Installation Procedures

Please follow the steps below to install the SBC84600 onto a
chassis:
1. Remove the pillar (a) from the SBC84600 as shown in
Figure 1.
2. Screw the pillar (a) removed from the SBC84600 and
another three pillars (c), which have same height with
the pillar (a), to the chassis as shown in the Figure 2.
3. Use the bolt (b) on the SBC84600 module to screw
the module with the pillar (a) on the chassis.
4
Figure 1.
