ASSEMBLY

• Assembly requires two persons.
• Place all parts in a cleared area and remove the
packing materials. Do not dispose of the packing
materials until you finish all assembly steps.
• Left parts are marked "L" or "Left" and right parts
are marked "R" or "Right."
• To identify small parts, see page 5.
1. Go to www.proformservice.com/registration
on your computer and register your product.
• activates your warranty
• saves you time if you ever need to contact
Customer Care
• allows us to notify you of upgrades and offers
Note: If you do not have internet access, call
1-888-533-1333 and register your product.
2. Move the Frame (1) and the Upright (2) apart
until the Frame Pin (13) snaps into the Frame;
this is the storage position.
Next, pull the Frame Pin (13), press downward
on the Upright (2), and release the Frame Pin
into the next hole in the Frame (1); this is the
upright position.
• In addition to the included tool(s), assembly
requires the following tool(s):
one Phillips screwdriver
one adjustable wrench
Assembly may be easier if you have a set of
wrenches. To avoid damaging parts, do not use
power tools.
1
2
6
2
1
13
