Electric Screwdrivers
EL 24V Series
Maintenance Information
Save These Instructions

Advertisement

loading
Need help?

Need help?

Do you have a question about the EL 24V Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Ingersoll-Rand EL 24V Series

  • Page 1 Form 16575318 Edition 1 April 2005 Electric Screwdrivers EL 24V Series Maintenance Information Save These Instructions...
  • Page 2 WARNING • Maintenance procedures have the potential for severe shock hazard and should be performed by qualified personnel. • Always wear eye protection when operating or performing maintenance on this tool. Always turn off the electrical supply and disconnect the electrical cord before installing, removing or adjusting any accessory on this tool, or before performing any maintenance on this tool.
  • Page 3 If the Brush Assemblies need to be replaced, desolder the blue and Remove the Push Rod (35 or 36) from the Armature. red Motor wires and remove the Brush Screws (26 or 34). Inspect the Push Rod. If it is worn, replace it. Using a thin blade screwdriver, remove the Motor Assembly 10.
  • Page 4 Apply grease to the end of the Plunger (13 or 37) and insert it with NOTICE the Plunger Spring (14 or 38) into the Switch Plate. Insert a Switch Adjusting Gauge Rod part no. EL0410B-SG into the Motor Assembly. Model EL0109 has only one bit Retaining Ball. Place the Gear Case and Motor together by aligning the Motor Assembly Springs with the notches in the Gear Case.
  • Page 5: Troubleshooting Guide

    Troubleshooting Guide Screwdriver fails to rotate (forward or reverse) Defective Power Cord Assembly. Replace the Power Cord Assembly if necessary. Is there power to the tool? No power from the controller. Repair or replace (see Controller Service manual). Defective Trigger Switch. Does the Trigger Switch click Replace the Trigger Switch.
  • Page 6 Troubleshooting Guide (Continued) Shutoff brake malfunctions more than one index of the Clutch. Does the speed of the Bit exceed rated Motor magnet is demagnetized. speed by more than 100 rpm? Replace the motor. Is Brake Switch functioning? (Does it Defective Brake Switch.
  • Page 7: Related Documentation

    Related Documentation For additional information refer to: Electric Screwdrivers Product Safety Information Manual Form 16573685. Electric Screwdrivers Product Information Manual Form 16578668. Electric Screwdrivers Product Parts List Manual Form 16574642. Manuals can be downloaded from www.irtools.com. Form 16575318-Edition 1...
