SBC84600 Series Quick Installation Guide
COM4 Signal/+5V Selection
JP10
Default: COM Signal
COM3 Signal/+5V Selection
JP11
Default: COM Signal
Compact Flash Voltage Selection
JP12
Default: 3.3V
III. SBC84600 Connectors
Connectors
44 Pin IDE Connector
44-pin LCD Connector
Flat Panel Bezel Connector
20-pin LCD Connector
CPU FAN +5V Connector
Printer Port Connector
Digital I/O Port Connector
ATX Power On/Off Button
Power Input Connectors
IrDA Connector
AC97 Link Interface
Keyboard and Mouse
Connector
Temperature sensor
IV. AX93102 Connector
Connectors
CD AUDIO INPUT
For SBC84600VEA series products only.
2
Label Connectors
CN1 TV Connector
CN2 FDD Connector
CN3 USB connector
CN4 VGA CRT Connector
CN5 Ethernet Connector
CN7 PC/104 Connector
CN8 COM Connector
CN9 COM Connector
CN10 COM Connector
CN11 COM Connector
CN12 Compact Flash Connector
CN13 VIDEO Connector
JP17
Label Connectors
CN2 AUDIO PHONE JACK
©Copyright 2005 AXIOMTEK Co., Ltd.
Short 2-3
Short 2-3
Short 1-2
Label
CN14
CN15
USB1, USB2
VGA1
LAN1
J1, J2
COM1
COM2
COM3
COM4
CF1
VIDEO1
Label
CON1
Version A7 September 2005
Printed in Taiwan
94284600060E
