ascon M1 line Manual page 31

6 - Technical specification
Features
(at 25°C enviromental temp.)
Operating mode
and Outputs
Control mode
OP1 output
OP2 output
AL1 alarm
(indicator with 2 alarms)
AL2 alarm
30
Description
Indicator with 2 alarms
1 PID loop or 1 ON-OFF
loop with 1 Alarm
Algorithm
Proportional band (P)
Integral time (I)
Derivative time (D)
Cycle time
Overshoot control
High limit
Hysteresis
SPST relay N.O., 2A/250Vac (4A/120Vac) for resistive load
Triac, 1A/250Vac for resistive load
SSR drive, not isolated: 5Vdc, ± 10%, 30mA max.
SPST relay N.O., 2A/250Vac (4A/120Vac) for resistive load
Hysteresis 0.1...10.0% full scale
Active high
Active low
Hysteresis 0.1...10,0% c.s.
Active high
Action
Active low
Special function
AL1 alarm
OP1 - relay or Triac
OP2 - SSR drive or relay
Control output
OP1 - relay or Triac
OP2 - SSR drive or relay
PID with overshoot control or ON OFF
0.5...999.9%
0.1...100.0 min
0.01...10.00 min
1...200 s
0.01...1.00
100.0...10.0%
0.1...10.0%
Absolute threshold: full scale
Deviation threshold
Action type band threshold
Absolute threshold
Sensor break
AL2 alarm
OP2 - SSR drive or relay
OP1 - relay or Triac
AL2 alarm
OP2 - SSR drive or relay
OP1 - relay or Triac
OFF = O
PID algorithm
ON-OFF algorithm
±range
0...range
whole range
