1 - Installation

1.2 DIMENSIONAL DETAILS

1.3 PANEL CUT-OUT

48
mm
65
mm min.
1.89
in
2.56
in min.
48
mm
1.89
in
20
mm max.
0.79
in max.
45 +0.6 mm
1.78 +0.023 in
120
mm
4.72
in
5
