag of desiccant material (silica gel or similar) into the to storage/transport box to keep the components as dry as possible.
  • Page 515 Equipment handling Note When you handle electronic circuit boards and modules, you must beware of the dangers of electrostatic discharge (ESD), both to yourself and to the equipment. In order to ensure safe transport and storage, circuit boards and other electronic units will always be wrapped in a clear plastic protective bag, and the bag will be sealed.

  • Page 516: Returning A Printed Circuit Board Or An Electronic Module To Kongsberg Maritime

    Simrad SC90 Installation Manual Returning a printed circuit board or an electronic module to Kongsberg Maritime If you wish to return a printed circuit board or an electronic module to us – either operational or defective – certain rules apply.

  • Page 517: About Electrostatic Discharge (Esd)

    Equipment handling About Electrostatic Discharge (ESD) Electrostatic discharge (ESD) is the sudden flow of electricity between two electrically charged objects. Such flow can be caused by contact, an electrical short, or dielectric breakdown. ESD can cause serious damage to printed circuit boards and electronic modules.

  • Page 518: Disposal Of Old Products

    Simrad SC90 Installation Manual Precautions to prevent Electrostatic Discharge (ESD) Sensitive printed circuit boards and electronic modules must always be transported and stored in protective antistatic packing bags. The circuit boards and modules must not be transported or stored close to strong electrostatic, electromagnetic or radioactive fields.
  • Page 519 Equipment handling Product recycling service Kongsberg Maritime offers a product recycling service. The service is described on our website. • https://www.km.kongsberg.com → → Observe the following path: Products Services Product recycling We accept all Kongsberg Maritime products for recycling free of charge. The cost of having products removed, packed and delivered to a Kongsberg Maritime registered company location is, however, not covered by us.

  • Page 520: General Safety Rules

    Safety is important. The safety precautions must be followed at all times during installation and maintenance work. WARNING The SC90 operates on 115 and/or 230 VAC 50/60 Hz. This voltage is lethal! You must never work alone on high-voltage equipment! The hull unit is powered by a 3-phase high voltage.

  • Page 521: General Supply Conditions

    General supply conditions General supply conditions The following general supply conditions apply to this Simrad SC90 delivery. Topics Receipt, unpacking and storage, page 519 Equipment responsibility, page 519 Receipt, unpacking and storage Upon accepting shipment of the equipment, the shipyard and/or the dealer must ensure that the delivery is complete and inspect each shipping container for evidence of physical damage.
  • Page 522 • The period of time between commissioning and the final acceptance of the equipment by the end user or owner Unless other arrangements have been made in the contract, the Simrad SC90 warranty period (as specified in the contract) begins when the acceptance documents have been signed.
  • Page 523 ........16 acoustic noise..........78 propellers..........78 purpose of this manual ........15 rattle noise ..........80 registered trademark SIMRAD ......16 reverberation..........81 B-Scan self noise ..........78 testing the receiver and transmitter serial lines..........254 channels..........
  • Page 524 Simrad SC90 Installation Manual diagram............ 21 cable terminations ........259 book cable trays..........257 purpose ............ 15 grounding ..........259 target audience ........... 15 identification..........259 bootable physical protection........258 creating bootable USB flash drive ....386 radio frequency interference......258...
  • Page 525 Index approval of installation drawings ..... 15, Øverland UPC-3005 Serial line splitter..... 216 53, 123, 133, 143, 160, 437 Øverland UPC-5000P Serial line splitter ... 220 cleaning verify correct cable connections ..... 280 a electromechanical unit ......510 vessel ground cable ........231 a hull unit ..........
  • Page 526 Simrad SC90 Installation Manual Ryokosei RBY (buoy data) ......433 about ............. 437 Serpe BSC (buoy data)........ 434 blind panel outline dimensions TDS (trawl door distance) ......425 drawing .......... 463–464 TFI (trawl fill) .......... 425 computer ..........397 TPC (trawl position in Cartesian computer outline dimensions drawing ....
  • Page 527 Index installation drawings ........54 unpacking ..........505 www.simrad.com ........16 electrostatic discharge (ESD) about ............. 515 datagram format........408 preventing..........516 drawing what is it? ..........515 3–phase AC mains to motor control unit ... 249 emergency hoist ac power cable.......... 229 connecting to hull unit ........
  • Page 528 Simrad SC90 Installation Manual datagram format........410, 419 failures global positioning system support if something breaks down..... 18 scope of supply........... 40 familiarization verify installation parameters for antenna ..376 gate valve ........... 88, 106 global positioning system (GPS) hull unit ....... 147, 164, 285–286 setting up the interface ........
  • Page 529 Index choose the best location for the Operating restore from a backup image on a USB flash Panel ............. 62 drive ............ 385 choose the best location for the Operating Panel return electronic modules to Kongsberg Power Supply ........... 62 Maritime ..........
  • Page 530 Simrad SC90 Installation Manual familiarization ......147, 164, 285–286 mounting flange, gate valve and transducer installation, side view example ..71–72, dock installation ........ 100, 118 74–75, 145–146, 162–163 sonar room ........155, 173 installation, top view example ....70, transducer ........
  • Page 531 Index setting up navigation sensor interface....328 weight ........... 397 setting up the catch sensor interface....330 lifting setting up the gyro interface ......324 hull unit ........... 148, 165 setting up the motion reference unit (MRU) transportation boxes ........499 interface..........
  • Page 532 Simrad SC90 Installation Manual hull unit ......... 89, 107, 152, 170 transducer dock ........89, 107 National Marine Electronics mechanical unit Association ......... 338, 404 cleaning ..........510 navigation sensor unpacking ..........504 setting up the interface ........ 328 minimum requirements verifying the interface ......
  • Page 533 Index noise display ........... 395 about acoustic noise ........76 Processor Unit.......... 395 ambient noise..........80 operational power cavitation..........79 verify ............ 298 contributing factors ........76 optional item electrical noise ........78, 81 gate valve ..........39 flow noise ..........79 motion reference unit (MRU) ......
  • Page 534 Simrad SC90 Installation Manual transducer ..........29 power up important reminder ........17 precautions electrostatic discharge (ESD) ......516 prerequisites packing cable installation ........198 instructions ..........507 preventing parts identification electrostatic discharge (ESD) ......516 hull unit ....... 147, 164, 285–286 printed circuit boards Motor Control Unit ........
  • Page 535 Index making a noise/speed curve to determine vessel verifying the quality of the hull unit noise............ 358 installation........155, 173 measuring noise at different speeds ....358 verifying the quality of the installation trunk measuring noise in passive mode ... 301, mounting ........
  • Page 536 Simrad SC90 Installation Manual PSIMP-D required items datagram format........422 not provided with the delivery ......34 PSIMP-F requirement datagram format........424 skills of installation personnel ......55 publication requirements purpose ............ 15 ac mains power......... 395 target audience ........... 15 approval by classification society......
  • Page 537 16 sound speed value........319 Simrad DBS sound velocity value........319 datagram format........418 synchronization mode ......... 226 Simrad FS3300 binary depth synchronization port........225 datagram format........419 self noise Simrad GLL acoustic noise..........78 datagram format........419...
  • Page 538 Simrad SC90 Installation Manual Simrad TPC sound velocity datagram format........426 define value ..........319 Simrad TPP specification datagram format........426 3–phase AC mains to motor control unit ... 249 Simrad TPT specifications datagram format........427 ac power cable.......... 229 Simrad TS2 compass safe distance .........
  • Page 539 Index support brackets hull unit ......... 89, 107, 152, 170 datagram format........425 transducer dock ........89, 107 this manual support information......... 47 purpose ............ 15 switch target audience ........... 15 on ............311 tolerances switch off supply power ..........44 important reminder ........
  • Page 540 Simrad SC90 Installation Manual TPT datagram format........427 outline dimensions drawing ......221 trawl door distance technical specifications........ 219 TDS datagram format ......... 425 TS2 datagram format ........428 general requirements ........44 trawl fill minimum requirements ......35, 44 TFI datagram format ........
  • Page 541 ....195 prerequisites ..........198 wiring diagram computer ..........192 Processor Unit.......... 192 sonar room ..........193 topside ........... 192 worker skills requirements for installation......55 www.simrad.com document downloads ........16 datagram format........417 419050/B...
  • Page 542 ©2018Kongsberg Maritime ISBN xxx...

Table of Contents
