SBC84600 Series Quick Installation Guide
5.
If the Audio kit, AX93102, is used, plug the 10-pin
female box-header of the AX93102 onto the 10-pin
male box-header of the SBC84600 as shown on
Figure 3.
6.
Make sure the spacer support (e) fit into the hole (f)
on the SBC84600.
(f)
6
(e)
©Copyright 2005 AXIOMTEK Co., Ltd.
AX93102
10-pin female
box-header
10-pin male
box-header
Version A7 September 2005
Printed in Taiwan
94284600060E
