Icons table

ICONS TABLE
Main universal input
Thermocouple
RTD (Pt100)
Delta Temp (2x RTD)
mA and mV
Custom
Frequency
Auxiliary input
Current transformer
mA Remote setpoint
Volt Remote setpoint
Feedback
potentiometer
34
Digital input
Isolated contact
NPN open collector
TTL open collector
Setpoint
Local
Stand-by
Keypad lock
Outputs lock
Start-up function
Timer function
Memorized
Remote
Setpoint programmer
Digital input
connected functions
Auto/Manual
Run, Hold, Reset and
program selection
PV hold
Setpoint slopes
inhibition
Output
SPST Relay
Triac
SPDT Relay
mA
mA mV
SSR drive
